8.06.09 J-LINK MICROCHIP ADAPTER datasheet, PDF

8.06.09 J-LINK MICROCHIP ADAPTER: DescriptionADAPTER BOARD J-LINK MICROCHIP; CategoryDevelopment board/suite/development tools; File Size85KB，1 Pages; ManufacturerSegger Microcontroller; Environmental Compliance

Download Datasheet Parametric Compare View All

8.06.09 J-LINK MICROCHIP ADAPTER Overview

ADAPTER BOARD J-LINK MICROCHIP

Parameter Name	Attribute value
Accessory type	adapter board
Supporting products/related products	J-Link

SEGGER - The Embedded Experts - Adapters

Page 1 of 1

J-Link Microchip Adapter

The J-Link Microchip Adapter allows debug connections between J-Link and target

hardware which comes with Microchip PIC32 series MCUs. It supports the RJ12 modular

debug connector as specified by Microchip as well as the 14-pin dual row MIPS debug

header and the Microchip 6-pin single row PICkit connector (options, can be soldered by

customer on demand).

Note that the delivered modular cable will invert the pin order as shown in the pinout

below.

#MCLR

VDD

GND

Signal

DIO/PGD/RB7

CLK/PGC/RB6

Schematic

http://www.segger.com/jlink-adapters.html

5/8/2014

	8.06.09 J-LINK MICROCHIP ADAPTER
Description	ADAPTER BOARD J-LINK MICROCHIP
Accessory type	adapter board
Supporting products/related products	J-Link
