INSTRUMENT CASES/SYSTEM ENCLOSURES
ripac
vario-moDule
ripac vario-module 3 u
B
T
HE
TE
= Width
= Depht
=U
= HP
technical specifications:
May be used as a rack-mount
enclosure or instrument case.
External dimensions to
IEC 60 297-1 for installation in
482.6 mm (19˝) racks.
Installation dimensions for
board type plug-in assemblies
to IEC 60 297-3-101.
material/surface finish:
Side panels:
Extruded aluminum section,
spray finished in RAL 7035
Horizontal rails:
Extruded aluminum section,
clear-chromated
Corner trims:
Die-cast zinc,
spray-finished in RAL 7035
Side trims:
Extruded aluminum section,
spray-finished in RAL 7035
protection category:
IP 40 for non-vented version.
supply includes:
2 side panels,
4 horizontal rails,
4 threaded inserts,
2 corner trims,
assembly parts.
A
1
2
Equipped as an instrument
case
Equipped as a rack-mount
unit
note:
Corner trims, mounting flanges
and top and bottom covers
must be ordered separately.
Horizontal rail configuration
Horizontal rails for further
configuration must be ordered
separately, see page 100 – 101.
C
A
A
C
A
3U
ripac vario-module
installation width
(TE)
Width
(B1) mm
Width
(B2) mm
Depth
(T) mm
order no. vm Basic enclosure
also required
Top covers
– with vent holes
– without vent holes
Bottom covers
– with vent holes
– without vent holes
Front corner trims for assembly as
instrument case
Flanges for configuration
as rack-mount
– without handle holes
– with handle holes
accessories
Front/rear panels
Carrying handles
Front
Rear adjustable feet
1)
Only
Packs of
42
235.6
251.6
250.4
1
3982.040
3U
42
235.6
251.6
310.4
3982.070
Page
84
449.0
465.1
250.4
3982.060
63
342.3
358.3
250.4
3982.050
63
342.3
358.3
310.4
3982.080
84
449.0
465.1
310.4
3982.090
84
449.0
465.1
370.4
3982.100
1
1
1
1
2
3982.941
3982.901
3982.741
3982.701
3981.310
3982.951
3982.911
3982.751
3982.711
3981.310
3982.942
3982.902
3982.742
3982.702
3981.310
3982.952
3982.912
3982.752
3982.712
3981.310
3982.940
3982.900
3982.740
3982.700
3981.310
3982.950
3982.910
3982.750
3982.710
3981.310
3982.960
3982.920
3982.760
3982.720
3981.310
77
77
77
77
78
2
2
3981.210
3981.260
3981.210
3981.260
3981.210
3981.260
3981.210
3981.260
3981.210
3981.260
3981.210
3981.260
3981.210
3981.260
78
78
see page 135 – 150
2
2
4
3981.350
3636.010
3901.000
3981.360
3636.010
3901.000
3981.350
3636.010
3901.000
3981.360
3636.010
3901.000
3981.350
3636.010
3901.000
3981.360
3636.010
3901.000
3981.370
3636.010
3901.000
78
104
79
handles
1)
in conjunction with mounting flanges with handle holes.
accessories ripac vario-module
Page 77
riBox
Page 70
ricase
Page 80
73
