2SA1873
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT process)
2SA1873
Audio Frequency General Purpose Amplifier Applications
•
•
•
•
•
Small package (dual type)
High voltage and high current: V
CEO
=
−50
V, I
C
=
−150
mA (max)
High h
FE
Excellent h
FE
linearity: h
FE
(I
C
=
−0.1
mA)/h
FE
(I
C
=
−2
mA)
= 0.95 (typ.)
Complementary to 2SC4944
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C) (Q1, Q2 common)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
(Note 1)
T
j
T
stg
Rating
−50
−50
−5
−150
−30
200
125
−55
to 125
Unit
V
V
V
mA
mA
mW
°C
°C
JEDEC
―
JEITA
―
Using continuously under heavy loads (e.g. the application of
TOSHIBA
2-2L1A
high temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
Weight: 6.2 mg (typ.)
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the
absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Total rating
Note:
Marking
Equivalent Circuit
(top view)
Electrical Characteristics
(Ta
=
25°C) (Q1, Q2 common)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Transition frequency
Collector output capacitance
Symbol
I
CBO
I
EBO
Test Condition
V
CB
= −50
V, I
E
=
0
V
EB
= −5
V, I
C
=
0
Min
⎯
⎯
120
⎯
80
⎯
Typ.
⎯
⎯
⎯
−0.1
⎯
4
Max
−0.1
−0.1
400
−0.3
⎯
7
V
MHz
pF
Unit
μA
μA
h
FE
V
= −6
V, I
C
= −2
mA
(Note)
CE
V
CE (sat)
f
T
C
ob
I
C
= −100
mA, I
B
= −10
mA
V
CE
= −10
V, I
C
= −1
mA
V
CB
= −10
V, I
E
=
0, f
=
1 MHz
Note 2: h
FE
classification Y (Y): 120 to 240, GR (G): 200 to 400
( ) marking symbol
Start of commercial production
1992-07
1
2014-03-01
2SA1873
