ESDSLC3V3LB
Features
•
•
•
•
•
Ultra low capacitance: 0.25pF typical
Ultra low operating voltage: 3.3V
Low clamping voltage
IEC61000−4−4
(EFT) 40A (5/50ns)
IEC61000-4-5(Lightning)
5A
(8/20us)
ESD Protection
Device
DFN1006-2
A
C
B
D
•
•
•
•
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen free available upon request by adding suffix "-HF"
Marking:3L
Junction
Temperature: -55°C to +125°C
StorageTemperature: -55°C to +150°C
Symbol
Contact
Air
Limits
f
25
f
20
unit
KV
E
Maximum Ratings
•
•
Parameter
IEC61000-4-2(ESD)
V
ESD
P
pk
I
pp
-
Peak Pulse Power (8/20us)
Peak Pulse Current (8/20us)
100
5
W
A
G
F
H
H
-
Circuit and Pin Schematic
1
L
DIM
A
B
C
D
E
F
G
H
L
2
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
0.018
0.022
0.45
0.55
0.000
0.002
0.00
0.05
0.005
0.007
0.12
0.18
0.037
0.041
0.95
1.05
0.022
0.026
0.55
0.65
0.026 REF.
0.650 REF.
0.45
0.55
0.018
0.022
0.07
0.17
0.003
0.007
0.008
0.012
0.20
0.30
NOTE
Suggested Solder
Pad Layout
╋
0.8
0.3
╋
0.5
1.3
(mm)
0.6
www.mccsemi.com
Revision:B
1 of
4
2017/02/23
MCC
Micro Commercial Components
R
Electrical Characteristics (T
A
=25°C unless otherwise specified)
Parameter
Reverse Working Voltage
Breakdown Voltage
Reverse Leakage Current
Clamping Voltage
Clamping Voltage
Junction Capacitance
Symbol
V
RWM
V
BR
I
R
V
C
V
C
C
J
Min
Typ
Max
3.3
Unit
V
V
Test Condition
5
0.05
10
20
0.25
0.3
I
T
= 1mA
V
RWM
= 3.3V
I
PP
= 1A (8 x 20µs pulse)
I
PP
= 5A (8 x 20µs pulse)
VR = 0V, f = 1MHz
uA
V
V
pF
Typical Performance Characteristics (TA=25°C unless otherwise Specified)
Juncxtion Capacitance_Cj (pF)
0.5
0.4
0.3
0.2
0.1
0.0
0
1
2
3
4
5
Reverse Voltage_VR (V)
Junction Capacitance vs. Reverse Voltage
www.mccsemi.com
Revision:
B
2
of
4
2017/02/23
MCC
Micro Commercial Components
R
Typical Performance Characteristics (T
A
=25°C unless otherwise Specified)
25
120
Clamping Voltage_Vc (V)
20
15
10
100
% of Rated Power
0
1
2
3
4
5
Peak Pulse Current_Ipp (A)
6
80
60
40
20
0
5
0
0
25
50
75
100 125
Ambient Temperature_Ta(℃)
150
Clamping Voltage vs. Peak Pulse Current
100
90
% of Peak Pulse Current
80
70
60
50
40
Power Derating Curve
30
20
10
0
0
40
60
Time_t(uS)
8 X 20uS Pulse Waveform
20
80
ESD Clamping Voltage
8 kV Contact per IEC61000−4−2
www.mccsemi.com
Revision:
B
3
of
4
2017/02/23
MCC
Micro Commercial Components
R
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
10Kpcs/Reel
