CARBON ZINC BATTERIES
Panasonic carbon zinc batteries offer economy and peak performance and are built for professional applications.
Applications
• Clocks
• Communications Equipment
• Electronic Calculators
• Flashlights, Penlights
• Measuring Instruments
• Remote Controls
• Portable electronics
Carbon Zinc Batteries Specification Table
Model
Number
UM-4NPA
UM-3NPA
UM-2NPA
UM-1NPA
R1NW
6F22NW
Size
Type
Label
Color
Blue
Blue
Blue
Blue
Black
Black
V
1.5
1.5
1.5
1.5
1.5
9
Diameter/Width
Inch (mm)
.413 (10.49)
.571 (14.50)
1.031 (26.19)
1.339 (34.01)
.472 (11.99)
1.043 (26.49)
Height
Inch (mm)
1.752 (44.50)
1.988 (50.50)
1.969 (50.00)
2.421 (61.49)
1.189 (30.20)
1.909 (48.49)
Thickness
---
---
---
---
---
Avg./Wt.
oz (g)
0.34 (9.70)
0.67 (19.00)
1.82 (51.50)
3.53 (100.0)
0.23 (6.55)
AAA Super Heavy Duty
AA
C
D
N
9V
Super Heavy Duty
Super Heavy Duty
Super Heavy Duty
Extra Heavy Duty
Extra Heavy Duty
0.689 (17.50) 1.31 (38.00)
* Extra Heavy Duty and Super Heavy Duty are the same grade product. Super Heavy Duty is manufactured in Indonesia and Extra Heavy Duty is
manufactured in Japan.
CARBON ZINC
MAY 2004
This information is generally descriptive only and is not intended to make or imply any representation, guarantee or warranty with respect to any cells and batteries. Cell and battery designs/specifications are subject to
modification without notice. Contact Panasonic for the latest information.
CARBON ZINC BATTERIES
DIMENSIONS / INCH (MM)
Model No.
Size “AAA”
Dimensions/inch (mm)
1. Nominal Voltage: 1.5 volts
0.413 (10.49)
0.150 (3.8)
Dimensions/inch (mm)
Size “AA”
1. Nominal Voltage: 1.5 volts
0.39min
(1.0min)
0.571 (14.5)
0.217 (5.5)
0.31min
(0.8min)
UM-4NPA
+
1.752max (44.5max)
1.673min (42.5min)
UM-3NPA
+
1.988max (50.5max)
1.831min (46.5min)
1.909 max
(48.49max)
_
Note:
Drawing not to scale
Note:
Drawing not to scale
Size “C”
1. Nominal Voltage: 1.5 volts
0.59min
(1.5min)
Size “D”
1. Nominal Voltage: 1.5 volts
0.59min
(1.5min)
1.339 (34.01)
0.374 (9.5)
1.031 (26.19)
0.295 (7.5)
1.969max (50.0max)
UM-2NPA
+
Note:
Drawing not to scale
Note:
Drawing not to scale
Size “N”
1. Nominal Voltage: 1.5 volts
( 11.99)
0.472
( 3.2)
0.126
Size “9V”
1. Nominal Voltage: 9.0 volts
1.043 (26.49)
(0.8)
0.031
R1NW
+
6F22NW
(30.2)
1.189
+
0.504
(12.8)
Note:
Drawing not to scale
Note:
Drawing not to scale
0.689
(17.5)
CARBON ZINC
MAY 2004
This information is generally descriptive only and is not intended to make or imply any representation, guarantee or warranty with respect to any cells and batteries. Cell and battery designs/specifications are subject to
modification without notice. Contact Panasonic for the latest information.
2.376min (60.30min)
1.909min (48.5min)
2.421 (61.49 max)
UM-1NPA
+
1.929min (49.0min)
