Muilt - 6 Pack, Inductors and Transformers

PM600 / PM610 / PM620 Series

Special Features:

•

Six windings offer many inductor or transformer

configuration

•

High magnetic coupling

•

Non-gapped and gapped core construction

•

Low core loss at high frequency applications

•

Low noise radiation

•

Compact size and low profile

•

Dielectric strength: 500 Vrms between windings

•

Operating temperature: -40 to +105 ºC

•

Tape & Reel packaging:

PM600, 600/reel

PM610, 300/reel

PM620, 200/reel

Part

Number

PM600-01

PM600-02

PM600-03

PM600-04

PM600-05

PM600-06

PM600-07

PM600-08

PM600-09

PM600-10

PM610-01

PM610-02

PM610-03

PM610-04

PM610-05

PM610-06

PM610-07

PM610-08

PM610-09

PM610-10

PM620-01

PM620-02

PM620-03

PM620-04

PM620-05

PM620-06

PM620-07

PM620-08

PM620-09

PM620-10

PM620-11

PM620-12

L (uH)

@ 100KHz

201.6

±30%

89.6

±30%

27.4

±10%

12.2

±10%

14.7

±10%

6.5

±10%

10.9

±10%

4.9

±10%

8.5

±10%

3.8

±10%

160.0

±30%

78.4

±30%

21.6

±10%

10.6

±10%

11.6

±10%

5.7

±10%

8.3

±10%

4.1

±10%

6.6

±10%

3.2

±10%

160.6

±30%

77.0

±30%

131.8

±20%

63.2

±20%

23.3

±10%

11.2

±10%

14.2

±10%

6.8

±10%

9.3

±10%

4.5

±10%

7.9

±10%

3.8

±10%

DCR (Ω)

Max.

0.324

0.137

0.324

0.137

0.324

0.137

0.324

0.137

0.324

0.137

0.202

0.094

0.202

0.094

0.202

0.094

0.202

0.094

0.202

0.094

0.065

0.094

0.065

0.094

0.065

0.094

0.065

0.094

0.065

0.094

0.065

Isat

(A)

0.02

0.03

0.31

0.47

0.58

0.87

0.88

1.32

1.23

1.85

0.04

0.06

0.67

0.96

1.30

1.86

2.00

2.86

2.30

3.29

0.03

0.04

0.08

0.12

0.36

0.52

0.76

1.10

1.11

1.60

1.40

2.02

Irms

(A)

0.46

0.71

0.46

0.71

0.46

0.71

0.46

0.71

0.46

0.71

0.68

1.00

0.68

1.00

0.68

1.00

0.68

1.00

0.68

1.00

1.28

1.54

1.28

1.54

1.28

1.54

1.28

1.54

1.28

1.54

1.28

1.54

Typical Applications:

•

Inductors: buck, boost, buck-boost, coupled, input,

output, choke, filter, resonant, high-Q, EMI/RFI

filtering, differential, forward, common mode

•

Transformers: flyback, forward, push-pull, bridge,

multiple outputs, inverter, step-up, step-down, gate

drive, base drive, signal, wide band, pulse,

impedance, isolation, converter

Notes:

1. Saturation current is rated to each winding that

causes inductance to drop 30% from its initial value.

2. Rms current is rated to each winding that causes

40°C temperature rise.

3. PM600-01, -02, PM610-01, -02

PM620-01, -02 are non gap core.

J.W.Miller

M A G N E T I C S

306 E. Alondra Blvd., Gardena, CA 90247-1059

•

(310) 515-1720

•

FAX (310) 515-1962

www.jwmiller.com
