SPECIFICATION
Product Type :
EPD
Model Number : GDEW0213Z16
Description
:
Screen Size:
2.13"
Color: Black, White
and Red
Display Resolution:
212*104
:
:
:
:
Li Lanxi
Wen Xin
Jian Yongcheng
2017.02.27
Prepared
Checked
Approved
Issue Date
DALIAN GOOD DISPLAY CO., LTD.
No.17 Gonghua Street, Shahekou District, Dalian 116021 China
Tel: +86-411-84619565 Fax: +86-411-84619585-810
Email: info@good-display.com
Website: www.good-display.com
GDEW0213Z16
Revision History
Rev.
1.0
1.1
1.2
1.3
Issued Date
Jun.01.2015
Jun.09.2015
Jun.17.2015
Jul.21.2015
Preliminary
Revised Contents
1. In part 4: Modify the mechanical drawing of EPD module.
1. In part 7-2): Modify Image update Time at 25℃ from 8~12S to 12~15S.
1. In part 4: Modify the Mechanical Drawing of EPD module.
1. In part 9-1): Add the panel’s storage and transportation conditions.
2. In part 9-1): Add the panel’s operation conditions.
3. In part note 9-2: Modify each update interval time should be minimum at 150
seconds to 180 seconds.
4. In part 12: Delete block diagram.
1. In part 8: Modify typical operating sequence.
1. Modify
Part Number.
1. In part 11: Modify T=40℃, RH=80% for 168 hrs to 240 hrs.
1. In part
7-5: Modify
Reference Circuit.
1.4
Jul.23.2015
1.5
1.6
1.7
2.0
Aug.24.2015
Sep.18.2015
Nov.07.2015
Feb.27.2017
www.good-display.com
2／44
GDEW0213Z16
TECHNICAL SPECIFICATION
CONTENTS
NO.
-
-
-
1
2
3
4
5
6
7
8
9
10
11
12
13
ITEM
Cover
Revision History
Contents
Application
Features
Mechanical Specifications
Mechanical Drawing of EPD module
Input/Output Terminals
Command Table
Electrical Characteristics
Typical Operating Sequence
Optical Characteristics
Handling, Safety and Environment Requirements
Reliability test
Point and line standard
Packing
PAGE
1
2
3
4
4
4
5
6
8
26
34
38
40
41
43
44
www.good-display.com
3／44
GDEW0213Z16
1. Over View
The display is a TFT active matrix electrophoretic display, with interface and a reference system design. The 2.13” active area
contains 212×104 pixels, and has 1-bit white/black and 1-bit red full display capabilities. An integrated circuit contains gate
buffer, source buffer, interface, timing control logic, oscillator, DC-DC, SRAM, LUT, VCOM, and border are supplied with
each panel.
2. Features
High contrast
High reflectance
Ultra wide viewing angle
Ultra low power consumption
Pure reflective mode
Bi-stable
Commercial temperature range
Landscape, portrait mode
Antiglare hard-coated front-surface
Low current deep sleep mode
On chip display RAM
Waveform stored in On-chip OTP
Serial peripheral interface available
On-chip oscillator
On-chip booster and regulator control for generating VCOM, Gate and source driving voltage
I
2
C Signal Master Interface to read external temperature sensor
Available in COG package IC thickness 280um
3. Mechanical Specifications
Parameter
Screen Size
Display Resolution
Active Area
Pixel Pitch
Pixel Configuration
Outline Dimension
Weight
Specifications
2.13
212(H)×104(V)
48.55(H)×23.71(V)
0.229×0.228
Square
59.2(H)×29.2 (V) ×0.98(D)
4±0.5
mm
g
Unit
Inch
Pixel
mm
mm
Dpi: 111
Remark
www.good-display.com
4／44
1.2
0.6
0.9
1.2
0.9
0.644
29.2±0.2<EPD>
26.8±0.2<PS>
25±0.2<FPL>
23.71±0.1<AA>
0.228
4. Mechanical Drawing of EPD module
www.good-display.com
0.229
0.98±0.10
0.50±0.10
3.00
6.00±0.20
7.80±0.20
? 2.00
3.91±0.20
3.91±0.20
2.50
48.55±0.2<AA>
53.7±0.2<FPL>
55.5±0.2<PS>
59.2±0.2<EPD>
3.65±0.3
1.00±0.10
24
0.45±0.05
0.35±0.05
0.5±0.05
1
15.51±0.10
12.50±0.1
0.15
14.11±0.10
0.13±0.03
1.40±0.10
6.75
+0.10
-0.00
开窗区域
6.00±0.30
10.30±0.10
10.30±0.10
9.40±0.10
3.90±0.30
1.5max
12.50±0.10
1,Unlabeled tolerances:±0.15
2,Resolution:104*212
3,DPI: 111
14.30±0.20
1
24
0.30±0.03
½色丝印
8.56±0.20
(rtv area)
(ec area)
(without protective film)
GDEW0213Z16
GDEW0213Z16
5／44
