CTS05F40
Schottky Barrier Diode
Silicon Epitaxial
CTS05F40
1. Applications
•
High-Speed Switching
2. Features
(1)
(2)
High average rectified current
Low Reverse current: I
R
(2) = 1.8
µA
(typ.) at V
R
= 40 V
3. Packaging and Internal Circuit
1: Cathode
2: Anode
CST2
4. Absolute Maximum Ratings (Note) (Unless otherwise specified, T
a
= 25
)
Characteristics
Reverse voltage
Average rectified current
Non-repetitive peak forward surge current
Junction temperature
Storage temperature
Symbol
V
R
I
O
I
FSM
T
j
T
stg
(Note 1)
(Note 2)
Note
Rating
40
0.5
2
150
-55 to 150
Unit
V
A
A
Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
("Handling Precautions"/"Derating Concept and Methods") and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Mounted on an FR4 board.
(25.4 mm
×
25.4 mm
×
1.6 mm, Cu Pad: 645 mm
2
)
Note 2: Measured with a 10 ms pulse.
Note:
Start of commercial production
©2016 Toshiba Corporation
1
2016-06
2016-07-07
Rev.1.0
