HK-A Series
Single Output 115VAC Input Industrial Power Supplies
Features
3 Year Warranty
Small size
Approved to UL & CSA (cUL)
85 - 132VAC Input, 47-440Hz
±10% output adjustment
Adjustment potentiometer
Low profile
Key Market Segments & Applications
Specifications
Model
Input Voltage range
Inrush Current (100VAC)
Temperature Coefficient (Typ)
Overcurrent Protection
Overvoltage Protection
Hold Up Time (Typ at 100VAC)
Remote Sense
LED Indicator
Operating Temp (no cover) (1)
Operating Temp (w/ cover) (1)
Storage Temperature
Operating Humidity
Storage Humidity
Cooling
Withstand Voltage
Isolation Resistance
Vibration (non operating)
Shock
Safety Agency Approvals
Conducted & Radiated EMI
Recommended EMI Filter
Weight (Typ)
Size (WxHxD)
Warranty
-
A
-
-
%
ms
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
g
in
-
HK15A
HK25A
HK50A
HK100A
HK150A
85 - 132VAC (47 - 440Hz) or 110 - 175VDC*
20
30
15
30
15
15
1% (over operating temperature range)
>105%
>115% (Zener clamp)
115 to 135%
20
No
Yes
Green LED = On
0°C to +60°C, derate linearly to 50% load from 50°C to 60°C
0°C to +50°C, derate linearly to 50% load from 40°C to 50°C
-30 to +85°C
30 - 90% RH (non condensing)
10 - 95% RH (non condensing)
Convection cooled
I/P to Grnd, I/P to O/P 2kVAC (20mA), O/P to Grnd 500VAC (100mA) for 1 min.
>100M at 25C & 70%RH, Output to Ground 500VDC
10 - 55Hz (1 minute sweep), 19.6m/s
2
constant X, Y, Z 1 hour
< 196.1 m/s
2
UL60950-1, CSA C22.2 No. 60950-1 (cUL)
FCC Class B, VCCI-B
RSEL-20R5W
RSEL-2001W
RSEL-2002W
RSEN-2006
150
170
230
280
540
650
2.83x2.83x1.02 2.83x3.31x1.08 2.83x3.9x1.26 2.83x4.69x1.38 3.66x5.91x1.52 3.66x6.69x1.85
Three Years
*Safety certified for AC only
HK10A
(1) Vertical mount as photo, HK100A & HK150A models operate to -10°C
See installation manual for full details, test methods of parameters and application notes
N ot Rec o m en de d For N e w D es i gns
1-800-526-2324 • www.us.tdk-lambda.com/lp/
74
Disclaimer: us.tdk-lambda.com/lp/legal.htm
HK-A Series
Model Selector
Adjust
Model
Voltage Range
5
5
5
5
5
5
12
12
12
12
12
12
15
15
15
15
15
15
24
24
24
24
24
24
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
13.5 - 16.5
13.5 - 16.5
13.5 - 16.5
13.5 - 16.5
13.5 - 16.5
13.5 - 16.5
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
21.6 - 26.4
HK10A-5/A
HK15A-5/A
HK25A-5/A
HK50A-5/A
HK100A-5/A
HK150A-5/A
HK10A-12/A
HK15A-12/A
HK25A-12/A
HK50A-12/A
HK100A-12/A
HK150A-12/A
HK10A-15/A
HK15A-15/A
HK25A-15/A
HK50A-15/A
HK100A-15/A
HK150A-15/A
HK10A-24/A
HK15A-24/A
HK25A-24/A
HK50A-24/A
HK100A-24/A
HK150A-24/A
Max
2.0
3.0
5.0
10.0
20.0
30.0
0.9
1.3
2.1
4.2
8.5
12.5
0.7
1.0
1.7
3.4
7.0
10.0
0.5
0.7
1.1
2.2
4.5
6.5
Load
40
40
40
40
40
40
96
96
96
96
96
96
120
120
120
120
120
120
150
150
150
150
150
150
Line
20
20
20
20
20
20
48
48
48
48
48
48
60
60
60
60
60
60
96
96
96
96
96
96
Ripple
120
120
120
120
120
120
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
Eff.
71
69
72
79
80
80
73
74
76
81
81
81
74
75
77
82
81
81
78
77
80
84
82
82
Curr. Reg mV Reg mV Noise (typ)%
HK-10A Outline Drawing
Notes
A: M3 tapped holes (4) for customer chassis moun ng.
Screws must not protrude into power supply by more than 5 mm.
B: Model name and nominal output voltage and
maximum output current are shown here
in accordance with the specifica ons.
C: Country of manufacturer will be shown here.
D: C-UL-US & CE Marking (only 5V, 12V, 15V & 24V)
Derate to 80% load from 0 to -10°C
HK-150A Outline Drawing
HK10A - HK50A M3 mounting holes
HK100A - HK150A M4 mounting holes
(See website for detailed outline drawings)
INPU :100-120VAC 3.2 A
50 / 60H
U PU : 24 V
6.5 A
HK150A - 24
MAD
IN CHINA
Sample Configurations
Suffix
Blank
/A
LDIN30
Description
No cover (Special order)
With cover (Standard US stock)
DIN Rail Mounting Bracket (Sold Separately)
Other Industrial Products
HWS
DLP/DPP/DSP
ZWS
VSB/VSC
15W to 1500W Single output 85-265VAC
10W to 480W DIN rail mount 85-265VAC
5W to 150W pcb style single output 85-265VAC
10W to 150W pcb style single output 85-132VAC
For Additional Information, please visit
us.tdk-lambda.com/lp/products/hka-series.htm
N ot Rec o m en de d For N e w D es i gns
1-800-526-2324 • www.us.tdk-lambda.com/lp/
75
Revision A9: Sept. 2014
