SLEEVE SPRING
TIP SPRING
RING SPRING
1.02
0.26
0.12
0.93
0.05 X 0.09
SLOT TYP
1.22
0.945
0.25
0.25
0.89
0.09
0.748
0.138 HOLE COUNTERSUNK
FOR #4 FLAT HEAD SCREW
NOTES:
1. MATES WITH SWITCHCRAFT P/N 267 PLUG
2. MOUNTING HOLE:
0.938
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
- THREE PLACE DECIMALS
0.02
0.005
SIZE
FINISH
SPEC No.
FIRST USED ON
DATE DRAWN
CUSTOMER DRAWING
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
3. MATERIALS:
HOUSING ZINC ALLOY, SATIN NICKEL PLATED
PLUG HOUSING - THERMOPLASTIC, BLACK
INTERNAL LATCH - THERMOPLASTIC, RED
LATCH RELEASE - ZINC ALLOY, NICKEL PLATED
TERMINALS / SPRINGS - NICKEL SILVER, ELECTRO-TIN PLATED
TORSION & RETURN SPRINGS - MUSIC WIRE, TINNED
4. THIS PRODUCT IS RoHS COMPLIANT.
B
REV
*
WIDTH
*
*
*
MULT
*
LBS/M
MATERIAL
SPEC No.
*
TEMPER
*
*
*
*
SCALE
2:1
BY
18079
ECO NUMBER
2/13/12
DATE
TJK
BY
TJK
APVD
2/13/12
TJK
TJK
2/13/12
CHKD
TJK
2/13/12
PART No.
APVD
SHEET
1
OF
1
REV
REVISIONS
DO NOT SCALE DRAWING
"E" SERIES - 0.25
3 CONDUCTOR LOCKING JACK, RoHS
NAME
E112BL
B
SolidWorks CAD File
B
