MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MC145026/D
Encoder and Decoder Pairs
CMOS
These devices are designed to be used as encoder/decoder pairs in remote
control applications.
The MC145026 encodes nine lines of information and serially sends this
information upon receipt of a transmit enable (TE) signal. The nine lines may be
encoded with trinary data (low, high, or open) or binary data (low or high). The
words are transmitted twice per encoding sequence to increase security.
The MC145027 decoder receives the serial stream and interprets five of the
trinary digits as an address code. Thus, 243 addresses are possible. If binary
data is used at the encoder, 32 addresses are possible. The remaining serial
information is interpreted as four bits of binary data. The valid transmission (VT)
output goes high on the MC145027 when two conditions are met. First, two
addresses must be consecutively received (in one encoding sequence) which
both match the local address. Second, the 4 bits of data must match the last
valid data received. The active VT indicates that the information at the Data
output pins has been updated.
The MC145028 decoder treats all nine trinary digits as an address which
allows 19,683 codes. If binary data is encoded, 512 codes are possible. The VT
output goes high on the MC145028 when two addresses are consecutively
received (in one encoding sequence) which both match the local address.
•
•
•
•
•
•
Operating Temperature Range: – 40 to + 85°C
Very–Low Standby Current for the Encoder: 300 nA Maximum @ 25°C
Interfaces with RF, Ultrasonic, or Infrared Modulators and Demodulators
RC Oscillator, No Crystal Required
High External Component Tolerance; Can Use
±
5% Components
Internal Power–On Reset Forces All Decoder Outputs Low
MC145026
MC145027
MC145028
SC41343
SC41344
P SUFFIX
PLASTIC DIP
CASE 648
1
16
16
1
D SUFFIX
SOG PACKAGE
CASE 751B
16
DW SUFFIX
SOG PACKAGE
CASE 751G
1
ORDERING INFORMATION
MC145026P
MC145026D
MC145027P, SC41343P
MC145027DW, SC41343DW
MC145028P, SC41344P
MC145028DW, SC41344DW
Plastic DIP
SOG Package
Plastic DIP
SOG Package
Plastic DIP
SOG Package
•
Operating Voltage Range: MC145026 = 2.5 to 18 V
*
MC145027, MC145028 = 4.5 to 18 V
•
Low–Voltage Versions Available:
SC41343 = 2.8 to 10 V Version of the MC145027
SC41344 = 2.8 to 10 V Version of the MC145028
•
For Infrared Applications, See Application Note AN1016/D
PIN ASSIGNMENTS
MC145026
ENCODER
A1
A2
A3
A4
A5
A6/D6
A7/D7
VSS
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
VDD
Dout
TE
RTC
CTC
RS
A9/D9
A8/D8
MC145027/SC41343
DECODERS
A1
A2
A3
A4
A5
R1
C1
VSS
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
VDD
D6
D7
D8
D9
VT
R2/C2
Din
MC145028/SC41344
DECODERS
A1
A2
A3
A4
A5
R1
C1
VSS
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
VDD
A6
A7
A8
A9
VT
R2/C2
Din
* All MC145026 devices manufactured after date code 9314 or 314 are guaranteed over this wider voltage range. All previous designs using the
low–voltage SC41342 should convert to the MC145026, which is a drop–in replacement. The SC41342 part number has been discontinued.
REV 2
1/98
©
Motorola, Inc. 1998
MOTOROLA
MC145026•MC145027•MC145028•SC41343•SC41344
1
RS
RTC
CTC
TE
11
14
12
13
3–PIN
OSCILLATOR
AND
ENABLE
÷
4
DIVIDER
DATA SELECT
AND
BUFFER
15 D
out
9
A1
A2
A3
A4
A5
A6/D6
A7/D7
A8/D8
A9/D9
1
2
3
4
5
6
7
9
10
RING COUNTER AND 1–OF–9 DECODER
8
7
6
5
4
3
2 1
TRINARY
DETECTOR
VDD = PIN 16
VSS = PIN 8
Figure 1. MC145026 Encoder Block Diagram
11
VT
4–BIT SHIFT REGISTER
15
14
LATCH
13
12
CONTROL
LOGIC
D6
D7
D8
D9
SEQUENCER CIRCUIT
5
A1
A2
A3
A4
A5
1
2
3
4
5
C1
7
R1
DATA
EXTRACTOR
6
C2
10
R2
9
Din
4
3
2
1
VDD = PIN 16
VSS = PIN 8
Figure 2. MC145027 Decoder Block Diagram
MC145026•MC145027•MC145028•SC41343•SC41344
2
MOTOROLA
CONTROL
LOGIC
11
VT
9
A1
A2
A3
A4
A5
1
2
3
4
5
8
SEQUENCER CIRCUIT
7
6
5
4
3
2
1
9–BIT
SHIFT
REGISTER
DATA
EXTRACTOR
C1
7
R1
6
C2
10
R2
9
Din
A6 15
A7 14
A8 13
A9 12
VDD = PIN 16
VSS = PIN 8
Figure 3. MC145028 Decoder Block Diagram
MAXIMUM RATINGS*
(Voltages Referenced to VSS)
Rating
VDD
VDD
Vin
Vout
Iin
Iout
PD
Tstg
TL
Symbol
DC Supply Voltage (except SC41343,
SC41344)
DC Supply Voltage (SC41343, SC41344
only)
DC Input Voltage
DC Output Voltage
DC Input Current, per Pin
DC Output Current, per Pin
Power Dissipation, per Package
Storage Temperature
Lead Temperature, 1 mm from Case for
10 Seconds
Value
– 0.5 to + 18
– 0.5 to + 10
– 0.5 to VDD + 0.5
– 0.5 to VDD + 0.5
±
10
±
10
500
– 65 to + 150
260
Unit
V
V
V
V
mA
mA
mW
°C
°C
This device contains protection circuitry to
guard against damage due to high static
voltages or electric fields. However, precau-
tions must be taken to avoid applications of any
voltage higher than maximum rated voltages
to this high–impedance circuit. For proper
operation, Vin and Vout should be constrained
to the range VSS
≤
(Vin or Vout)
≤
VDD.
* Maximum Ratings are those values beyond which damage to the device may occur. Func-
tional operation should be restricted to the limits in the Electrical Characteristics tables or
Pin Descriptions section.
MOTOROLA
MC145026•MC145027•MC145028•SC41343•SC41344
3
ELECTRICAL CHARACTERISTICS — MC145026
*
, MC145027, and MC145028
(Voltage Referenced to VSS)
Guaranteed Limit
VDD
V
(Vin = VDD or 0)
5.0
10
15
5.0
10
15
5.0
10
15
5.0
10
15
5.0
5.0
10
15
5.0
10
15
5.0
10
15
15
– 40°C
Min
—
—
—
4.95
9.95
14.95
—
—
—
3.5
7.0
11
– 2.5
– 0.52
– 1.3
– 3.6
0.52
1.3
3.6
—
—
—
—
Max
0.05
0.05
0.05
—
—
—
1.5
3.0
4.0
—
—
—
—
—
—
—
—
—
—
—
—
—
±
0.3
Min
—
—
—
4.95
9.95
14.95
—
—
—
3.5
7.0
11
– 2.1
– 0.44
– 1.1
– 3.0
0.44
1.1
3.0
3.0
16
35
—
25°C
Max
0.05
0.05
0.05
—
—
—
1.5
3.0
4.0
—
—
—
—
—
—
—
—
—
—
11
60
120
±
0.3
Min
—
—
—
4.95
9.95
14.95
—
—
—
3.5
7.0
11
– 1.7
– 0.36
– 0.9
– 2.4
0.36
0.9
2.4
—
—
—
—
85°C
Max
0.05
0.05
0.05
—
—
—
1.5
3.0
4.0
V
(Vout = 0.5 or 4.5 V)
(Vout = 1.0 or 9.0 V)
(Vout = 1.5 or 13.5 V)
IOH
High–Level Output Current
(Vout = 2.5 V)
(Vout = 4.6 V)
(Vout = 9.5 V)
(Vout = 13.5 V)
IOL
Low–Level Output Current
(Vout = 0.4 V)
(Vout = 0.5 V)
(Vout = 1.5 V)
Iin
Input Current — TE
(MC145026, Pull–Up Device)
Input Current
RS (MC145026), Din (MC145027, MC145028)
Input Current
A1 – A5, A6/D6 – A9/D9 (MC145026),
A1 – A5 (MC145027),
A1 – A9 (MC145028)
Input Capacitance (Vin = 0)
Quiescent Current — MC145026
—
—
—
—
—
—
±
1.0
µA
—
—
—
—
mA
—
—
—
mA
Unit
U i
V
Symbol
S b l
VOL
Characteristic
Ch
i i
Low–Level Output Voltage
VOH
High–Level Output Voltage
(Vin = 0 or VDD)
V
VIL
Low–Level Input Voltage
(Vout = 4.5 or 0.5 V)
(Vout = 9.0 or 1.0 V)
(Vout = 13.5 or 1.5 V)
V
VIH
High–Level Input Voltage
Iin
Iin
µA
µA
5.0
10
15
—
5.0
10
15
5.0
10
15
5.0
10
15
5.0
10
15
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
±
110
±
500
±
1000
7.5
0.1
0.2
0.3
50
100
150
200
400
600
400
800
1200
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
pF
µA
Cin
IDD
IDD
Quiescent Current — MC145027, MC145028
µA
Idd
Dynamic Supply Current — MC145026
(fc = 20 kHz)
Dynamic Supply Current — MC145027, MC145028
(fc = 20 kHz)
µA
Idd
µA
* Also see next Electrical Characteristics table for 2.5 V specifications.
MC145026•MC145027•MC145028•SC41343•SC41344
4
MOTOROLA
ELECTRICAL CHARACTERISTICS — MC145026
(Voltage Referenced to VSS)
Guaranteed Limit
VDD
V
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
– 40°C
Min
—
2.45
—
2.2
0.28
0.22
—
—
—
—
Max
0.05
—
0.3
—
—
—
—
—
—
—
Min
—
2.45
—
2.2
0.25
0.2
0.09
—
—
—
25°C
Max
0.05
—
0.3
—
—
—
1.8
±
25
0.05
40
Min
—
2.45
—
2.2
0.2
0.16
—
—
—
—
85°C
Max
0.05
—
0.3
—
—
—
—
—
—
—
Unit
U i
V
V
V
V
mA
mA
µA
µA
µA
µA
Symbol
S b l
VOL
VOH
VIL
VIH
IOH
IOL
Iin
Iin
IDD
Idd
Characteristic
Ch
i i
Low–Level Output Voltage
High–Level Output Voltage
Low–Level Input Voltage
High–Level Input Voltage
High–Level Output Current
Low–Level Output Current
Input Current (TE — Pull–Up Device)
Input Current (A1–A5, A6/D6–A9/D9)
Quiescent Current
Dynamic Supply Current (fc = 20 kHz)
(Vin = 0 V or VDD)
(Vin = 0 V or VDD)
(Vout = 0.5 V or 2.0 V)
(Vout = 0.5 V or 2.0 V)
(Vout = 1.25 V)
(Vout = 0.4 V)
ELECTRICAL CHARACTERISTICS — SC41343 and SC41344
(Voltage Referenced to VSS)
Guaranteed Limit
VDD
V
2.8
5.0
10
2.8
5.0
10
2.8
5.0
10
2.8
5.0
10
2.8
5.0
10
2.8
5.0
10
10
2.8
5.0
10
—
2.8
5.0
10
2.8
5.0
10
– 40°C
Min
—
—
—
2.75
4.95
9.95
—
—
—
1.96
3.5
7.0
– 0.73
– 0.59
– 1.3
0.35
0.8
3.5
—
—
—
—
—
—
—
—
—
—
—
Max
0.05
0.05
0.05
—
—
—
0.84
1.5
3.0
—
—
—
—
—
—
—
—
—
±
0.3
—
—
—
—
—
—
—
—
—
—
Min
—
—
—
2.75
4.95
9.95
—
—
—
1.96
3.5
7.0
– 0.7
– 0.5
– 1.1
0.3
0.6
2.9
—
—
—
—
—
—
—
—
—
—
—
25°C
Max
0.05
0.05
0.05
—
—
—
0.84
1.5
3.0
—
—
—
—
—
—
—
—
—
±
0.3
±
30
±
140
±
600
7.5
60
75
150
300
500
1000
Min
—
—
—
2.75
4.95
9.95
—
—
—
1.96
3.5
7.0
– 0.55
– 0.41
– 0.9
0.24
0.4
2.3
—
—
—
—
—
—
—
—
—
—
—
85°C
Max
0.05
0.05
0.05
—
—
—
0.84
1.5
3.0
V
(Vout = 0.5 V or 2.3 V)
(Vout = 0.5 V or 4.5 V)
(Vout = 1.0 V or 9.0 V)
IOH
High–Level Output Current
(Vout = 1.4 V)
(Vout = 4.5 V)
(Vout = 9.0 V)
IOL
Low–Level Output Current
(Vout = 0.4 V)
(Vout = 0.5 V)
(Vout = 1.0 V)
Iin
Iin
Input Current — Din
Input Current
A1 – A5 (SC41343)
A1 – A9 (SC41344)
Input Capacitance (Vin = 0)
Quiescent Current
—
—
—
±
1.0
—
—
—
—
—
—
—
—
—
—
µA
µA
—
—
—
mA
—
—
—
mA
Unit
U i
V
Symbol
S b l
VOL
Characteristic
Ch
i i
Low–Level Output Voltage
(Vin = 0 V or VDD)
VOH
High–Level Output Voltage
(Vin = 0 V or VDD)
V
VIL
Low–Level Input Voltage
(Vout = 2.3 V or 0.5 V)
(Vout = 4.5 V or 0.5 V)
(Vout = 9.0 V or 1.0 V)
V
VIH
High–Level Input Voltage
Cin
IDD
pF
µA
Idd
Dynamic Supply Current (fc = 20 kHz)
µA
MOTOROLA
MC145026•MC145027•MC145028•SC41343•SC41344
5
