24.2 ± 0.3
24.8 ± 0.3
32.2 ± 0.3
32.8 ± 0.3
6 ± 0.1
6.3
Ø1.65
32.6 ±
0.2
0
PANEL CUTOUT
14.4
0.8
10.2
24.6 ±
0.2
0
R5
27.5 ±
0.5
0
2.5
3.1
2 ± 0.05
5 ± 0.1
13 ± 0.2
29 ±
0.5
0
35.5 ±
0.5
0
8 ± 0.2
4
3
2
1
14 ±
1
0.5
0.5
17 ±
0
19 ±
0
1
21
21 ±
0.5
0
2.5
CONTROLLED
3
2
1
1
Soldering PIN Bronze Strip t=0.8mm Tin-Plated
Contact PIN Bronze Strip t=2mm Ni-Plated
Contact PIN Bronze Strip t=2mm Ni-Plated
Body Insulator PC 940A Black Color
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B.Zhang
06-25-02
Qualtek Electronics Corp.
Part Number:
Description:
NOTES:
RATING:
UL, CSA: 20A 125V AC/20A 250V AC
VDE, CCC: 16A 250V AC
APPROVALS: UL, CSA, VDE, CCC
PANEL THICKNESS: 2.5mm
IEC 60320 C20
RoHS COMPLIANT
PPC DIVISION
745W-25/16
AC RECEPTACLE
UNIT: mm
Checked / Date
06-25-02
REV. C
Approved / Date
JJH / 06-25-02
