BAW56HMFHT116 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BAW56HMFHT116

BAW56HMFHT116: DescriptionHIGH RELIABILITY AND SMALL MOLD; CategoryDiscrete semiconductor diode; File Size1MB，9 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BAW56HMFHT116 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BAW56HMFHT116	-	-	View	Buy Now

BAW56HMFHT116 Overview

HIGH RELIABILITY AND SMALL MOLD

BAW56HMFHT116 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	R-PDSO-G3
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
Other features	HIGH RELIABILITY
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.25 V
JESD-30 code	R-PDSO-G3
Maximum non-repetitive peak forward current	4 A
Number of components	2
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	0.215 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power dissipation	0.25 W
Guideline	AEC-Q101
Maximum repetitive peak reverse voltage	100 V
Maximum reverse current	0.1 µA
Maximum reverse recovery time	4 µs
Reverse test voltage	80 V
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Base Number Matches	1

Preview

Download Datasheet

View All

BAW56HMFH

Switching Diode (High speed switching)

(AEC-Q101 qualified)

Data sheet

●

Outline

FSM

100

500

215

4000

●

Features

●

Inner Circuit

High reliability

Small mold type

●

Application

High speed switching

●

Structure

Epitaxial planar

●

Absolute Maximum Ratings

●

Packaging Specifications

Packing

Embossed T

ape

Reel Size(mm)

180

aping Width(mm)

Basic Ordering Unit(pcs)

3000

aping Code

T116

Marking

D8Y

Parameter

Repetitive peak reverse voltage

Reverse voltage

Power dissipation

Repetitive peak reverse forward current

Peak forward surge current

Forward current

Junction temperature

Storage temperature

※

Caution

：

static electricity

= 25ºC)

Symbol

FSM

stg

Conditions

≦

℃

Per diode

t=1μs

Per diode

Per device

Limits

100

250

500

4000

215

125

150

-65

150

Unit

℃

www.rohm.com

1/5

2018/04/11_Rev.003
