BCM5395
®
Brief
WITH
5-PORT GbE SWITCH
•
FIVE INTEGRATED PHY
S
AND
PACKET BUFFER
FEATURES
Highly integrated, non-blocking, 5-port 10/100/1000 switch
silicon that integrates:
•
Five integrated 10/100/1000 PHYs
•
One GMII/RGMII interface for an In-band Management Port
(IMP) for glueless connection to a CPU/management entity
•
Serial EEPROM, MDC/MDIO, SPI, and Interrupt-to-CPU
Interface
LoopDTech™ and CableChecker™ reduce network down
time and minimize support effort
•
Broadcom’s patented LoopDTech technology for loop
detection without running spanning tree protocol
•
Broadcom’s CableChecker enables advanced cable diagnostics
based on Broadcom’s convergence algorithm
VLAN
•
IEEE 802.1Q-based VLAN with 4K entries
•
VLAN double-tagging (Q-in-Q)
QoS
•
Four selectable CoS per port: SP and WRR
•
Port, MAC, 802.1P, and IPv4/IPv6 DSCP based QoS
Performance
•
9 KB jumbo frame support—wirespeed performance for all
frame sizes
•
4K MAC addresses with automatic learning and aging
Security
•
IEEE 802.1x support for secure user authentication
•
DoS prevention hardware
Traffic control and network resiliency
•
Storm control and port-based ingress/egress rate control
•
Spanning tree support (rapid spanning tree and multiple
spanning trees—up to 16)
BroadSync™ HD (AV bridging)
•
Frame timer in MAC
•
Real-time clock module for master clock generation and time
sync
Management
•
On-chip MIB counters to collect, receive, and transmit
statistics for each port. Hardware support for SNMP/MIBs and
RMON.
SUMMARY OF BENEFITS
•
Provides a flexible solution for the cost-optimized board and
system designs
•
Additional interfaces enable efficient designs for the branch
office switch applications. Flexible CPU interface allows the
BCM5395 to work with any CPU.
•
Supports all types of client connections, including VoIP,
video, multimedia, and data. Proper priority can be assigned
to each traffic type to ensure guaranteed delivery of time-
sensitive packets and efficient use of network bandwidth.
•
Access Control List (ACL) provides the security vehicle for
frame classification and filtering.
•
IGMP and MLD snooping enables multicast switching
without expensive L3 multicast routing.
•
BroadSync HD provides quality of service for audio-video
packs through Ethernet by adding end-to-end bandwidth
reservation, admission control, timing, and synchronization.
•
Switch can be completely managed remotely using SNMP,
RMON, and OAM.
•
•
•
•
•
•
•
•
OVERVIEW
BCM5395
TRD[3:0]_0 +/-
10/100/1000
PHY
GMAC
ContentAware™
Compact Flash
Field Processor
TRD[3:0]_1 +/-
10/100/1000
PHY
GMAC
Register
Space
TRD[3:0]_2 +/-
10/100/1000
PHY
GMAC
Packet
Buffer
TRD[3:0]_3 +/-
10/100/1000
PHY
GMAC
Address
Management
TRD[3:0]_4 +/-
10/100/1000
PHY
Embedded PHY bypass option
GMAC
LED
interface
LED
GMAC
EEPROM
Interface
EEPROM
BCM5395 Block Diagram
The BCM5395 is a highly integrated, cost-effective Gigabit switch. The
BCM5395 combines all the functions of a high-speed switch system,
including five full-duplex 10/100/1000 BASE-T/TX Ethernet
transceivers, packet buffer, Media Access Controllers (MACs), and a
non-blocking switch fabric into a single 0.13μ CMOS device. In
addition, the BCM5395 has one GMII/RGMII/MII/RvMII interface for
a CPU or a wireless/DSL/cable router chip. It complies with the IEEE
802.3™ and IEEE 802.3x specifications, including the MAC control
pause frame, providing compatibility with all industry-standard
Ethernet, fast Ethernet, and Gigabit Ethernet devices.
The BCM5395 is packed with features, including VLAN, VLAN double
tagging, per port QoS, jumbo frame, rate control, and MIBs
management. Most importantly, it includes two Broadcom patented
technologies, LoopDTech and CableChecker, that are designed to
troubleshoot cable problems and loops during installation. Unlike
traditional TDR-based cable diagnostics, Broadcom CableChecker, can
detect cable and connector problems without having to disconnect the
cable from the other end. This means CableChecker can be running while
the switch is passing packets. With Broadcom WebSuperSmart™, a
web-based management interface, network support personnel can
monitor and troubleshoot network problems remotely, which is very
important in SMB environment where IT resources are scarce.
LoopDTech and CableChecker, when set up correctly, actually detect
problems automatically without any human intervention.
The BCM5395 can be smart-managed with Broadcom WebSuperSmart,
which can be provided by Broadcom and customized for system vendors.
Broadcom's turnkey solution approach (silicon chip, reference boards,
and management software) greatly accelerates time-to-market for
customers.
The BCM5395 has all the features needed to enable SMB in a box, which
can be connected to voice, multimedia, and data devices all at once.
With the support for per port QoS/queuing and rate control, different
packet types can be identified and prioritized within the switch, and
voice packets can be assigned with higher priority for outbound.
The Ethernet functionalities, QoS, LoopDTech, and CableChecker are
all integrated in a compact silicon chip, and all of the features can be
managed through Broadcom's SDK, which makes the BCM5395 the
most powerful and the easiest to deploy Gigabit Ethernet switch on the
market today.
