1
4
NOTES:
2
3
5
6
7
A
B
A
4
4
A
C
4
4
7
MATERIAL
1.Insulator Material:PBT+30%GF(UL94V-0)
2.Contact Material : Brass
3.Contact Plating :
AWP xx-7240-T : Gold flash over Ni
AWP xx-7540-T : Tin over Ni
8
AWP xx-7340-T : Selective 15u"Au on contact area ,Tin on
soldering area over Ni
ELECTRICAL
1.Current Rating : 3AMP
2.Withstand Voltage : 1000V AC/DC
3.Contact Resistance : 20mΩ max
4.Insulation Resistance: 1000MΩ min
ENVIRONMENTAL
1.Operation Temperature: -40°C to +105°C
2.Packing: Tray
6P Without Slot "M" and "N"
8P-12P With Slot "M" ,Without Slot "N"
14P-64P With Slot "M" and "N"
A
B
C
6
Wire Spec: AWG28
D
D
E
E
4
F
Scale
Free
8
TOLERANCE
X.X
5
7
Add the plating selective 15u"Au
Update drawing
07.09.2017
29.09.2015
Winnie
Jesse
Drawn
Date
25.01.2006
Section A-A
F
Name
Customer-No.
G
RoHS compliant
File No.: E198287
Alex
±0.40
X.XX
Angle
±0.25
6
Add wire spec
14.02.2014
Amy
Approved
07.09.2017
G
X.XXX ±0.15
5
Add the UL-File No
13.12.2013
Winnie
Winnie
ASSMANN WSW-No.
AWP xx-7x40-T
±
3°
4
3
Id.
Update
New p/n added
Modification
27.03.2013
21.12.2009
Date
Winnie
Dean
Name
Drawing-No.
H
1
2
ASS 1194C CO
rev08
H
3
4
5
Replace
Sheet
6
7
