FEATURES
APPLICATIONS
Small size
-
High Temperature
–
Lead Free Leads
Bypass
–
Coupling
–
Filtering
–
De-coupling
-40°C to +125°C
+20% at 120 Hz, 20°C
35
50
44
63
35
50
.17
.14
2 Minutes
.01CV or 3uA,Whichever is greater
35
50
3
3
4
4
Operating Temperature Range
Capacitance Tolerance
WVDC
Surge voltage
SVDC
WVDC
Dissipation Factor
tan δ
Leakage current
Low temperature
stability
Impedance ratio
(120 Hz)
Rated WVDC
-25°C to +20°C
-40°C to +20°C
10
13
10
.30
16
20
16
.24
25
32
25
.2
10
6
12
16
5
8
25
4
6
Load Life
Shelf Life
Resistance to soldering heat
1000 hours (1500 hours for 8, 10mm) at 125°C with rated WVDC
Capacitance change
<30% of initial measured value
Dissipation factor
<300% of maximum specified value
Leakage current
<100% of maximum specified value
1000 hours at 125°C with no voltage applied
(Rated WVDC applied for 30 minutes prior to measuring)
Capacitance change
<30% of initial measured value
Dissipation factor
<300% of maximum specified value
Leakage current
<100% of maximum specified value
Capacitors placed on a 250°C hot plate for 30 seconds with their electrode
terminations facing downward will fulfill the following conditions after being cooled to
room temperature
Capacitance change
<10% of initial measured value
Dissipation factor
<100% of maximum specified value
Leakage current
<100% of maximum specified value
Ripple Current Multipliers
50
.85
Frequency (Hz)
120
300
1k
1
1.17
1.36
10k
1.5
D+0.5
6.3
8
10
L
7.7
+/-0.3
10.5
+/-0.5
10.5
+/-0.5
W+0.2
6.6
8.3
1.03
H+0.2
6.6
8.3
10.3
C+0.2
7.3
9
11
R
0.5~0.8
0.8~1.1
0.8~1.1
LL+0.2
2.4
2.9
3.2
S+0.2
2.2
3.1
4.5
