MP35-060K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The power supply circuit> MP35-060K

MP35-060K: DescriptionAC-DC Regulated Power Supply Module, 3 Output, 5W, Hybrid,; CategoryThe power supply circuit; File Size851KB，2 Pages; ManufacturerSemiconductor Circuits Inc

Download Datasheet Parametric View All

MP35-060K Overview

AC-DC Regulated Power Supply Module, 3 Output, 5W, Hybrid,

MP35-060K Parametric

Parameter Name	Attribute value
Maker	Semiconductor Circuits Inc
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Other features	ADDITIONAL +/-15V OUTPUTS AVAILABLE
Analog Integrated Circuits - Other Types	AC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	252 V
Minimum input voltage	200 V
Nominal input voltage	220 V
JESD-30 code	R-XDMA-P7
Maximum grid adjustment rate	0.01%
Maximum load regulation	0.2%
Number of functions	1
Output times	3
Number of terminals	7
Maximum operating temperature	71 °C
Minimum operating temperature	-25 °C
Maximum output voltage	5.05 V
Minimum output voltage	4.95 V
Nominal output voltage	5 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Protect	CURRENT
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL EXTENDED
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum total power output	5 W
Fine-tuning/adjustable output	NO
Base Number Matches	1

Preview

Download Datasheet

View All

765432121098765432109876543210987654321

All specifications are typical at nominal line and full load at 25°C unless

otherwise noted and are subject to change without notice.

ENVIRONMENTAL

GENERAL

OUTPUT

INPUT

Operating Temperature

Storage Temperature

Cooling

Voltage Tolerance

Ripple and Noise (PARD)

Regulation

Line

Load

Short Circuit Protection

Temperature Coefficient

I/O Isolation

Suffix I

Voltage and Frequency

Standard

105 to 125 Vac - 50 to 440 Hz

Suffix I

200 to 252 Vac - 50 to 60 Hz

Suffix N

90 to 110 Vac - 50 to 60 Hz

Suffix K

200 to 252 Vac - 50 to 60 Hz

Suffix K2

105 to 125/210 to 250 Vac

MP Series

-25°C to +71°C No Derating

-25°C to +85°C

Free-air Convection

1500 Vac

2500 Vac

Current Limiting

0.02% / °C

0.2%

0.01%

± 1%

1mV RMS

Features include MTBF’s of greater

than 150,000 hours, lower case tem-

perature rise (to 18°C cooler) and the

high in-circuit performance. This

higher efficiency results in lower

ambient temperatures and greater

system reliability.

These economy priced triple output

supplies are ideal for those applications

where space (PC Board real estate) is

limited. Three outputs are available in

the area normally occupied by most

single or dual output encapsulated

modules.

he MP Series boast over a

decade of reliable, field proven

service and are the recognized

industry standard for high performance

AC/DC power supplies.

Triple Outputs

5 to 7 Watts

High performance design

Ultra-low noise

Continuous short circuit

protection
