RGC Series
Semi-Precision Thick Film Chip Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Features:
•
•
•
•
•
•
Precision performance
RoHS compliant and halogen free
Highly stable performance over time
Tolerances of 0.1% may be available - contact factory for details
Temperature coefficient of resistance as low as ±50ppm/ºC
0402 and 0603 package sizes are qualified to AEC-Q200
Electrical Specifications
Type / Code
Power Rating
(Watts) @ 70ºC
0.05W
Maximum
Working
Voltage
(1)
25V
Maximum
Overload
Voltage
50V
Ohmic Range (Ω) and Tolerance
TCR (ppm/ºC)
0.1%
± 200 ppm/ºC
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
RGC0603
0.1W
75V
150V
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
RGC1206
0.25W
0.25W
RGC1210
0.33W
200V
200V
200V
400V
400V
400V
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
± 100 ppm/ºC
± 50 ppm/ºC
± 100 ppm/ºC
± 200 ppm/ºC
-
-
-
-
10 - 1M
10 - 1M
-
10 - 1M
10 - 1M
-
10 - 1M
10 - 1M
-
-
10 - 1M
10 - 1M
-
10 - 1M
10 - 1M
-
-
10 - 1M
10 - 1M
-
1.02M - 10M
1.02M - 10M
-
10 - 10M
10 - 10M
-
1.02M - 10M
10 - 10M
1 - 10M
-
1 - 9.76
1.02M - 10M
-
10 - 10M
10 - 10M
-
1.02M - 10M
10 - 10M
1 - 10M
1 - 9.76
1.02M - 10M
10 - 10M
1 - 10M
0.5%
10 - 10M
100 - 1M
10 - 1M
1.02M - 10M
10 - 10M
1 - 10M
-
1 - 1M
-
1%
-
RGC0201
RGC0402
0.063W
50V
100V
RGC0805
0.125W
150V
300V
RGC2010
0.75W
200V
200V
400V
400V
500V
RGC2512
1W
250V
Note: (1) Lesser of √P*R or maximum working voltage
Power Derating Curve
100
-55ºC
70ºC
Percent Rated Power (%)
80
60
0402 - 2512
40
20
0
-60
0201
125ºC
155ºC
0
20
40
60
80
100
120
140
160
180
Ambient Temperature (ºC)
Rev Date: 02/08/2018
This specification may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
1
www.seielect.com
marketing@seielect.com
RGC Series
Semi-Precision Thick Film Chip Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Mechanical Specifications
Type / Code
RGC0201
RGC0402
RGC0603
RGC0805
RGC1206
RGC1210
RGC2010
RGC2512
Weight (g)
(1000 pc.)
0.150
0.620
2.042
4.368
8.947
15.959
24.241
39.448
L
Body Length
0.024 ± 0.001
0.60 ± 0.03
0.039 ± 0.004
1.00 ± 0.10
0.063 ± 0.004
1.60 ± 0.10
0.079 ± 0.004
2.00 ± 0.10
0.122 ± 0.006
3.10 ± 0.15
0.126 ± 0.010
3.20 ± 0.25
0.197 ± 0.008
5.00 ± 0.20
0.250 ± 0.008
6.35 ± 0.20
W
Body Width
0.012 ± 0.001
0.30 ± 0.03
0.020 ± 0.002
0.50 ± 0.05
0.031 ± 0.004
0.80 ± 0.10
0.049 ± 0.004
1.25 ± 0.10
0.061 ± 0.004
1.55 ± 0.10
0.102 ± 0.006
2.60 ± 0.15
0.098 ± 0.006
2.50 ± 0.15
0.124 ± 0.008
3.15 ± 0.20
H
Body Height
0.009 ± 0.001
0.23 ± 0.03
0.012 ± 0.004
0.30 ± 0.10
0.018 ± 0.004
0.45 ± 0.10
0.020 ± 0.004
0.50 ± 0.10
0.024 ± 0.006
0.60 ± 0.15
0.022 ± 0.004
0.55 ± 0.10
0.022 ± 0.004
0.55 ± 0.10
0.022 ± 0.004
0.55 ± 0.10
a
Top Termination
0.006 ± 0.002
0.15 ± 0.05
0.008 ± 0.004
0.20 ± 0.10
0.012 ± 0.008
0.30 ± 0.20
0.016 ± 0.010
0.40 ± 0.25
0.020 ± 0.010
0.50 ± 0.25
0.020 ± 0.010
0.50 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
0.024 ± 0.010
0.60 ± 0.25
b
Bottom Termination
0.006 ± 0.002
0.15 ± 0.05
0.010 ± 0.006
0.25 ± 0.15
0.012 ± 0.008
0.30 ± 0.20
0.016 ± 0.008
0.40 ± 0.20
0.020 ± 0.012
0.50 ± 0.30
0.020 ± 0.008
0.50 ± 0.20
0.024 ± 0.012
0.60 ± 0.30
0.024 ± 0.012
0.60 ± 0.30
Unit
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
Recommended Pad Layout
Type/Code
RGC0201
RGC0402
RGC0603
RGC0805
RGC1206
RGC1210
RGC2010
RGC2512
A
0.012
0.30
0.020
0.50
0.035
0.90
0.047
1.20
0.079
2.00
0.079
2.00
0.150
3.80
0.193
4.90
B
0.010
0.25
0.018
0.45
0.024
0.60
0.028
0.70
0.035
0.90
0.035
0.90
0.035
0.90
0.063
1.60
C
0.012
0.30
0.024
0.60
0.035
0.90
0.051
1.30
0.063
1.60
0.110
2.80
0.110
2.80
0.138
3.50
Unit
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
Rev Date: 02/08/2018
This specification may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
2
www.seielect.com
marketing@seielect.com
RGC Series
Semi-Precision Thick Film Chip Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Soldering Profiles
(1) Time of IR reflow soldering at maximum temperature point 260ºC : 10s
(2) Time of wave soldering at maximum temperature point 260ºC : 10s
(3) Time of soldering iron at maximum temperature point 410ºC : 5s
Packaging Specifications
Type/Code
RGC0201
RGC0402
RGC0603
RGC0805
RGC1206
RGC1210
RGC2010
RGC2512
Packaging
Description
Tape
Width
Reel
Diameter
A
B
C
W
T
Unit
Paper
8mm
7 inches
7.028 ± 0.059
178.50 ± 1.50
2.362 ± 0.039
60.00 + 1.00
0.512 ± 0.008
13.00 ± 0.20
0.354 ± 0.020
9.00 ± 0.50
0.492 ± 0.020
12.50 ± 0.50
inches
mm
Embossed
12mm
7 inches
7.028 ± 0.059
178.50 ± 1.50
2.362 ± 0.039
60.00 + 1.00
0.512 ± 0.020
13.00 ± 0.50
0.512 ± 0.020
13.00 ± 0.50
0.610 ± 0.020
15.50 ± 0.50
inches
mm
Rev Date: 02/08/2018
This specification may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
3
www.seielect.com
marketing@seielect.com
RGC Series
Semi-Precision Thick Film Chip Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Paper Tape Specifications
Type/Code
RGC0201
RGC0402
RGC0603
RGC0805
RGC1206
RGC2010
Type/Code
RGC0201
RGC0402
RGC0603
RGC0805
RGC1206
RGC2010
0.157
4.00
0.157
4.00
0.157
4.00
0.157
4.00
0.157
4.00
0.157
4.00
0.015
0.38
0.026
0.65
0.043
1.10
0.063
1.60
0.075
1.90
0.114
2.90
A
± 0.002
± 0.05
± 0.004
± 0.10
± 0.004
± 0.10
± 0.004
± 0.10
± 0.004
± 0.10
± 0.004
± 0.10
P0
±
±
±
±
±
±
±
±
±
±
±
±
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
B
0.027 ± 0.002
0.68 ± 0.05
0.045 ± 0.004
1.15 ± 0.10
0.075 ± 0.004
1.90 ± 0.10
0.094 ± 0.008
2.40 ± 0.20
0.138 ± 0.008
3.50 ± 0.20
0.138 ± 0.008
3.50 ± 0.20
P1
0.079
2.00
0.079
2.00
0.157
4.00
0.157
4.00
0.157
4.00
0.157
4.00
±
±
±
±
±
±
±
±
±
±
±
±
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
W
0.315 ± 0.008
8.00 ± 0.20
0.315 ± 0.008
8.00 ± 0.20
0.315 ± 0.008
8.00 ± 0.20
0.315 ± 0.008
8.00 ± 0.20
0.315 ± 0.008
8.00 ± 0.20
0.315 ± 0.008
8.00 ± 0.20
P2
0.079
2.00
0.079
2.00
0.079
2.00
0.079
2.00
0.079
2.00
0.079
2.00
±
±
±
±
±
±
±
±
±
±
±
±
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
E
0.069 ±
1.75 ±
0.069 ±
1.75 ±
0.069 ±
1.75 ±
0.069 ±
1.75 ±
0.069 ±
1.75 ±
0.069 ±
1.75 ±
D0
0.059
1.50
0.059
1.50
0.059
1.50
0.059
1.50
0.059
1.50
0.059
1.50
±
±
±
±
±
±
±
±
±
±
±
±
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.138
3.50
0.138
3.50
0.138
3.50
0.138
3.50
0.138
3.50
0.138
3.50
0.017
0.42
0.018
0.45
0.028
0.70
0.033
0.85
0.033
0.85
0.033
0.85
F
±
±
±
±
±
±
±
±
±
±
±
±
T
±
±
±
±
±
±
±
±
±
±
±
±
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.002
0.05
0.008
0.20
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
0.004
0.10
Unit
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
Unit
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
inches
mm
Embossed Tape Specifications
Type/Code
RGC2010
RGC2512
Type/Code
RGC2010
RGC2512
A
0.110 ± 0.004
2.80 ± 0.10
0.138 ± 0.004
3.50 ± 0.10
P0
0.157 ± 0.004
4.00 ± 0.10
0.157 ± 0.004
4.00 ± 0.10
B
0.217 ± 0.004
5.50 ± 0.10
0.264 ± 0.004
6.70 ± 0.10
P1
0.157 ± 0.004
4.00 ± 0.10
0.157 ± 0.004
4.00 ± 0.10
W
0.472 ± 0.012
12.00 ± 0.30
0.472 ± 0.012
12.00 ± 0.30
P2
0.079 ± 0.002
2.00 ± 0.05
0.079 ± 0.002
2.00 ± 0.05
E
0.069 ± 0.004
1.75 ± 0.10
0.069 ± 0.004
1.75 ± 0.10
D0
0.059 ± 0.004
1.50 ± 0.10
0.059 ± 0.004
1.50 ± 0.10
0.217
5.50
0.217
5.50
0.047
1.20
0.047
1.20
F
±
±
±
±
T
±
±
±
±
0.002
0.05
0.002
0.05
0.000
0.00
0.000
0.00
Unit
inches
mm
inches
mm
Unit
inches
mm
inches
mm
Rev Date: 02/08/2018
This specification may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
4
www.seielect.com
marketing@seielect.com
RGC Series
Semi-Precision Thick Film Chip Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Performance Characteristics
Test
Temperature Coefficient of
Resistance
± 1% and below
Test Specification
± 5%
Jumper
Test Method
JIS-C-5201-1 4.8
As specified.
IEC-60115-1 4.8
-55ºC +125 C, 25ºC is the reference temperature
JIS-C-5201-1 4.13
IEC-60115-1 4.13
Short Time Overload
±(1.0%+0.05Ω)
±(2.0%+0.05Ω)
<50mΩ
RCWV*2.5 or max. overload voltage whichever is
lower for 5 seconds;
2 seconds for high power series
JIS-C-5201-1 4.6
≥10G
Insulation resistance
IEC-60115-1 4.6
Max. overload voltage for 1 minute
JIS-C-5201-1 4.25
IEC-60115-1 4.25.1
Endurance
±(1.0%+0.10Ω)
±(2.0%+0.10Ω)
<100mΩ
70±2ºC, RCWV for 1000 h. with 1.5 h.
"ON" and 0.5 h. "OFF"
JIS-C-5201-1 4.24
IEC-60115-1 4.24
<100mΩ
Damp Heat with Load
±(1.0%+0.10Ω)
±(2.0%+0.10Ω)
40±2ºC, 90~95% R.H., RCWV for 1000 h.
with 1.5 h. "ON" and 0.5 h. "OFF"
JIS-C-5201-1 4.23
Dry Heat
±(1.0%+0.05Ω)
±(1.5%+0.10Ω)
<50mΩ
IEC-60115-1 4.23.2
at +125/+155ºC for 1000 h.
JIS-C-5201-1 4.33
IEC-60115-1 4.33
Bending Strength
±(1.0%+0.05Ω)
±(1.0%+0.05Ω)
<50mΩ
Bending once for 5 seconds
2010, 2512 sizes: 2mm; other sizes: 3mm
JIS-C-5201-1 4.17
Solderability
95% minimum coverage
IEC-60115-1 4.17
245±5ºC for 3 seconds
JIS-C-5201-1 4.18
Resistance to Soldering Heat
±(0.5%+0.05Ω)
±(1.0%+0.05Ω)
<50mΩ
IEC-60115-1 4.18
260±5ºC for 10 seconds
JIS-C-5201-1 4.7
Voltage Proof
No breakdown or flashover
IEC-60115-1 4.7
1.42 times max. operating voltage for 1 minute
Individual leaching area
≤5%
JIS-C-5201-1 4.18
Leaching
Total leaching area
≤10%
IEC-60068-2-58 8.2.1
260±5ºC for 30 seconds
JIS-C-5201-1 4.19
Rapid Change of Temperature ±(0.5%+0.05Ω)
<50mΩ
±(1.0%+0.05Ω)
IEC-60115-1 4.19
-55ºC to +125/+155ºC, 5 cycles
RCWV (Rated Continuous Working Voltage) =
√(P*R)
or max. operating voltage whichever is lower
Storage Temperature: 25±3ºC; humidity < 80% RH
Rev Date: 02/08/2018
This specification may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
5
www.seielect.com
marketing@seielect.com
京公网安备 11010802033920号
EEWORLD
