THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
REV.
B
C
REVISION
DESCRIPTION
RoHS Compliancy
Updated Approvals
DATE
06-01-06
10-15-08
APPROVED
D.P.
LY
24.2 ± 0.3
24.8 ± 0.3
32.2 ± 0.3
32.8 ± 0.3
6 ± 0.1
32.6 ±
0.2
0
14.4
0.8
10.2
PANEL CUTOUT
24.6 ±
0.2
0
R5
6.3
Ø1.65
27.5 ±
0.5
0
21 ±
0.5
0
14 ±
1
0.5
17 ±
0.5
0
2.0
19 ±
0
1
21
2.0
5 ± 0.1
13 ± 0.2
29 ±
0.5
0
35.5 ±
0.5
0
3.1
2 ± 0.05
CONTROLLED
8 ± 0.2
4
3
2
1
Soldering PIN Bronze Strip t=0.8mm Tin-Plated
Contact PIN Bronze Strip t=2mm Tin-Plated
Contact PIN Bronze Strip t=2mm Tin-Plated
Body Insulator PC 241R Black Color
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B.Zhang
08-08-03
3
2
1
1
Qualtek Electronics Corp.
Part Number:
Description:
NOTES:
RATING:
UL, CSA: 20A 125V AC/20A 250V AC
VDE, CCC: 16A 250V AC
APPROVALS: UL, CSA, VDE, CCC
PANEL THICKNESS: 2.0mm
IEC 60320 C20
RoHS COMPLIANT
PPC DIVISION
745W-20/12
AC RECEPTACLE
UNIT: mm
Checked / Date
08-08-03
REV. C
Approved / Date
JJH / 08-08-03
