Product Data
Product
Description
The 3M Fire Barrier Pass-Through Device
is a one-piece hinged metal enclosure
designed to prevent the passage of fire and
smoke. The metal device has a fixed
firestopping intumescent material which
works in conjunction with foam smoke seals
and an optional mounting bracket.
It has been contractor-designed to allow for
use in either retrofit or new construction
applications where an “install and be done”
technology is needed. It is designed to provide
years of dependable through-penetration
firestopping with no reapplication of
additional product to maintain its rating.
The 3M Fire Barrier Pass-Through Device
achieved up to 3 hour fire ratings (dependent
upon system application) when tested by
Underwriter Laboratories Inc. in accordance
with ASTM E814 (UL1479).
™
FIRESTOP DEVICE
FOR USE IN THROUGH-PENETRATION FIRESTOP SYSTEMS
SEE UL DIRECTORY OF PRODUCTS CERTIFIED FOR CANADA
AND UL FIRE RESISTANCE DIRECTORY
24KP
1. Applications
24 volt, optical, Cat 6,
•
Cables – 750 kcmil, telephone, thermostat
•
Pipes – copper, steel, iron, flexible gas
fiber optic, 300 pair
•
Insulated – AB/PVC, line sets
Blanks – for future use
•
•
Combinations – metallic, non-metallic
Plastic pipes – ccPVC, PVC, ENT,
and insulated pipes plus cables
•
CPVC, FRPP, PVDF, ccABS, ABS,
rigid non-metallic, PEX
2. Physical Properties
Color
Red
Red
Red
Red
2" x 10'' round
6
Nominal Size
2.5" x 2.5" x 10" square 4" x 4" x 10" square 4" x 10'' round
Units per carton
6
6
6
Size
2.5" x 2.5" Square x 10" Long (63.5 x 63.5 mm x 254 mm)
4" x 4" Square x 10" Long (101.6 x 101.6 mm x 254 mm)
2" Round x 10" Long (50.8 mm x 254 mm)
4" Round x 10" Long (101.6 mm x 254 mm)
2.5" Square single mounting bracket
2.5" Square triplex mounting bracket
2.5" Square sixplex mounting bracket
4" Square single mounting bracket
4" Square triplex mounting bracket
4" Square sixplex mounting bracket
2" Round single mounting bracket
4" Round single mounting bracket
2" Round stud bracket
4" Round stud bracket
2.5" Square stud bracket
4" Square stud bracket
Part
No.
98-0400-5513-3
98-0400-5514-1
98-0400-5539-8
98-0400-5515-8
98-0400-5516-6
98-0400-5517-4
98-0400-5544-8
98-0400-5518-2
98-0400-5519-0
98-0400-5543-0
98-0400-5540-6
98-0400-5520-8
98-0400-5541-4
98-0400-5542-2
98-0400-5545-5
98-0400-5546-3
Fire (F) Rating
Up to 3 hour
Up to 3 hour
Up to 3 hour
Up to 3 hour
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
3M Fire Barrier Pass-Through
Device Product
Features
enclosure
•
One-piece, hinged metaland easy
makes installations fast
•
Blank to multiple penetrants tested
identify as
•
Red color – easy to inspection a fire
rated device during
•
Stackable for multiple penetrations
•
Warning
labels part of device
•
Convenient pictorial installation instructions
•
UL classified – meets all code requirements
Logos on both sides
•
3M easy identification of the penetration
for
2
1
/
2
" Square • 4" Square • 2" Round • 4" Round
3. Specifications
Product
Installations shall be in strict accordance with manufacturer’s written instructions, as shown on approved shop
drawings. The device shall also be classified by Underwriter’s Laboratory Inc. as a through-penetration firestop
device when tested in accordance with ASTM E 814 (UL 1479) for up to 3 hour rating.
All penetrations must be firestopped with a UL Classified system or device as listed in current UL Fire
Resistance Directory or have approved shop drawing prior to installation. Suitability for the intended service
application should be determined prior to installation.
4. Performance
A. Testing Procedures
•
Tested per ASTM E 814 (UL 1479)
(T) rating.
•
UL classified 1, 2 and 3 hour fire (F) and temperaturedevices.
See UL Directory under through-penetration firestop
•
UL classified L rating, Hot and Cold Smoke Seal. See UL
Directory under through-penetration firestop devices.
•
ULC
5. Installation Techniques
•
over existing
•
Slide the device eitheropening
penetrants or into the
•
Remove the foam visual/smoke seals and place in a safe location
3M
•
Secure with optionalBarrierFire Barrier Pass-Through Mounting
Brackets, 3M Fire
Pass-Through Stud Brackets and/or
Prepare the opening by cutting correct size hole
™
™
New
3) Secure in wall
with sealant and/or
mounting bracket.
1) Prepare opening.
2) Slide device into wall or floor.
Next, install penetration
and insert foam seal.
Retro Fit
•
•
Re-install the foam visual/smoke seals flush with device ends
6. Re-installing Penetrations
3M
™
Fire Barrier Sealant to the assembly
Install penetrants
1) Insert around penetration(s) optional.
2) Close cover and slide into wall assembly.
3) Secure in wall with sealant and/or
mounting bracket then insert foam seal.
•
Remove the foam visual/smoke seals and place in a safe location
•
Install new penetration
•
Re-install the foam visual/smoke seals flush with device ends
7.
Maintenance
The 3M Fire Barrier Pass-Through Device requires no
maintenance over a normal life cycle.
New
3) Secure in wall
with sealant and/or
mounting bracket.
1) Prepare opening.
2) Slide device into wall or floor.
Next, install penetration
and insert foam seal.
Retro Fit
8. Availability
3M Fire Barrier Pass-Through Devices are available from
Authorized 3M Fire Protection Products Distributors.
3) Secure in wall with sealant and/or
mounting bracket then insert foam seal.
Call 1-800-328-1687 opt. 1
1) Insert around penetration(s) optional.
2) Close cover and slide into wall assembly.
Warranty and Limited Remedy.
This product will be free from defects in material and manufacture for a period of ninety (90) days from date of purchase.
3M MAKES NO OTHER
WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
User is responsible for
determining whether the 3M product is fit for a particular purpose and suitable for user's application. If this 3M product is defective within the warranty period stated above, your exclusive
remedy and 3M's sole obligation shall be, at 3M's option, to replace or repair the 3M product or refund the purchase price of the 3M product.
Limitation of Liability. Except where prohibited by law, 3M will not be liable for any loss or damage arising from this 3M product, whether direct, indirect, special, incidental or
consequential, regardless of the legal theory asserted, including warranty, contract, negligence or strict liability.
Building and Commercial
Services Division
3M Center
Building 223-2N-21
St. Paul, MN 55144-1000
800-328-1687
www.3m.com/firestop
