Data Sheet
1.5 Amp MEGARECTIFIERS
Mechanical Dimensions
JEDEC
D0-15
.104
.140
.230
.300
1.00 Min.
1N5391GP . . . 99GP Series
Description
.031 typ.
Features
n
HIGH TEMPERATURE METALLURGI-
CALLY BONDED CONSTRUCTION
n
SINTERED GLASS CAVITY-FREE
JUNCTION
n
CAPABILITY OF MEETING
ENVIRONMENTAL STANDARDS
OF MIL-S-19500
Electrical Characteristics @ 25
o
C.
Maximum Ratings
Peak Repetitive Reverse Voltage...V
RRM
RMS Reverse Voltage...V
R(rms)
DC Blocking Voltage...V
DC
Average Forward Rectified Current...I
F(av)
Current 3/8" Lead Length @ T
A
= 75°C
Non-Repetitive Peak Forward Surge Current...I
FSM
8.3 mS, ½ Sine Wave Superimposed on Rated Load
Forward Voltage @ 1.5A...V
F
Full Load Reverse Current...I
R(av)
Full Cycle Average @ T
A
= 70°C
DC Reverse Current...I
R
@ Rated DC Blocking Voltage
T
A
= 25°C
T
A
= 150°C
1N5391GP . . . 99GP Series
1N5391 1N5392 1N5393 1N5394 1N5395 1N5396 1N5397 1N5398 1N5399
GP
GP
GP
GP
GP
GP
GP
GP
GP
50
35
50
100
70
100
200
140
200
300
210
300
400
280
400
500
350
500
600
420
600
800
560
800
1000
700
1000
Units
Volts
Volts
Volts
Amps
Amps
Volts
µAmps
............................................. 1.5 ...............................................
............................................. 5 0 ...............................................
............................................. 1.4 ...............................................
............................................. 3 0 0 ...............................................
............................................. 5 ...............................................
............................................. 3 0 0 ...............................................
............................................. 1 5 ...............................................
............................................. 4 5 ...............................................
.........................................
2.0
..........................................
......................................... -65 to 175 ..........................................
µAmps
µAmps
pF
°C
/ W
µS
°C
Typical Junction Capacitance...C
J
(Note 1)
Typical Thermal Resistance...R
θJA
(Note 2)
Typical Reverse Recovery Time...t
RR
(Note 3)
Operating & Storage Temperature Range...T
J
, T
STRG
Page 6-8
Data Sheet
1.5 Amp MEGARECTIFIERS
Forward Current Derating Curve
T
A
= Ambient Temperature (°C)
°
Non-Repetitive
Peak Forward Surge Current
T
J
= T
J
max.
8.3 mS Single Half Sine Wave
(Jedec Method)
Typical Junction Capacitance
T
J
= 25°C
°
f = 1.0 MHZ
V
SIG
= 50mVp-p
Amps
Number of Cycles @ 60 HZ
Typical Instantaneous Forward Characteristics
pF
Reverse Voltage (Volts)
Typical Reverse Characteristics
T
J
= 125°C
°
Amps
µ
Amps
°
T
J
= 25°C
Pulse Width = 300µS
µ
1% Duty Cycle
°
T
JJ
= 25°C
T = 75°C
°
Ratings at
25 Deg. C ambient
temperature
unless otherwise
specified.
Single Phase Half
Wave, 60 HZ
Resistive or
Inductive Load.
For Capacitive
Load, Derate
Current by 20%.
T
J
= 25°C
°
Volts
Percent of Rated Peak Voltage
NOTES:
1. Measured @ 1 MHZ and applied reverse voltage of 4.0V.
2. Thermal Resistance from Junction to Ambient at 3/8" Lead Length, P.C. Board Mounted.
3. Reverse Recovery Condition I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A.
Page 6-9
1N5391GP . . . 99GP Series
Amps
Embedded System
