AC/DC
5- 7 Watts
Triple Outputs
MP Series
High performace design
Ultra-low noise
Continuous short circuit
protection
Specifications
The
MP Series boast over a decade of
reliable, field proven service and are
the recognized industry standard for
high performance AC/DC power
supplies.
These economy priced triple output
supplies are ideal for those applications
where space (PC Board real estate) is
limited. Three outputs are available in
the area normally occupied by most
single or dual ouput encapsulated
modules.
Features include MTBF’s of greater
than 150,000 hours, lower case tem-
perature rise (to 18°C cooler) and the
high in-circuit performance. This
higher efficiency results in lower
ambient temperatures and greater
system reliability.
INPUT
Voltage and Frequency
Standard
Suffix I
Suffix N
Suffix K
Suffix K2
105 to 125 Vac - 50 to 440 Hz
200 to 252 Vac - 50 to 60 Hz
90 to 110 Vac - 50 to 60 Hz
200 to 252 Vac - 50 to 60 Hz
105 to 125/210 to 250 Vac
OUTPUT
Voltage Tolerance
Ripple and Noise (PARD)
Regulation
Line
Load
± 1%
1mV RMS
0.01%
0.2%
Current Limiting
0.02% / °C
Short Circuit Protection
Temperature Coefficient
GENERAL
I/O Isolation
Suffix I
1500 Vac
2500 Vac
ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Cooling
-25°C to +71°C-No Derating
-25°C to +85°C
Free-air Convection
All specifications are typical at nominal line and full load at 25°C unless otherwise noted and
are subject to change without notice.
MP Series Ordering Information
Output
Voltage
Output
Current
Case
Model
5 Vdc / ±12Vdc
5 Vdc / ±12Vdc
5 Vdc / ±15Vdc
5 Vdc / ±15Vdc
5 Vdc / ±15Vdc
300 mA / ±150mA
500 mA / ±100mA
300 mA / ±150mA
500 mA / ±100mA
750 mA / ±100mA
B
B
B
B
C
MP34-060
MP34-070
MP35-060
MP35-070
MP35-095
Dimensions and Connections
D
C
B
.88
(23)
.040 (1.01)
DIA. TYP.
1
1.0
(25.4)
.50
(12.7)
.50
(12.7)
3
4
C
L
5
6
2
1.60
(40.6)
3.50
(89)
BOTTOM VIEW
FIG. 1
A
1.25
(32)
1.56
(40)
2.00
(51)
.20 MIN.
(5.08)
2 MOUNTING INSERTS:
No. 4-40 X 0.10 Dp. Min.
C
L
.55
(14)
.55
(14)
.55
(14)
.55
(14)
2.50
(64)
1.0
(25.4)
PIN CONNECTIONS
1. AC in high
2. AC in neutral
3. Common Out*
4. + 5 Vdc Out
5. - Vdc Out
6. Common Out*
7. + Vdc Out
* Pins 3 and 6 are
Internally Connected
7
1.60
(40.6)
NOTES:
1. Ripple measured with a 3.3 mf tantalum capacitor
across each output.
7/27/99
All specifications are typical at nominal line and full load at 25°C unless otherwise noted and
are subject to change without notice.
49 Range Road
Windham, NH 03087
(603) 893-2330
FAX (603) 893-6280
