REVISIONS
REV.
A
ECO. NO
2291
DESCRIPTION
INITIAL RELEASE
DATE
03/11/2011
BY
LH
F
F
B±.012 [0.30]
E
.134 3.40
E
A
D
.050 1.27
D
.118 3.00
.079 2.00
.102 2.60
C
C
.050 1.27
.016 0.40
.050 1.27
A
.028 0.70
B
A
NOTES:
1. INSULATOR MATERIAL: NYLON 6T, UL 94V-0, BLACK.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: .000030" ~ .000050" NICKEL UNDERPLATE, GOLD FLASH OVERALL.
4. CURRENT RATING: 1 AMP PER CONTACT.
5. INSULATOR RESISTANCE: 5000 MEGOHMS MIN.
6. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
7. DIELECTRIC WITHSTANDING: 500 VAC.
8. OPERATING TEMPERATURE: -40° C TO +105° C.
9. *PROCESSING TEMP.: 230° C FOR 60 SECS MAX.
(260° C FOR 10 SECS.)
*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT INSULATOR. HIGHER PROCESSING
TEMPERATURES MAY BE USED, PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB,
AND INSULATOR DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.
8
7
6
5
.050 1.27
B
RECOMMENDED PCB LAYOUT
DRAWN
DATE
3/11/11
NAME
LH
Pb
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
ANGULAR: 30'
X.XX= .012 [0.3]
X.XXX= .008 [0.20]
X.XXXX= .0040 [0.100]
TOLERANCES:
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
HEADER MALE .050"[1.27mm] PITCH, ST
PART NUMBER
SIZE
TITLE
A
R
oHS COMPLIANT
INTERPRET DIMENSIONS AND
TOLERANCING
PER: ASME Y14.5M-2009
3
SCALE: 8:1
2
C
CAGE CODE
SMH200-NPPB-D_ _-ST-BK
DWG. NO.
54453
11673
REV
SHEET 1 OF 1
1
A
FILE NAME: Z:\ECO PENDING\2291, TAIWAN PARTS HAD ORDERS BY 3-8-11\11673, SMH200-NPPB-D_ _-ST-BK SLDPRT PRINT: 7/21/2011
