SERIES 35-1 PCB TAINER
MATERIALS TABLE
B
BH
CR
DIMENSION TABLE
BOARD
THICKNESS
DASH #
-1
-2
-3
-4
A
0.79 (.031)
1.59 (.063)
2.38 (.094)
3.18 (.125)
B
4.58 (.180)
4.58 (.180)
4.58 (.180)
4.58 (.180)
C MAX
8.39 (.330)
8.39 (.330)
8.39 (.330)
9.40 (.370)
9.15 (.360)
9.15 (.360)
9.15 (.360)
10.16 (.400)
D
7.57 (.298)
7.57 (.298)
7.57 (.298)
8.39 (.330)
E
3.97 (.156)
3.97 (.156)
3.97 (.156)
3.97 (.156)
FINISH TABLE
DASH #
-1
-2
-3
-4
-5
-6
-7
-8
NONE
Center Mounting Hole: __________________
None: _____________________________
Flared Entry: _______________________________
None: ________________________________
Material
___________________________
Board Thickness
59
_____________________
2
Length in
( ) increments __________________ 4 [
_________________________________________ to 12 [
Special Length ______________________________ 15 [
(
(
(
)]
)]
)]
Finish
________________________________________________
5
No dash number required for CR material. Stainless steel parts are
passivated only.
nVent may modify standard parts without prior notice to or approval from customers. These modifications may change product appearance, but will not have a
detrimental effect on form, fit or function. ©2018 nVent. All nVent marks and logos are owned or licensed by nVent Services GmbH or its affiliates. All other trademarks
are the property of their respective owners. nVent reserves the right to change specifications without notice.
