F98 Series
Resin-Molded Chip, High CV Undertab
FEATURES
• Compliant to the RoHS2 directive 2011/65/EU
• SMD face down design
• Small and low profile
APPLICATIONS
•
•
•
•
Smartphone
Mobile phone
Wireless module
Hearing aid
LEAD-FREE COMPATI-
BLE
COMPONENT
CASE DIMENSIONS:
millimeters (inches)
Code EIA Code EIA Metric
M
S
U
0603
0805
0402
1608-09
2012-09
1106-06
1.60
(0.063
2.00
(0.079
L
+0.20
-0.10
+0.008
-0.004
+0.20
-0.10
+0.008
-0.004
W
1
)
)
0.85
(0.033
1.25
(0.049
+0.20
-0.10
+0.008
-0.004
+0.20
-0.10
+0.008
-0.004
W
2
)
)
0.65±0.10
(0.026±0.004)
0.90±0.10
(0.035±0.004)
0.35±0.05
(0.014±0.002)
H
0.80±0.10*
3
(0.031±0.004)
0.80±0.10
(0.031±0.004)
0.55±0.05
(0.022±0.002)
S
1
0.50±0.10
(0.020±0.004)
0.50±0.10
(0.020±0.004)
0.30±0.05
(0.012±0.002)
S
2
0.60±0.10
(0.024±0.004)
1.00±0.10
(0.039±0.004)
0.50±0.05
(0.020±0.002)
1.10±0.05
(0.043±0.002)
0.60±0.05
(0.024±0.002)
*
3
F980J107MMAAXE: 1.0mm Max.
L
W
1
H
MARKING
U CASE
M CASE
S CASE
*Capacitance
Code
W
2
J
Js
S
1
S
2
S
1
Rated Voltage
Code
Rated Voltage
Code
HOW TO ORDER
F98
0J
Type
Rated
Voltage
106
M
Tolerance
M = ±20%
M
Case
Size
See
table
above
Packaging
See Tape & Reel
Packaging Section
Specification Suffix
LZT = Rated temperature 60ºC only
AXE = Rated temperature 60ºC and
H dimension 1.0mm Max
Capacitance
Code
pF code: 1st two digits
represent significant figures,
3rd digit represents multiplier
(number of zeros to follow)
TECHNICAL SPECIFICATIONS
Category Temperature Range:
Rated Temperature:
Capacitance Tolerance:
Dissipation Factor:
ESR 100kHz:
Leakage Current:
-55 to +125°C
+85°C
±20% at 120Hz
Refer to next page
Refer to next page
Refer to next page
Provided that:
After 5 minute’s application of rated voltage, leakage current at 85°C
10 times or less than 20ºC specified value.
After 5 minute’s application of rated voltage, leakage current at 125°C
12.5 times or less than 20ºC specified value.
58
062718
F98 Series
Resin-Molded Chip, High CV Undertab
CAPACITANCE AND RATED VOLTAGE RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
µF
Code
0.47
474
1.0
105
2.2
225
4.7
475
10
106
15
156
22
226
33
336
47
476
68
686
100
107
220
227
2.5 (0e)
4V (0G)
6.3V (0J)
Rated Voltage
10V (1A)
16V (1C)
U
M
M/U
M
M/U**
M
M
S
M**/S
M**/S
S
20V (1D)
M
25V (1E)
M
35V (1V)
S
*Cap
Code
N
A
J
S
a
e
J
n
s
w
A
J
M
U
U
U
M/U**
M
M
M/S
M/S
S
M/U
M/U**
M
M
M/S
M*
4
/S
Released ratings
*
4
Rated temperature 60°C and H dimension 1.0mm Max only. Please contact AVX
when you need detail spec.
**Rated temperature 60ºC only. Please contact AVX when you need detail spec.
We can consider the type of compliance to AEC-Q200.
Please contact to your local AVX sales office when these series
are being designed in your application.
RATINGS & PART NUMBER REFERENCE
AVX
Part No.
Case Capacitance
Size
(μF)
Rated
Voltage
(V)
*2
DCL
(μA)
DF
ESR
@ 120Hz @ 100kHz
(%)
(Ω)
*1
ΔC/C
(%)
MSL
AVX
Part No.
Case Capacitance
Size
(μF)
Rated
Voltage
(V)
*2
DCL
(μA)
DF
ESR
@ 120Hz @ 100kHz
(%)
(Ω)
*1
ΔC/C
(%)
MSL
F980E476MMA
F980G475MUA
F980G106MUA
F980G156MUA
F980G226MMA
F980G226MUALZT
F980G336MMA
F980G476MMA
F980G686MMA
F980G686MSA
F980G107MMA
F980G107MSA
F980G227MSA
F980J475MMA
F980J475MUA
F980J106MMA
F980J106MUALZT
F980J226MMA
F980J336MMA
F980J476MMA
F980J476MSA
F980J107MMAAXE
F980J107MSA
M
U
U
U
M
U
M
M
M
S
M
S
S
M
U
M
U
M
M
M
S
M
S
47
4.7
10
15
22
22
33
47
68
68
100
100
220
4.7
4.7
10
10
22
33
47
47
100
100
2.5 Volt
2.5
4 Volt
4
4
4
4
4
4
4
4
4
4
4
4
6.3 Volt
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
1.2
0.5
0.8
9.0
0.9
25.0
1.3
1.9
27.2
2.7
80.0
4.0
132
0.5
0.6
0.6
6.3
1.4
4.2
29.6
3.0
126
63.0
30
20
25
40
15
40
30
40
50
30
60
35
80
20
20
8
30
20
35
45
25
80
50
4
20
20
25
7.5
20
4
8
10
4
10
4
5
7.5
20
6
30
6
8
10
6
10
8
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
F981A225MMA
F981A225MUA
F981A475MMA
F981A475MUALZT
F981A106MMA
F981A226MMALZT
F981A226MSA
F981A336MMALZT
F981A336MSA
F981A476MSA
F981C474MUA
F981C105MMA
F981C225MMA
F981C475MMA
F981C106MSA
F981D105MMA
F981E105MMA
F981V105MSA
M
U
M
U
M
M
S
M
S
S
U
M
M
M
S
M
M
S
2.2
2.2
4.7
4.7
10
22
22
33
33
47
0.47
1
2.2
4.7
10
1
1
1
10 Volt
10
10
10
10
10
10
10
10
10
10
16 Volt
16
16
16
16
16
20 Volt
20
25 Volt
25
35 Volt
35
0.5
0.5
0.5
4.7
1.0
11.0
2.2
33.0
3.3
9.4
0.5
0.5
0.5
0.8
1.6
0.5
0.5
0.7
6
15
6
25
20
30
20
45
30
35
6
6
6
12
18
6
8
20
7.5
15
6
25
7.5
8
4
8
6
5
25
10
10
12
4
10
10
8
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±20
±30
±30
±30
±30
±30
±30
±30
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
Moisture Sensitivity Level (MSL) is defined according to J-STD-020.
*2: Leakage Current
After 5 minute’s application of rated voltage,
leakage current at 20ºC.
062718
59
F98 Series
Resin-Molded Chip, High CV Undertab
QUALIFICATION TABLE
TEST
Damp Heat
(Steady State)
F98 series (Temperature range -55ºC to +125ºC)
Condition
At 40°C, 90 to 95% R.H., 500 hours (No voltage applied)
Capacitance Change ........... Refer to page 59 (*1)
Dissipation Factor ................ 150% or less of initial specified value
Leakage Current .................. 200% or less of initial specified value
-55°C / +125°C, 30 minutes each, 5 cycles
Capacitance Change ........... Refer to page 59 (*1)
Dissipation Factor ................ 150% or less of initial specified value
Leakage Current .................. 200% or less of initial specified value
10 seconds reflow at 260°C, 5 seconds immersion at 260°C.
Capacitance Change ........... Refer to page 59 (*1)
Dissipation Factor ................ Initial specified value or less
Leakage Current .................. Initial specified value or less
After application of surge in series with a 1kΩ resistor at the rate of 30 seconds ON, 30 seconds OFF,
for 1000 successive test cycles at 85ºC, capacitors shall meet the characteristic requirements in the table above.
Capacitance Change ........... Refer to page 59 (*1)
Dissipation Factor ................ 150% or less of initial specified value
Leakage Current .................. 200% or less of initial specified value
After 1000 hours’ application of rated voltage in series with a 3Ω resistor at 85°C,
capacitors shall meet the characteristic requirements in the table above.
Capacitance Change ........... Refer to page 59 (*1)
Dissipation Factor ................ 150% or less of initial specified value
Leakage Current .................. 200% or less of initial specified value
After applying the pressure load of 5N for 10±1 seconds horizontally to the center of capacitor side body
which has no electrode and has been soldered beforehand on a substrate, there shall be found neither
exfoliation nor its sign at the terminal electrode.
Keeping a capacitor surface-mounted on a substrate upside down and supporting the substrate at
both of the opposite bottom points 45mm apart from the center of capacitor, the pressure strength is
applied with a specified jig at the center of substrate so that the substrate may bend by 1mm as
illustrated. Then, there shall be found no remarkable abnormality on the capacitor terminals.
Temperature Cycles
Resistance to
Soldering Heat
Surge
Endurance
Shear Test
Terminal Strength
60
062718
