1N4728CG ~ 1N4764CG
V
Z
:
3.3 to 100V
P
D
:
1.0 Watt
FEATURES :
• Silicon planar power zener diodes.
• For use in stabilizing and clipping circuits with high
power rating.
• Standard zener voltage tolerance is
±
2%
• Other tolerances are available upon request.
• Pb / RoHS Free
ZENER DIODES
DO-41 Glass
(DO-204AL)
0.102(2.6 )max.
1.00 (25.4)
min.
Cathode
Mark
0.161 (4.1)
max.
0.034 (0.86)max.
1.00 (25.4)
min.
MECHANICAL DATA :
Case:
DO-41 Glass Case
Weight:
approx. 0.35g
Dimensions in inches and ( millimeters )
Rating at 25
°
C ambient temperature unless otherwise specified.
Maximum Ratings and Thermal Characteristics
Parameter
Zener Current see Table "Characteristics"
Maximum Forward Voltage at I
F
= 200 mA.
Power Dissipation
Thermal Resistance Junction to Ambient Air
Junction temperature
Storage temperature range
V
F
P
D
R
θ
JA
T
J
T
S
1.2
1.0
(1)
100
(1)
Symbol
Value
Unit
V
W
K/W
°C
°C
175
-55 to + 175
Note:
(1) Valid provided that leads at a distance of 3/8” from case are kept at ambient temperature.
Page 1 of 2
Rev. 03 : March 25, 2005
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Nominal Zener
Type No.
Voltage
(3)
V
Z
@ I
ZT
I
ZT
(V)
(mA)
Maximum Zener Impedance
Z
ZT
@ I
ZT
(Ω)
Z
ZK
@ I
ZK
(Ω)
(1)
Maximum Reverse
Leakage Current
I
R
@ V
R
(
µ
A)
(V)
Maximum
Regulator Current
I
ZM
(2)
Maximum
Surge Current
I
RM
(mA)
I
ZK
(mA)
(mA)
1N4728CG
3.3
76.0
10
400
1.0
100
1.0
276
1380
1N4729CG
3.6
69.0
10
400
1.0
100
1.0
252
1260
1N4730CG
3.9
64.0
9.0
400
1.0
50
1.0
234
1190
1N4731CG
4.3
58.0
9.0
400
1.0
10
1.0
217
1070
1N4732CG
4.7
53.0
8.0
500
1.0
10
1.0
193
970
1N4733CG
5.1
49.0
7.0
550
1.0
10
1.0
178
890
1N4734CG
5.6
45.0
5.0
600
1.0
10
2.0
162
810
1N4735CG
6.2
41.0
2.0
700
1.0
10
3.0
146
730
1N4736CG
6.8
37.0
3.5
700
1.0
10
4.0
133
660
1N4737CG
7.5
34.0
4.0
700
0.5
10
5.0
121
605
1N4738CG
8.2
31.0
4.5
700
0.5
10
6.0
110
550
1N4739CG
9.1
28.0
5.0
700
0.5
10
7.0
100
500
1N4740CG
10
25.0
7.0
700
0.25
10
7.6
91
454
1N4741CG
11
23.0
8.0
700
0.25
5.0
8.4
83
414
1N4742CG
12
21.0
9.0
700
0.25
5.0
9.1
76
380
1N4743CG
13
19.0
10
700
0.25
5.0
9.9
69
344
1N4744CG
15
17.0
14
700
0.25
5.0
11.4
61
305
1N4745CG
16
15.5
16
700
0.25
5.0
12.2
57
285
1N4746CG
18
14.0
20
750
0.25
5.0
13.7
50
250
1N4747CG
20
12.5
22
750
0.25
5.0
15.2
45
225
1N4748CG
22
11.5
23
750
0.25
5.0
16.7
41
205
1N4749CG
24
10.5
25
750
0.25
5.0
18.2
38
190
1N4750CG
27
9.5
35
750
0.25
5.0
20.6
34
170
1N4751CG
30
8.5
40
1000
0.25
5.0
22.8
30
150
1N4752CG
33
7.5
45
1000
0.25
5.0
25.1
27
135
1N4753CG
36
7.0
50
1000
0.25
5.0
27.4
25
125
1N4754CG
39
6.5
60
1000
0.25
5.0
29.7
23
115
1N4755CG
43
6.0
70
1500
0.25
5.0
32.7
22
110
1N4756CG
47
5.5
80
1500
0.25
5.0
35.8
19
95
1N4757CG
51
5.0
95
1500
0.25
5.0
38.8
18
90
1N4758CG
56
4.5
110
2000
0.25
5.0
42.6
16
80
1N4759CG
62
4.0
125
2000
0.25
5.0
47.1
14
70
1N4760CG
68
3.7
150
2000
0.25
5.0
51.7
13
65
1N4761CG
75
3.3
175
2000
0.25
5.0
56.0
12
60
1N4762CG
82
3.0
200
3000
0.25
5.0
62.2
11
55
1N4763CG
91
2.8
250
3000
0.25
5.0
69.2
10
50
1N4764CG
100
2.5
350
3000
0.25
5.0
76.0
9.0
45
Notes:
(1) The Zener impedance is derived from the 1kHZ AC voltage which results when an AC current having an RMS value equal
to 10% of the Zener current (I
ZT
or I
ZK
) is superimposed on I
ZT
or I
ZK
. Zener impedance is measured at two points to
insure a sharp knee on the breakdown curve and to eliminate unstable units
(2) Valid provided that electrodes at a distance of 10mm from case are kept at ambient temperature
(3) Measured under thermal equilibrium and DC test conditions.
(4) Suffix "C" for
±
2% tolerance. Add suffix “A” for
±
5% tolerance. Other Zener voltages
and tolerances are available upon request.
Page 2 of 2
Rev. 03 : March 25, 2005
