DA01S Series
1W DC/DC CONVERTER, DIP-Package, High Isolation
FEATURES
Efficiency up to 79%
DIP Package with Industry Standard Pinout
High Isolation Voltage 3000VDC
Temperature Performance -40℃ to +75℃
> 2MHours MTBF
Internal SMD platform
Lead free, RoHs Compliant
12 Standard Models
3 Years Product Warranty
The DA01S series are miniature, DIP Package, isolated 1W DC/DC converters with 3,000VDC isolation. It allows a wide
operating temperature range of –40°C to +75°C. These isolated DC/DC converters are the latest offering from a world leader in
power systems technology and manufacturing ― Delta Electronics, Inc. With creative design technology and optimization of
component placement, these converters possess outstanding electrical and thermal performance, as well as extremely high reliability
under highly stressful operating conditions.
Model List
Model
Number
Input
Voltage
(Range)
VDC
DA01S0505A
DA01S0509A
5
DA01S0512A (4.5 ~ 5.5)
DA01S0515A
DA01S1205A
DA01S1209A
12
DA01S1212A (10.8 ~ 13.2)
DA01S1215A
DA01S2405A
DA01S2409A
24
(21.6 ~ 26.4)
DA01S2412A
DA01S2415A
Output
Voltage
Output Current
Input Current
Load
Regulation
Max. apacitive
Load
Efficiency
(typ.)
@Max.
Load
% (max.)
11
8
7
6
9
5
5
4
8
5
4
4
uF
%
69
76
77
78
71
77
79
79
70
76
79
79
Max.
VDC
5
9
12
15
5
9
12
15
5
9
12
15
mA
200
110
84
67
200
110
84
67
200
110
84
67
Min.
mA
4
2
1.5
1
4
2
1.5
1
4
2
1.5
1
@Max. Load @No Load
mA(typ.)
290
260
262
257
117
107
106
106
60
54
53
53
mA(typ.)
30
33
13
33
10
33
Input Characteristics
Parameter
Input Voltage Range
Model
5V Input Models
12V Input Models
24V Input Models
5V Input Models
Input Surge Voltage (1 sec. max.)
Reverse Polarity Input Current
Input Filter
Internal Power Dissipation
All Models
---
12V Input Models
24V Input Models
Min.
4.5
10.8
21.6
-0.7
-0.7
-0.7
---
Typ.
5
12
24
---
---
---
---
---
Max.
5.5
13.2
26.4
7
15
28
0.3
450
A
mW
VDC
Unit
Internal Capacitor
DS_DA01S_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Output Characteristics
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Temperature Coefficient
Short Circuit Protection
Over Line, Load & Temp.
For Vin Change of 1%
Io=20% to 100%
---
---
---
---
100
---
---
±0.01
Conditions
Min.
---
---
Typ.
±1.0
±1.2
+-11% max
150
200
15
±0.02
mV
P-P
mV
P-P
mV rms
%/℃
Max.
±3.0
±1.5
Unit
%
%
0.5 Second Max.
General Characteristics
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF (calculated)
MIL-HDBK-217F@25℃, Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Min.
3000
10
---
50
2,000,000
Typ.
---
---
60
90
---
Max.
---
---
100
110
---
Unit
VDC
GΩ
pF
KHz
Hours
Recommended Input Fuse
5V Input Models
500mA Slow-Blow Type
12V Input Models
200mA Slow-Blow Type
24V Input Models
100mA Slow-Blow Type
Environmental Characteristics
Parameter
Operating Temperature Range (with Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature (1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
Max.
-40
+85
---
+90
-50
+125
---
95
Free-Air convection
---
260
Unit
℃
℃
℃
% rel. H
℃
Power Derating Curve
Output Power (%)
(5V Output Only)
Output Power (%)
(All Other Output)
Notes
1
2
3
4
5
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will
not damage these modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
Specifications subject to change without notice.
DS_DA01S_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Package Specifications
Mechanical Dimensions
0.4 [0.02]
Pin Connections
Pin
1
L
Function
-Vin
+Vin
+Vout
-Vout
4
3.1
[0.12]
5
7
2.54
[0.10]
7.62 [0.30]
0.50
[0.02]
2.6
[0.10]
L=7.0 [0.28] for 5V & 12V Input Models
L=8.0 [0.31] for 24V Input Models
Bottom View
7
5
7.62 [0.30]
10.2 [0.40]
1
4
►
All dimensions in mm
(inches)
1.29
[0.05]
5.08
[0.20]
12.7 [0.50]
►
Tolerance: X.X±0.25
(X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
►
Pin
diameter
⇔
0.5 ±0.05 (0.02±0.002)
Physical Characteristics
Case Size
(5V&12V Input)
Case Size(24V Input)
Case Material
Weight(5V&12V Input)
Weight(24V Input)
:
:
:
:
:
12.7x7.0x10.2mm (0.50x0.28x0.40 Inches)
12.7x8.0x10.2mm (0.50x0.31x0.40 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
1.3g
1.7g
DS_DA01S_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Part Numbering System
D
Form factor
D-DIP
P-SIP
S-SMD
A
Family series
A~Z
01
Watt
01:1W
02:2W
03:3W
04:4W
06:6W
S
Number of
Outputs
S - Single
D- Dual
05
Input Voltage
03:3.3V
05: 5V
12:12V
24: 24V
48:48V
05
Output Voltage
03:3.3V
05: 5V
12:12V
15: 15V
24: 24V
A
Option Code
A - Std. Functions
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
