Product specifications
Core
EQ38/8/25 + PLT38/25/2.7
Effective parameters
Symbol
∑(I/A)
Ve
Le
Ae
Amin
m
m
Parameter
core factor (C1)
effective volume
effective length
effective area
minimum area
EQ38/8/25
PLT38/25/2.7
Value
0.282
6190
41.7
148
119
≈ 21.5
≈ 14.6
Unit
mm⁻¹
mm³
mm
mm²
mm²
g/pcs
g/pcs
Dimensions for product: EQ38/8/25
Symbol
A
B
C
D2
D3
E
F
Nom
38.10
25.40
24.76
33.10
14.00
8.00
5.30
Tol +
0.70
0.50
0.50
0.60
0.20
0.15
0.20
Tol -
0.70
0.50
0.50
0.60
0.20
0.15
0.20
Max
38.80
25.90
25.26
33.70
14.20
8.15
5.50
Min
37.40
24.90
24.26
32.50
13.80
7.85
5.10
Unit
mm
mm
mm
mm
mm
mm
mm
Dimensions for product: PLT38/25/2.7
Symbol
A
Nom
38.10
Tol +
0.70
Tol -
0.70
Max
38.80
Min
37.40
Unit
mm
