SmartSwarm 342
BB-SG30x series
Asset Integration Gateway
FEATURES & BENEFITS
+ Configurable user business logic data processing & display engine
+ Comprehensive data outputs via MQTT, email, SMS and a variety of other
services and database connections
+ Integrates data from Wzzard Mesh, WISE, ADAM & third party devices
+ Integrates data from internet feeds
+ Cellular or Ethernet connection to IIoT system
+ Acts as LAN to WAN bridge for third party device connection
+ Cellular (EMEA/NATAM support) and wired models available
ORDERING INFORMATION
MODEL NUMBER
DESCRIPTION
BB-SG30000520-42
2 Ethernet, Dust (no power supply)
BB-SG30000525-42
2 Ethernet, Dust, International Power Supply
BB-SG30300520-42
2 Ethernet, LTE-EMEA, Dust (no power supply)
BB-SG30300525-42
2 Ethernet, LTE-EMEA, Dust, International Power Supply
BB-SG30500520-42
2 Ethernet, LTE-NATAM, Dust (no power supply)
Seamlessly integrate data from diverse systems, devices and
sensors into the Industrial Internet of Things
The SmartSwarm 342 IIoT gateway is aimed at owners and operators of
remote assets wishing to integrate data from the asset into IIoT applications
such as dashboarding, analytics or predictive maintenance.
Data can be collected from a number of sources, including web feeds,
databases and files, as well as from locally connected physical devices and
sensors. SmartSwarm 342 also includes an interface and manager for B+B
SmartWorx Wzzard wireless sensor platform providing robust acquisition
and transmission of asset sensor data without the expense or time involved
in installing cables. For bulk I/O requirements where cabling is not an issue,
it is also compatible with WISE and ADAM Ethernet connected I/O modules.
USER APPLICATIONS -
SmartSwarm 342 offers flexible data acquisition,
processing and handoff via an inbuilt Node-RED user applications
environment. Node-RED is a powerful, yet simple to use, applications
programming environment optimized for processing data streams. Users
drag and drop function nodes to acquire, process and output data, via an
internal web server interface provided by the SmartSwarm 342. Crucially,
the Node-RED environment is containerized, meaning that any user
error made in programming cannot crash the gateway, which will remain
connected and available for remote management in order to correct the
error without the expense of a site visit.
In addition to offering local data processing, the Node-RED environment is
also able to create and serve local dashboards, providing a mechanism to
serve summary data to engineers, managers or operational staff.
CONNECTIVITY AND SECURITY -
SmartSwarm 342 connects to
enterprise applications either via a local Ethernet WAN, or wirelessly via an
internal cellular modem, and includes the ability to switch between these
connections for redundancy purposes. In addition, the gateway provides
a second Ethernet port intended to provide a local LAN connection, and
bridges traffic from this LAN to its active WAN connection. As such it may
be used as a cellular modem to allow any local Ethernet enabled device
to obtain an outbound WAN connection. All inbound WAN connections
are prohibited by default via an internal firewall and all enterprise
communications can be via VPN with device authentication and message
encryption, significantly increasing the security of the device.
CONFIGURATION -
Configuration is achieved via the SmartWorx
Hub remote configuration management tool that provides access to all
configurable parameters and allows the download of additional Node-RED
nodes to enrich the base installed palette without the need to visit the site.
NodeRED - easy drag and drop configuration
NodeRED - at-a-glance dashboards
SmartSwarm342_0318ds.indd
All product specifications are subject to change without notice.
www.advantech-bb.com
/
Enabling an Intelligent Planet
SmartSwarm 342
BB-SG30x series
SPECIFICATIONS
Asset Integration Gateway
CELLULAR MODULE PARAMETERS
SG303 series - EMEA
LTE
Bit rate 100 Mbps (DL) / 50 Mbps (UL)
Supported frequencies:
800/900/1800/2100/2600 MHz
Bit rate 42.0 Mbps (DL) / 5.76 Mbps (UL)
Supported frequencies:
900/1800/2100 MHz
Bit rate 237 kbps (DL) / 59.2 kbps (UL)
Supported frequencies:
900/1800 MHz
SG305 series - NATAM
Bit rate 100 Mbps (DL) / 50 Mbps (UL)
Supported frequencies:
700/700/850/AWS (1700/2100)/1900 MHz
Bit rate 42.0 Mbps (DL) / 5.76 Mbps (UL)
Supported frequencies:
850/AWS (1700/2100)/1900 MHz
Bit rate 236 kbps (DL) / 59.2 kbps (UL)
Supported frequencies:
850/900/1800/1900 MHz
POWER
*Optional - Power Supply
Power Consumption
ENVIRONMENTAL
Temperature Range
Temperature Range LTE450
Humidity
Cold Start
Operating Altitude
Ingress Protection Rating
MECHANICAL
100 m
300 m
1200 m
-93 dBm
-95 dBm
8 dBm
0 dBm
Metal case with metal DIN rail
Dimensions
Weight
Radio for general
LTE
Emissions/
Immunity
Safety
Vehicle
Environmental
55 x 97 x 125 mm
375 g
ETSI EN 301 511 v9.0.2, ETSI EN 301 908–1 v5.2.1,
ETSI EN 301 908-2 v5.2.1, ETSI EN 301 908-13 v5.2.1
IEC 61000-6-2:2005, ETSI EN 301 489-1 v1.9.2,
EN 55022:2010
EN 60950-1:06 ed.2 (not Hazardous Locations),
EN 62311:2008
E8
RoHS, RoHS2, REACH, WEEE
Operating: -40 to +75 °C
Storage: -40 to +85 °C
Operating: -20 to +60 °C
Storage: -40 to +85 °C
Operating: 0 to 95 %
Storage (Non-condensing): 0 to 95 %
-35 °C
2000 m / 70 kPa
IP30
10 – 60 VDC (2–way Molex connector)
Idle: 2.5 W
Average: 4 W
Peak: 11 W
Sleep Mode: 10mW
WCDMA
GPRS/EDGE
WZZARD RADIO - 802.15.4E, 2.4 GHZ
Number of Channels
Channel Separation
Channel Clear Frequency
Modulation
Raw Data Rate
Range (25
°C,
50% RH,
+2 dBi omni-directional
antenna, antenna 2m)
Receiver Sensitivity
Receiver Sensitivity
Output Power (delivered
to a 50 Ω load)
(2) Ethernet Ports
SIM
LED Indicators
Wzzard
RST
*Optional - 3x ANT - ANT,
DIV
SD
(USB)
15
5 MHz
2405 + 5* (k-11) MHz
IEEE 802.15.4 Direct Sequence Spread Spectrum (DSSS)
250 kbps
Indoor
Outdoor
Free Space
Packet Data Error Rate
(PER) = 1%
Packet Data Error Rate
(PER) = 50%
High Calibration Setting
Low Calibration Setting
RJ45, 10/100 Mbps
(2) Mini SIM, 2FF, 1 supported (rear panel)
PWR, DAT, WAN, ETH, SIM, USR, POE, IN0, IN1, OUT
R-SMA connector
RESET button (rear panel)
SMA connectors
Available for file storage from Node-RED applications
(currently unsupported)
* Optional items sold separately.
INDUSTRY CERTIFICATIONS & APPROVALS
PORTS, LEDS, ANTENNAS
