74AUP1G57
CONFIGURABLE MULTIPLE-FUNCTION GATE
Description
The 74AUP1G57 is a single, 3-input positive configurable multiple
function gate with a standard push-pull output. The output state is
determined by eight patterns of 3-bit input. The user can chose the
logic functions AND, OR, NAND, NOR, XNOR, inverter or non-
inverting buffer. All inputs can be connected to ground or Vcc as
required.
The device is designed for operation with a power supply range of
0.8V to 3.6V.
The inputs are tolerant to 3.6V allowing this device to be used in a
mixed voltage environment.
The device is fully specified for partial power down applications using
IOFF. The IOFF circuitry disables the output preventing damaging
current backflow when the device is powered down. The user is
reminded that the device can simulate several types of logic gates but
may respond differently due to the Schmitt action at the inputs.
Pin Assignments
(Top View)
(Top View)
B
1
GND
2
6
C
5
Vcc
4
Y
B
1
GND
2
A
3
6
5
4
C
Vcc
Y
X2-DFN1410 -6
A
3
SOT26
(Top View)
B
1
GND
2
A
3
SOT363
6
C
5
Vcc
4
Y
NEW PRODUCT
(Top View)
B
GND
A
1
2
3
6
5
4
C
Vcc
Y
X2-DFN1010-6
(Top View)
6
B
1
C
2
Product
5
Vcc
GND
Future
3
4
Y
A
X2-DFN0910-6
Features
Advanced Ultra Low-Power (AUP) CMOS
Supply Voltage Range from 0.8V to 3.6V
±4mA Output Drive at 3.0V
Low Static Power Consumption
I
C
< 0.9µA
Low Dynamic Power Consumption
C
PD
= 4.8pF Typical at 3.6V
Schmitt Trigger Action at all inputs makes the circuit tolerant for
slower input rise and fall time. The hysteresis is typically 950mV
at V
CC
= 3.0V.
I
OFF
Supports Partial-Power-Down Mode Operation
ESD Protection per JESD 22
Exceeds 200-V Machine Model (A115)
Exceeds 2000-V Human Body Model (A114)
Exceeds 1000-V Charged Device Model (C101)
Latch-Up Exceeds 100mA per JESD 78, Class I
Standard SOT26 and SOT363 Packages
Leadless Packages per JESD30E
DFN1410 denoted as X2-DFN1410-6
DFN1010 denoted as X2-DFN1010-6
DFN0910 denoted as X2-DFN0910-6
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Applications
Suited for Battery and Low-Power Needs
Voltage Level Shifting
General Purpose Logic
Power Down Signal Isolation
Wide array of products such as:
PCs, Networking, Notebooks, Netbooks, PDAs
Tablet Computers, E-readers
Computer Peripherals, Hard Drives, CD/DVD ROMs
TVs, DVDs, DVRs, Set-Top Boxes
Cell Phones, Personal Navigation / GPS
MP3 players ,Cameras, Video Recorders
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free,
"Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
and <1000ppm antimony compounds.
74AUP1G57
Document number: DS36852 Rev. 1 - 2
1 of 16
www.diodes.com
June 2015
© Diodes Incorporated
74AUP1G57
Logic Configurations
Vcc
B
Y
C
B
1
2
3
B
Y
C
Configuration 1
2-Input AND Gate
2-Input NOR Gate with Both Inputs Inverted
6
5
4
Y
B
Y
C
Configuration 2
2-Input NAND Gate with B Input Inverted
2-Input OR Gate with C input Inverted
B
Y
C
Vcc
C
B
1
2
3
6
5
4
C
Y
NEW PRODUCT
Vcc
A
Y
C
1
2
A
A
Y
C
Configuration 3
2-Input NAND Gate with C Input Inverted
2-Input OR Gate with A Input Inverted
Vcc
A
Vcc
6
5
4
C
Y
C
1
2
6
5
4
C
3
Y
A
A
Y
C
3
Y
Configuration 4
2-Input NOR Gate
2-Input AND Gate with Both Inputs Inverted
Vcc
AB
Y
C
AB
1
2
3
6
5
4
C
A
Y
A
1
2
3
6
5
4
Y
Y
Configuration 5
2-Input XNOR Gate
Configuration 6
Inverter
Function Selection Table
Logic Function
2-Input AND
2-Input AND with both inputs inverted
2-Input NAND with inverted input
2-Input OR with inverted input
2-Input NOR
2-Input NOR with both inputs inverted
2-Input XNOR
1-Input INVERTER
Configuration
1
4
2, 3
2, 3
4
1
5
6
74AUP1G57
Document number: DS36852 Rev. 1 - 2
3 of 16
www.diodes.com
June 2015
© Diodes Incorporated
74AUP1G57
Absolute Maximum Ratings
(Notes 6 & 7)
Symbol
ESD HBM
ESD CDM
ESD MM
V
CC
V
I
V
o
I
IK
I
OK
Description
Human Body Model ESD Protection
Charged Device Model ESD Protection
Machine Model ESD Protection
Supply Voltage Range
Input Voltage Range
Voltage applied to output in high or low state
Input Clamp Current V
I
<0
Output Clamp Current (V
O
< 0 )
Continuous Output Current (V
O
= 0 to V
CC
)
Continuous Current through V
CC
Continuous Current through GND
Operating Junction Temperature
Storage Temperature
Rating
2
1
200
-0.5 to +4.6
-0.5 to +4.6
-0.5 to V
CC
+0.5
-50
-50
±20
50
-50
-40 to +150
-65 to +150
Unit
kV
kV
V
V
V
V
mA
mA
mA
mA
mA
°C
°C
NEW PRODUCT
I
O
I
CC
I
GND
T
J
T
STG
Notes:
6. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device
operation should be within recommend values.
7. Forcing the maximum allowed voltage could cause a condition exceeding the maximum current or conversely forcing the maximum current could
cause a condition exceeding the maximum voltage. The ratings of both current and voltage must be maintained within the controlled range.
Recommended Operating Conditions
(Note 8)
Symbol
V
CC
V
I
V
O
Operating Voltage
Input Voltage
Output Voltage
Active Mode
Power Down Mode
V
CC
= 0.8 V
V
CC
= 1.1 V
I
OH
High-Level Output Current
V
CC
= 1.4 V
V
CC
= 1.65 V
V
CC
= 2.3 V
V
CC
= 3.0 V
V
CC
= 0.8 V
V
CC
= 1.1 V
I
OL
Low-Level Output Current
V
CC
= 1.4 V
V
CC
= 1.65 V
V
CC
= 2.3 V
V
CC
= 3.0 V
T
A
Note:
Parameter
-
Min
0.8
0
0
0
-
-
-
-
-
-
-
-
-
-
-
-
-40
Max
3.6
3.6
V
CC
3.6
-20
-1.1
-1.7
-1.9
-3.1
-4
20
1.1
1.7
1.9
3.1
4
+125
Unit
V
V
V
V
µA
mA
uA
mA
Operating Free-Air Temperature -
°C
8. Unused inputs should be held at Vcc or Ground.
74AUP1G57
Document number: DS36852 Rev. 1 - 2
4 of 16
www.diodes.com
June 2015
© Diodes Incorporated
