ADVANCED ENGINEERING
Technical Data Sheet
G EN E R A L P U R P OS E
Tec hni c a l D a ta S h e e t
Put-Ups
High Coverage, Self-Wrapping
Design
Easy, Cost Effective
Installation
More Flexible than Split
Convoluted or Spiral Wrap
Ideal For Protecting
Components Without
Disconnecting Them
Melt Temp. 482°F
Nominal
Size
1/8”
3/16”
1/4”
5/16”
3/8”
1/2”
5/8”
3/4”
1”
1 1/2”
1 3/4”
2”
Part
#
F6W0.13
F6W0.19
F6W0.25
F6W0.31
F6W0.38
F6W0.50
F6W0.63
F6W0.75
F6W1.00
F6W1.50
F6W1.75
F6W2.00
Wall
Thickness
.027”
.027”
.027”
.027”
.027”
.027”
.027”
.027”
.027”
.027”
.027”
.027”
Standard Put-Ups
Bulk
1,800’
1,200’
925’
650’
450’
300’
250’
150’
100’
50’
50’
40’
A
900’
600’
450’
325’
225’
150’
125’
100’
75’
25’
10’
10’
B
300’
200’
200’
125’
100’
75’
75’
50’
50’
50'
-
-
Available
Colors
BK,
BK,
BK,
BK,
BK,
BK,
BK,
BK,
BK,
BK,
BK,
BK,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
WH,
CB
CB
CB
CB
CB
CB
CB
CB
CB
CB
CB
CB
Overlap
*A
40%
51%
44%
40%
41%
35%
30%
28%
26%
23%
23%
23%
Lbs/
100’
0.57
0.98
1.10
1.30
1.50
1.80
2.10
2.40
3.20
4.50
5.00
6.00
Woven, Split Tubular Harness Wrap
Woven Wrap has been engineered from the ground up
to meet the demanding specifications of today’s modern
wiring harness industry.
F6-WW utilizes many of the same characteristics
as our original F6 split braided sleeving including
the easy wrap around design and the extra
overlap to insure complete protection of
important electronic communication and
power systems.
Cut Cleanly
Hot Knife
Material
PET Polyethylene Terepthalate
Black (BK), White
(WH), & Carbon (CB).
Colors Available:
The new woven construction provides superior elastic
flexibility with unbeatable coverage over any harness
assembly. Through a unique process, the blend of
monofilament and multifilament polyester fibers are
formed into a sleeving with memory that causes the
sleeve to self-close, and also snap back when opened.
Wire harness professionals will also appreciate the
increased abrasion resistance F6-WW will provide to
their cable assemblies.
Colors Available:
Hook & Loop
Width
Grade
F6W
Filament Diameter
.009” Monofilament Polyester
1200 Denier Multifilament
Drawing Number
TF001FWPT-WD
Black (BK), White (WH), & Carbon (CB).
Nominal Diameter
The Right Overlap
For Your Harness
800.323.5140 • 973.300.9242 • fax: 973.300.9409
104 Demarest Road • Sparta, NJ 07871
www.techflex.com
*A
The engineered overlap allows ideal
flexibility without exposing wires and cables.
GEN E RAL PU RPOSE
ADVANCED ENGINEERING
Tech n i cal Data Shee t
Technical Data Sheet
Melt Point
ABRASION
Abrasion Resistance
FLAMMABILITY
Rating _____________________UL94VO
482°F (250°C)
Maximum Continuous
257°F (125°C)
Minimum Continuous
-94°F (-70°C)
Mil-I-23053
www.techflex.com
ASTM D-2117
Low
Abrasion Test Machine
Taber 5150
Abrasion Test Wheel
Calibrase H-18
500g
72°F
78%
Abrasion Test Load
Room Temperature
Humidity
Moderate Scuffing Visible
CHEMICAL
RESISTANCE
1=No Effect
2=Little Effect
3=Affected
4=More Affected
5=Severely Affected
PHYSICAL
PROPERTIES
Filament Diameter: ________________
Monofilament Polyester _______ .009
MultiFilament
_________
1200 Denier
Recommended Cutting _____Hot Knife
Colors _________________________ 3
Wall Thickness_________________ .027
Tensile Strength _______________6-10
Specific Gravity ________________ 1.38
Moisture Absorption% __________ .1-.2
Hard Vacuum Data ________________
ASTM E-595 at 10-5 torr
TML (%) _______________________ .19
CVCM (%) _____________________ .00
WVR (%) ______________________ .16
125 Test Cycles
Significant Scuffing;
Braid Separated
Approx. 20%
225 Test Cycles
300 Test Cycles
Pre-Test Weight
Braid Begins to Break;
Material Destroyed
9,736.4 mg
9,328.6 mg
407.8 mg
Post-Test Weight
Test End Loss Of Mass
Point Of Destruction
Aromatic Solvents ________________ 2
Aliphatic Solvents _________________ 1
Chlorinated Solvents ______________ 3
Weak Bases ______________________ 1
Salts ____________________________ 1
Strong Bases _____________________ 2
Salt Water
0-S-1926
________________ 1
Hydraulic Fluid
MIL-H-5606
_________ 1
Lube Oil
MIL-L-7808
________________ 1
De-Icing Fluid
MIL-A-8243
__________ 1
Strong Acids _____________________ 3
Strong Oxidants __________________ 2
Esters/Ketones ___________________ 1
UV Light ________________________ 1
Petroleum _______________________ 1
Fungus
ASTM G-21
________________ 1
Halogen Free ___________________ Yes
RoHS __________________________ Yes
SVHC ________________________ None
© 2017 Techflex, Inc. - Any unauthorized reproduction, in whole or part, in any medium whatsoever, without the express written permission of Techflex, Inc. is strictly forbidden.
Techflex product names and logos are registered trademarks of Techflex, Inc., unless otherwise attributed. The contents and illustrations contained herein are believed to be reliable.
Techflex makes no warranties as to their accuracy or completeness and disclaims any liability in connection with their use. Techflex’s only obligations are those in standard terms of
sale for these products and Techflex will not be liable for any consequential or other damages arising due to misuse of these products or typographical errors or omissions.
08-17
Users should make their own evaluation to determine the suitability of these products for their unique and specific applications.
