Fuse modular terminal block - UT 4-L/HESILA 250 (5X20) - 3214368
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Fuse modular terminal block, Connection method: Screw connection, Cross section: 0.14 mm²- 4 mm²,
AWG: 26 - 10, Nominal current: 30 A, Nominal voltage: 500 V, Width: 6.2 mm, Fuse type: G / 5 x 20, Fuse
type: Glass / ceramics / ..., Mounting type: NS 35/7,5, NS 35/15, Color: black
The figure shows the standard item
without light indicator
Key Commercial Data
Packing unit
Minimum order quantity
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 STK
50 STK
33.200 g
85369085
Poland
Technical data
Environmental Product Compliance
China RoHS
Hazardous substances above threshold values;
Environmentally Friendly Use Period = 50;
For details go to tab “Downloads”, Category “Manufacturer's declaration”
General
Note
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
The current is determined by the fuse used, the voltage by the selected
LED.
If the fuse is faulty, the downstream circuit will not be disconnected.
2
4
4 mm²
black
PA
09/01/2016 Page 1 / 20
https://www.phoenixcontact.com/us/products/3214368
Fuse modular terminal block - UT 4-L/HESILA 250 (5X20) - 3214368
Technical data
General
Flammability rating according to UL 94
Fuse
Fuse type
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation
LED voltage range
LED current range
Connection in acc. with standard
Maximum load current
Nominal current I
N
Nominal voltage U
N
Connection in acc. with standard
Maximum load current (upper level)
Nominal current I
N
(upper level)
Nominal voltage U
N
Open side panel
Relative insulation material temperature index (Elec., UL 746 B)
Static insulating material application in cold
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
V0
G / 5 x 20
Glass / ceramics / ...
6 kV
3
III
I
max. 1.6 W (With single arrangement of the fuse terminal block in the
event of overload)
110 V AC ... 250 V AC
0.41 mA ... 0.96 mA
IEC 60947-7-2/IEC 60947-7-3
36 A (the current is determined by the fuse used)
30 A
500 V
IEC 60947-7-2/IEC 60947-7-3
6.3 A (the current is determined by the fuse used)
6.3 A
250 V
No
130 °C
-60 °C
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 130 °C
Dimensions
09/01/2016 Page 2 / 20
https://www.phoenixcontact.com/us/products/3214368
Fuse modular terminal block - UT 4-L/HESILA 250 (5X20) - 3214368
Technical data
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
6.2 mm
92.7 mm
88.9 mm
96.4 mm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
0.14 mm²
4 mm²
0.14 mm²
4 mm²
26
10
0.14 mm²
4 mm²
0.14 mm²
4 mm²
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1.5 mm²
sleeve, max.
Connection method
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Screw connection
9 mm
A4
M3
0.6 Nm
0.8 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
IEC 60947-7-2/IEC 60947-7-3
IEC 60947-7-2/IEC 60947-7-3
V0
09/01/2016 Page 3 / 20
https://www.phoenixcontact.com/us/products/3214368
Fuse modular terminal block - UT 4-L/HESILA 250 (5X20) - 3214368
Drawings
Circuit diagram
Application
drawing
Fuse
terminal
blocks
in
interconne
arrangeme
block
consisting
of
5
fuse
terminal
blocks
Application
drawing
Fuse
terminal
block
in
single
arrangement,
block
consisting
of
one
fuse
terminal
block
and
4
feed-
through
terminal
blocks
Classifications
eCl@ss
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 8.0
eCl@ss 9.0
27141116
27141116
27141116
27141116
09/01/2016 Page 4 / 20
https://www.phoenixcontact.com/us/products/3214368
Fuse modular terminal block - UT 4-L/HESILA 250 (5X20) - 3214368
Classifications
ETIM
ETIM 4.0
ETIM 5.0
EC000899
EC000899
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / CSA / cULus Recognized
Ex Approvals
Approval details
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-10
16 A
300 V
C
26-10
16 A
300 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-10
16 A
300 V
C
26-10
16 A
300 V
CSA
http://www.csagroup.org/us/en/services/testing-and-certification/certified-product-listing 13631
B
26-10
16 A
C
26-10
16 A
09/01/2016 Page 5 / 20
