Switching Power Supplies
PS5R-V Series
PRODUCT DESCRIPTION
DIN-rail mount switching power supplies
with global approvals for both industrial and
hazardous locations
KEY FEATURES
• Compact size preserves panel space
STANDARDS COMPLIANCE
Applicable Standards
UL508
UL1310
1
ANSI/ISA 12.12.01
CSA C22.2 No.107.1
CSA C22.2 No.213
CSA C22.2 No.223
1
EN60950-1
EN50178
EN61204-3
EN50581
SEMI F47
Note 1: PS5R-VA/VB/VC/VD/VE only
Note 2: EN60950-1, EN50178 only
—
Mark
File No. or Organization
UL/c-UL Listed
File No. E467154, E177168
• Slim size (width):
22.5mm (10W/15W/30W)
36mm (60W/90W)
46mm (120W)
60mm (240W)
• Universal Voltage Input:
85-264V AC/100-370V DC
TÜV SÜD
²
EU Low Voltage Directive,
EMC Directive
RoHS Directive
EPRI
• Wide operating temperature range
• Spring-up terminals accept ring & fork
terminals
• Approved for use in Class I Division 2
hazardous locations
• Can be installed in 6 directions
PART NUMBERS
Output Capacity
7.5W
10W
15W
30W
60W
90W
120W
240W
Part Number
PS5R-VA05
PS5R-VA12
PS5R-VA24
PS5R-VB05
PS5R-VB12
PS5R-VB24
PS5R-VC12
PS5R-VC24
PS5R-VD24
PS5R-VE24
PS5R-VF24
PS5R-VG24
Input Voltage
Output Voltage
5V
12V
24V
5V
12V
24V
12V
24V
24V
24V
24V
24V
Output Current
1.5A
0.6A
0.3A
2.0A
1.3A
0.65A
2.5A
1.3A
2.5A
3.75A
5.0A
10.0A
• 10W ~ 90W meet NEC Class 2 output ratings
• Overcurrent protection with auto-reset
• Meets SEMI F47 Sag Immunity (208V AC input)
• RoHS compliant
• Five-year factory warranty
100 to 240V AC
(Voltage range: 85 to 264V
AC /
100 to 370V DC)
Part Number Structure
PS5R - V
Output Capacity
A: 7.5W
05: 5V
3
B: 10W/15W
12: 12V
4
C: 30W
24: 24V
D: 60W
E: 90W
F: 120W
Note 3: PS5R-VA/VB only
G: 240W
Note 4: PS5R-VA/VB/VC only
Use only for interpreting part numbers.
Do not use for developing part numbers.
Output Voltage
1
SPECIFICATIONS
Model
5V DC output
12V DC output
24V DC output
PS5R-VA05
PS5R-VA12
PS5R-VA24
7.5W
PS5R-VB05
PS5R-VB12
PS5R-VB24
15W (5V Model is 10W)
-
PS5R-VC12
PS5R-VC24
30W
-
-
PS5R-VD24
60W
-
-
PS5R-VE24
90W
-
-
PS5R-VF24
120W
-
-
PS5R-VG24
240W
Output Capacity
Rated Input Voltage
(Single-phase two-wire)
1
100 to 240V AC
(Voltage range: 85 to 264V AC/100 to 370V DC) (Load ≤ 80% at 100-105V DC)
50/60 Hz
5V:
12V, 24V:
5V:
12V, 24V:
0.25A
0.35A
0.14A
0.19A
Frequency
Input Current (Typ.)
100V AC
230V AC
100V AC
5V: 0.20A 12V, 24V: 0.18A
5V: 0.12A 12V, 24V: 0.10A
15A
36A
0.7A
0.3A
18A
45A
0.5mA max.
1.0mA max.
1.3A
0.8A
1.1A
0.6A
1.4A
0.7A
41A
2.7A
1.2A
14A
30A
Input
Inrush Current (Typ.)
(Ta=25°C, cold start)
Leakage Current
Efficiency (Typ.)
(at rated output)
2
230V AC
120V AC
230V AC
100V AC
Power Factor (Typ.)
Rated Voltage/Current
230V AC
100V AC
230V AC
5V: 74%, 12V: 79%, 24V: 80%
5V: 73%, 12V: 77%, 24V: 76%
—
—
5V/1.5A, 12V/0.6A, 24V/0.3A
5V: 77%, 12V: 82%, 24V: 84%
5V: 73%, 12V: 80%, 24V: 81%
—
—
5V/2.0A
3
, 12V/1.3A, 24V/0.65A
±10%
5V: 53ms, 12V: 34ms, 24V: 36ms
5V: 330ms 12V: 215ms
24V: 230ms
500ms max.
5V, 12V: 200ms max. 24V: 250ms max.
12V: 83%, 24V: 85%
12V: 85%, 24V: 87%
—
—
12V/2.5A, 24V/1.3A
12V: 13ms, 24V: 15ms
12V: 110ms 24V: 110ms
600ms max.
86%
86%
—
—
24V/2.5A
13ms
105ms
800ms max.
88%
89%
0.86
24V/3.75A
±5%
20ms
30ms
33ms
700ms max.
0.99
0.92
24V/5A
±10%
30ms
89%
90%
0.96
24V/10A
Adjustable Voltage Range
Output Holding Time
(Typ.) (at rated output)
100V AC
230V AC
45ms
285ms
500ms max.
5V, 12V: 200ms max
24V: 250ms max
40ms
800ms max.
Start Time
(at rated input and output)
Rise Time
(at rated input and output)
200ms max.
0.4% max.
1.0% max.
0.05%/°C max.
(-10 to +50°C )
Output
Input Fluctuation
Load Fluctuation
Temperature Change
5V: 2.5% max. 12V, 24V: 1.0% max.
0.04%/°C max. (-10 to
0.05%/°C max. (-10 to +65°C )
+65°C )
5V: 8% p-p max. (-25 to -10°C)
12V: 6% p-p max. (-25 to -10°C)
24V: 4% p-p max. (-25 to -10°C)
5V: 8% p-p max. (-25 to -10°C)
12V: 6% p-p max. (-25 to -10°C)
24V: 4% p-p max. (-25 to -10°C)
5V: 5% p-p max. (-10 to +0°C)
12V: 2.5% p-p max. (-10 to +0°C)
24V: 1.5% p-p max. (-10 to +0°C)
5V: 2.5% p-p max. (0 to +65°C)
12V: 1.5% p-p max. (0 to +65°C)
24V: 1% p-p max. (0 to +65°C)
12V: 0.05%/°C max. (-10 to +50°C)
24V: 0.05%/°C max. (-10 to +55°C)
12V: 6% p-p max. (-25 to -10°C)
24V: 4% p-p max. (-25 to -10°C)
12V: 2.5% p-p max. (-10 to +0°C)
24V: 1.5% p-p max. (-10 to +0°C)
12V: 1.5% p-p max. (0 to +50°C)
24V: 1% p-p max. (0 to +55°C)
0.05%/°C max.
(-10 to +55°C )
0.05%/°C max.
(-25 to +55°C )
0.05%/°C max.
(-25 to +50°C)
Regulation
4% p-p max. (-25 to -10°C)
Ripple
(including noise)
5V: 5% p-p max. (-10 to +0°C)
12V: 2.5% p-p max. (-10 to +0°C)
24V: 1.5% p-p max. (-10 to +0°C)
5V: 2.5% p-p max. (0 to +65°C)
12V: 1.5% p-p max. (0 to +65°C)
24V: 1% p-p max. (0 to +65°C)
1.5% p-p max. (-10 to +0°C)
1% p-p max. (0 to
+55°C)
1% p-p max. (0 to
+50°C)
101% min. (auto reset)
1% p-p max. (0 to +55°C)
1% p-p max. (0 to
+50°C)
Overcurrent Protection
Operation Indicator
Dielectric Strength
Between input and output terminals
Between input and ground terminals
Between output and ground terminals
105% min. (auto reset)
LED (green)
3,000V AC, 1 minute
2,000V AC, 1 minute
500V AC, 1 minute
105% min. (auto reset)
Insulation Resistance
Operating Temperature
4
(No freezing)
Operating Humidity (no condensation)
Storage Temperature (No freezing)
Storage Humidity (no condensation)
Between input and output terminals: 100MΩ min. (500V DC megger) Between input and ground terminals: 100MΩ min. (500V DC megger)
-25 to +75°C
-25 to +70°C
20 to 90% RH
-25 to +75°C
20 to 90% RH
10 to 55Hz, amplitude 0.33mm, 2 hours each in 3 axes
(when used with BNL6 end clips)
10 to 55Hz, amplitude 0.375mm, 2 hours each in 3 axes
(when used with BNL8 end clips)
10 to 55Hz, amplitude 0.21mm, 2
hours each in 3 axes
(when used with BNL6 end clips)
10 to 55Hz, amplitude 0.375mm, 2
hours each in 3 axes (when used with
BNL8 end clips)
10 to 55 Hz, amplitude
0.375mm, 2 hours each
in 3 axes
(when used with part no.
BNL6 mounting clips)
-25 to +65°C
Vibration Resistance
10 to 55Hz, amplitude 0.375mm, 2 hours each in 3 axes
(when used with BNL6 end clips)
Shock Resistance
Expected Life
5
EMI
EMC
300 m/s
2
(30G), 3 times each in 6 directions
8 years minimum (at the rated input, 50% load, operating temperature +40°C, standard mounting direction)
EN61204-3 (Class B)
EN61204-3 (industrial)
UL508 (Listing), UL1310 Class 2, ANSI/ISA-12.12.01
CSA C22.2 No. 107.1, 213, 223 EN60950-1, EN50178
SEMI F47 (at 208V AC input only)
IP20 (EN60529)
75H × 45W × 70D
130g
140g
90H × 22.5W × 95D
150g
M3.5
260g
95H × 36W × 108D
310g
115H × 46W × 121D
470g
125H × 60W × 125D
960g
UL508 (Listing) ANSI/ISA-12.12.01
CSA C22.2 No. 107.1, 213
EN60950-1, EN50178
EMS
Safety Standards
Other Standard
Degree of Protection
Dimensions (mm)
Weight (approx.)
Terminal Screw
*At normal temperature and humidity unless otherwise specified.
Note 1: DC input voltage is not subject to safety standards. When using on DC input, connect a fuse to the input terminal for DC input protection.
Note 2: Under stable state.
Note 3: PS5R-VB05 (5V DC/2.0A) is 10W (Up to 3.0A at Ta = 0 to 40°C. Not subject to safety standards above 2.0A.)
Note 4: See the output derating curves.
Note 5: Calculation of the expected life is based on the actual life of the aluminum electrolytic capacitor. The expected life depends on operating conditions.
2
CHARACTERISTICS
Operating Temperature vs. Output Current (Derating Curves)
PS5R-VA05, -VA12, -VA24
100
90
80
Conditions: Natural air cooling (Operating temperature is the temperature around the switching power supply.)
PS5R-VB05, -VB12, -VB24
Mounting A,E
100
90
80
PS5R-VC12
Mounting A
100
90
80
Mounting A
Input Voltage:
85-100V AC
Output Current (%)
Output Current (%)
70
60
50
40
30
20
10
0
-30 -20 -10
Output Current (%)
70
60
50
40
30
20
10
0
-30 -20 -10
Input Voltage:
85-100V AC
70
60
50
40
30
20
10
Mounting B, C, D, F
Mounting B, C, D, E, F
Mounting B, C, D, E, F
0
10
20
30
40
50
60
70
Operating Temperature (˚C)
0
10
20
30
40
50
60
70
80
Operating Temperature (˚C)
0
10
20
30
40
50
60
70
80
0
-30 -20 -10
Operating Temperature (˚C)
80
PS5R-VC24
100
90
80
PS5R-VD24
Mounting A, B
100
90
80
70
60
50
40
30
20
10
0
-30 -20 -10
0
10
20
30
40
50
60
70
80
PS5R-VE24
Mounting E
100
90
80
70
60
50
40
30
20
10
0
-30 -20 -10
0
10
20
30
40
50
60
70
80
Mounting A
Mounting E
Output Current (%)
70
60
50
40
30
20
10
Mounting B, C, D
Mounting C
Mounting D, E, F
0
10
20
30
40
50
60
70
80
Mounting F
Mounting A
Output Current (%)
Output Current (%)
Input Voltage:
85-100V AC
Input Voltage:
85-100V AC
Mounting
B, C, D, F
0
-30 -20 -10
Operating Temperature (˚C)
Operating Temperature (˚C)
Operating Temperature (˚C)
PS5R-VF24
100
90
80
60
50
40
30
20
10
0
-30 -20 -10
PS5R-VG24
Mounting C, E
Mounting B, D
100
90
80
Mounting A
Mounting E
Mounting B
Output Current (%)
Output Current (%)
70
70
60
50
40
30
20
10
Mounting F
0
10
20
30
40
50
60
70
Mounting A
Mounting
C, D, F
0
10
20
30
40
50
60
70
80
Operating Temperature (˚C)
80
0
-30 -20 -10
Operating Temperature (˚C)
Input Voltage vs. Output Current (Derating Curves) Ta=25°C
PS5R-VB05, -VB12, -VB24, -VC12, -VC24, -VD24,
-VE24, -VF24
100
90
80
70
60
50
40
30
20
10
PS5R-VA05, -VA12, -VA24, -VG24
100
90
AC
DC
Output Current
(%)
Input Voltage (V)
264
370
Output Current (%)
80
70
60
50
40
30
20
10
0
(ACV) 85 100
(DCV) 100 140
0
(ACV)
85
100
(DCV)100 105
Input voltage (V)
264
370
Overcurrent Protection Characteristics
PS5R-VA/VB/VC/VD/VF
100
PS5R-VE24
100
95
PS5R-VG24
100
95
Intermittent Operation
Output Voltage (%)
Output Voltage (%)
Output Voltage (%)
Intermittent Operation
0
0
100
Intermittent Operation
0
0
100
-30
0
0
Output Current (%)
100
105 and over
Output Current (%)
Output Current (%)
101 and over
105 and over
3
Operating Temperature Approved by Safety Standards
Part Number
PS5R-VA05, -VA12, -VA24
PS5R-VB05, -VB12, -VB24
PS5R-VC12
PS5R-VC24
PS5R-VD24
PS5R-VE24
PS5R-VF24
PS5R-VG24
UL508, CSA C22.2 No.107.1, ANSI/ISA12.12.01, EN60950-1, EN50178
Mounting A
65
65
50
55
55
50
55
50
Mounting B
60
60
45
55
40
40
40
35
Mounting C
60
60
45
50
40
40
45
30
Mounting D
60
60
45
45
40
40
40
30
Mounting E
65
60
45
45
45
45
45
45
Mounting F
60
60
45
45
35
40
35
30
MOUNTING STYLE
Up
Mounting A
(Vertical, standard)
Mounting B
(Upright)
Mounting C
(Right side up)
Mounting D
(Left side up)
Mounting E
(Upside down)
Mounting F
(Downward)
Front Panel
PS5R-VA
PS5R-VB/VC PS5R-VD/VE/VF PS5R-VG
Marking
L, N
INP U T
Name
AC Input Terminal
Ground Terminal
Description
Voltage range: 85 to 264V AC/100 to 370V DC
Be sure to connect this terminal to a proper
ground.
+V: Positive output terminal
-V: Negative output terminal
Allows adjustment within ±10%. (VE = ±5%)
Turning clockwise increases the output voltage.
Turning counterclockwise decreases the output
voltage.
Illuminates when the output voltage is on.
INPUT 50/60Hz
100 -240 VAC
L
N
+V, -V
DC ON
DC Output Terminals
ON
VR .
ADJ
VR.
ADJ
VR.ADJ
DC ON
+V
Output Voltage Adjustment
Operation Indicator (green)
OUTPUT
-V
O U TP U T
ACCESSORIES
Panel Mounting Bracket
2
Applicable Switching Power Supply
PS5R-VB
PS5R-VC
PS5R-VD
PS5R-VE
PS5R-VF
PS5R-VG
Part Number
PS9Z-5R1B
PS9Z-5R2B
PS9Z-5R1C
PS9Z-5R1E
PS9Z-6R1F
PS9Z-6R2F
Remarks
—
For side mounting
—
—
—
For side mounting
Note 2: Used when installing on a panel directly, PS5R-VA model does not require panel mounting bracket.
DIN Rail (35mm-wide)
Length
1000mm
Part Number
BNDN1000
Material
Aluminum
End Clip
Part Number
BNL6
BNL8
4
京公网安备 11010802033920号
EEWORLD
