Ultra-Miniature 01005 Size Accu-P
®
Thin-Film RF Microwave Capacitor
ACCU-P
®
TECHNOLOGY
The use of silicon oxide, a very low - loss dielectric material, in conjunction with
highly conductive electrode metals, results in low ESR and high Q. These high -
frequency characteristics change at a slower rate with increasing frequency than
for ceramic microwave capacitors.
ACCU-P
®
meets the fast - growing demand for low - loss (high - Q) capacitors for
use in surface mount technology, especially for the wireless communications
market at frequencies up to and above 5.8GHz.
ACCU-P
®
is currently unique in its ability to offer very low capacitance values (0.05
pF) and ultra tight capacitance tolerances (±0.01 pF).
APPLICATIONS
•
•
•
•
•
•
•
FEATURES
Ultra Miniature standard 01005 chip size.
Ultra tight capacitance tolerances (±0.01pF).
Low ESR and high Q at VHF, UHF and microwave frequencies.
TC ±30, ±60ppm/°C.
Nickel/Solder - coated terminations provide excellent solderability and leach
resistance.
• High insulation resistance: IR ≥ 10
10
Ohm.
• Orientation provides high SRF uniformity.
• Repeatable C
EFF
, ESR and Q vs. Frequency parameters, both lot to lot and
within lots, for increased production yields.
•
•
•
•
•
RF Modules
Mobile communications
Satellite TV
Global positioning systems
Filters
VCO’s
Matching networks
HOW TO ORDER
C005
Series
Y
Voltage
Y = 16V
X
Temperature
Coefficient
XXX
Capacitance
(pF)
X
Tolerance
B
Accu-P
S
Lead Free
Termination
TR
Packaging
Code
5000 pc reel
TR/10K = 10,000 pc reel
TR/20K = 20,000 pc reel
P/N Example: C 0 0 5 Y K 1 R 0 A B S T R
QUALITY AND RELIABILITY
Finished parts are tested for standard electrical parameters and visual / mechanical characteristics.
Each production lot is 100%
evaluated for:
• Capacitance
• Q Factor
• DWV at 12.5xV
RATED
Each production lot is evaluated
on a sample basis for:
• Dimensions
• Insulation Resistance
• Breakdown Voltage
• ESR
• Solderability
In addition, production is periodically
evaluated for:
• Mechanical stability
• Endurance (Life)
• Temperature Coefficient
• Accelerated Damp Heat Load (THB)
• Temperature Cycling
1
Ultra-Miniature 01005 Size Accu-P
®
Thin-Film RF Microwave Capacitor
ACCU-P
®
01005 CAPACITANCE RANGE
Capacitance
[pF]
0.05
0.10
0.15
0.20
0.25
0.30
0.35
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.80
0.85
Part Number
Tolerances
Z = ±0.01pF
TC
P = ±0.02pF J = ±30ppm/ºC
Q = ±0.03pF K = ±60ppm/ºC
A = ±0.05pF
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
Z, P, Q, A
J
P, Q, A
J
P, Q, A
J
P, Q, A
J
P, Q, A
J
P, Q, A
K
P, Q, A
K
P, Q, A
K
Voltage
(V)
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
Capacitance
[pF]
0.90
0.95
1.00
1.10
1.20
1.30
1.40
1.50
1.60
1.70
1.80
1.90
2.00
2.10
2.20
2.30
2.40
Part Number
Tolerances
Z = ±0.01pF
TC
P = ±0.02pF J = ±30ppm/ºC
Q = ±0.03pF K = ±60ppm/ºC
A = ±0.05pF
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
P, Q, A
K
Voltage
(V)
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
C005YJR05_BSTR
C005YJ0R1_BSTR
C005YJR15_BSTR
C005YJ0R2_BSTR
C005YJR25_BSTR
C005YJ0R3_BSTR
C005YJR35_BSTR
C005YJ0R4_BSTR
C005YJR45_BSTR
C005YJ0R5_BSTR
C005YJR55_BSTR
C005YJ0R6_BSTR
C005YJR65_BSTR
C005YJ0R7_BSTR
C005YJR75_BSTR
C005YK0R8_BSTR
C005YKR85_BSTR
C005YK0R9_BSTR
C005YKR95_BSTR
C005YK1R0_BSTR
C005YK1R1_BSTR
C005YK1R2_BSTR
C005YK1R3_BSTR
C005YK1R4_BSTR
C005YK1R5_BSTR
C005YK1R6_BSTR
C005YK1R7_BSTR
C005YK1R8_BSTR
C005YK1R9_BSTR
C005YK2R0_BSTR
C005YK2R1_BSTR
C005YK2R2_BSTR
C005YK2R3_BSTR
C005YK2R4_BSTR
Intermediate capacitance values are available
DIMENSIONS
- mm (inches)
B1
L
W
T
W
B2
L
T
B
0.405 ± 0.020
(0.016 ± 0.001)
0.215 ± 0.020
(0.0085 ± 0.001)
0.145 ± 0.020
(0.006 ± 0.001)
Top (B1): 0.0 +0.10/-0.0
(0.0 +0.004/-0.0)
Bottom (B2): 0.10 ± 0.03
(0.004 ± 0.001)
RECOMMENDED
PAD LAYOUT
- mm (inches)
0.22
(0.009)
0.17 (0.007)
0.20 (0.008)
PACKAGING SPECIFICATION
- mm (inches)
Standard Packaging:
5,000 / 10,000 / 20,000pcs in 4" / 7" reels
Materials:
Reel – Polystyrene
Tape – Paper: 8.00 (0.315)
Component pitch: 2.00 (0.079)
2.00 (0.079)
4.00 (0.157)
2.00 (0.079)
2.00 (0.079)
2
