FEATURES
APPLICATIONS
High Temperature
–
Very Low ESR – High Ripple Current –
Stable with Temperature – High Frequency
DC-DC Converters
–
Voltage Regulators
–
Decoupling
-55°C to +105°C
+20% at 120 Hz, 20°C
10
16
20
25
1.15 x rated WVDC
10% MAX
2 Minutes
0.2CV or 280uA, whichever is greater
<1.25
<1.25
2000 hours at 105°C with rated WVDC applied
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 hours at 60°C with rated voltage applied at 90-95% R.H.
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 cycles at 105°C with rated surge voltage applied for 30 seconds through a 1kΩ resistor
and discharged for 5 minutes and 30 seconds
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
Operating Temperature Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
Dissipation Factor
120 Hz, 20°C
Leakage Current
Low Temperature Stability
Impedance Ratio
(100 kHz)
2.5
4
-55°C/ +20°C
+105°C/ +20°C
Load Life
Damp Heat test
Surge Voltage test
Ripple Current Multipliers
120Hz<f<1kHz
0.05
Frequency (Hz)
1kHz<f<10kHz 10kHz<f<100kHz
0.3
0.7
100kHz<f<500kHz
1.0
5
6.3
2
2.5
0.5 L<7mm)
0.45 L<6mm)
d
0.6( L>7mm)
0.6( L>6mm)
L
1
=L+1.0 mm MAX L<11mm
L
1
=L+1.5 mm MAX, L>11 mm
D+0.5
S+0.5
8
3.5
0.6
10
5.0
0.6
