PHOTONIC
Silicon Photodiode, Filter Combination Photoconductive
DETECTORS INC.
Visible Spectral Response Range Type
PDV-C406-LP
PACKAGE DIMENSIONS INCH [mm]
Ø0.325 [8.25]
Ø0.250 [6.35]
C
L
45°
Ø0.358
[9.09]
0.035
[0.89]
WINDOW CAP
(WELDED)
0.030 [0.76]
Industry Equivalent:
BPW-21
0.125 [3.17]
0.105 [2.67]
0.075 [1.91] CHIP SURFACE
0.500
[12.70]
MIN
C
L
C
L
VIEWING
ANGLE
102°
0.200 [5.08]
C
L
ANODE
Ø0.018 [0.46]
CATHODE
Ø0.018 [0.46]
PHOTODIODE
0.125 [3.18]
0.113 [2.87]
ACTIVE AREA
0.113 [2.87]
ACTIVE AREA
PHOTOPIC FILTER
HEADER
TO-5 HERMETIC CAN PACKAGE
ACTIVE AREA = 7.95 mm
2
FEATURES
Wide view angle
Human eye response
RESPONSIVITY (A/W)
DESCRIPTION
APPLICATIONS
The
PDV-C406-LP
is a silicon, PIN planar
Photometry
diffused, photodiode with a visible spectral
Radiometry
Low noise, low capacitance
response range. The detector filter combination
Film color processing
has a wide bandwidth designed to simulate the
Hermetic package
spectral response of the human eye. Packaged
in a low profile hermetic TO-5 metal can.
SPECTRAL RESPONSE
ABSOLUTE MAXIMUM RATING
(TA=25
O
C unless otherwise noted)
0.7
SYMBOL
PARAMETER
MIN
MAX
UNITS
0.6
V
BR
T
STG
T
O
T
S
I
L
Reverse Voltage
Storage Temperature
Operating Temperature Range
Soldering Temperature*
Light Current
-50
-40
100
+100
+85
+240
500
V
O
O
O
0.5
0.4
0.3
0.2
0.1
190
300
400
500
600
700
800
900
1000
1100
Hz
1200
0
C
C
C
10
E=
Q
0%
mA
*1/16 inch from case for 3 secs max
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS
(TA=25
O
C unless otherwise noted)
SYMBOL CHARACTERISTIC
TEST CONDITIONS
MIN
TYP
I
SC
I
D
R
SH
TC R
SH
C
J
lrange
lp
V
BR
NEP
tr
Short Circuit Current
Dark Current
Shunt Resistance
RSH Temp. Coefficient
Junction Capacitance
H = 100 fc, 2850 K
H = 0, V
R
= 10 V
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 V**
150
90
110
5
300
-8
60
MAX
20
UNITS
m
A
nA
M
Ω
% /
o
C
150
pF
nm
nm
V
W/
nS
Spectral Application Range Flooded
Spectral Response Peak
Breakdown Voltage
Noise Equivalent Power
Response Time
(FWHM)
I = 10
m
A
V
R
= 10 V @ Peak
RL = 1 KΩ V
R
= 10 V
350
550
75
100
5x10
-14
50
820
Information in this technical data sheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications
are subject to change without notice.** f = 1 MHz
[FORM NO. 100-PDV-C406-LP REV A]
