3SK294(TE85L,F)

Description
FET RF 12.5V 500MHZ USQ
CategoryDiscrete semiconductor    The transistor
File Size285KB,5 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Environmental Compliance
Download Datasheet Parametric View All

3SK294(TE85L,F) Overview

FET RF 12.5V 500MHZ USQ

3SK294(TE85L,F) Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Reach Compliance Codeunknown
Base Number Matches1
3SK294
TOSHIBA Field Effect Transistor
Silicon N-Channel Dual Gate MOS Type
3SK294
TV Tuner, VHF RF Amplifier Application
Superior cross modulation performance
Low reverse transfer capacitance: C
rss
= 20 fF (typ.)
Low noise figure: NF = 1.4dB (typ.)
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Drain-source voltage
Gate 1-source voltage
Gate 2-source voltage
Drain current
Drain power dissipation
Channel temperature
Storage temperature range
Symbol
V
DS
V
G1S
V
G2S
I
D
P
D
T
ch
T
stg
Rating
12.5
±8
±8
30
100
125
−55
to 125
Unit
V
V
V
mA
mW
°C
°C
1.Drain
2.Source
3.Gate1
4.Gate2
USQ
JEDEC
Note: Using continuously under heavy loads (e.g. the application of high
JEITA
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
TOSHIBA
2-2K1B
reliability significantly even if the operating conditions (i.e.
Weight: 6 mg (typ.)
operating temperature/current/voltage, etc.) are within the
absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Gate 1 leakage current
Gate 2 leakage current
Drain-source voltage
Drain current
Gate 1-source cut-off voltage
Gate 2-source cut-off voltage
Forward transfer admittance
Input capacitance
Reverse transfer capacitance
Power gain
Noise figure
Symbol
I
G1SS
I
G2SS
V
(BR) DSX
I
DSS
V
G1S (OFF)
V
G2S (OFF)
⎪Y
fs
C
iss
C
rss
G
ps
NF
Test Condition
V
DS
=
0, V
G1S
= ±6
V, V
G2S
=
0
V
DS
=
0, V
G1S
=
0, V
G2S
= ±6
V
V
G1S
= −0.5
V, V
G2S
= −0.5
V,
I
D
=
100
μA
V
DS
=
6 V, V
G1S
=
0, V
G2S
=
4.5 V
V
DS
=
6 V, V
G2S
=
4.5 V, I
D
=
100
μA
V
DS
=
6 V, V
G1S
=
4.0 V, I
D
=
100
μA
V
DS
=
6 V, V
G2S
=
4.5 V, I
D
=
10 mA,
f
=
1 kHz
V
DS
=
6 V, V
G2S
=
4.5 V, I
D
=
10 mA,
f
=
1 MHz
V
DS
=
6 V, V
G2S
=
4.5 V, I
D
=
10 mA,
f
=
500 MHz (Figure 1)
Min
12.5
0.3
0.5
19.5
23.5
Typ.
0.9
1.0
23.5
2.5
20
26.0
1.4
Max
±50
±50
0.1
1.3
1.5
3.1
40
2.5
Unit
nA
nA
V
mA
V
V
mS
pF
fF
dB
dB
Start of commercial production
1996-10
