2SC4115S-Q
2SC4115S-R
2SC4115S-S
NPN
Plastic-Encapsulate
Transistors
•
•
•
Features
•
•
•
•
•
Electrical Characteristics @ 25
Symbol
V
CEO
V
CBO
V
EBO
I
CBO
I
EBO
h
FE
V
CE(sat)
f
T
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Power dissipation: P
CM
= 0.3W(T
amb
=25 )
Collector current: I
CM
= 3A
Collector-base voltage: V
(BR)CBO
= 40V
Operating and storage junction temperature range
T
J
, T
stg
: -55 to + 150
Halogen
free available upon request by adding suffix "-HF"
Parameter
Collector-Emitter Voltage
(I
C
=-50A, I
E
=0)
Collector-Base Voltage
(I
C
=-1A, I
B
=0)
Emitter-Base Voltage
(I
E
=-50A, I
C
=0)
Collector cut-off Current
(V
CB
=-20V, I
E
=0)
Emitter cut-off Current
(V
EB
=-5V, I
C
=0)
DC current gain
(V
CE
=-2V, I
C
=-0.1A)
Collector-Emitter Saturation Voltage
(I
C
=-2A, I
B
=-0.1A)
Transition Frequency
(V
CE
=2.0Vdc, I
C
=0.5Adc)
Min
20
40
6.0
---
---
120
---
200
Typ
---
---
---
---
---
---
---
---
TO-92S
B
Unit
V
Unless Otherwise Specified
Max
---
---
---
0.1
0.1
560
0.5
---
C
V
V
A
A
---
V
MHz
1. EMITTER
2. COLLECTOR
3. BASE
Measured Using Pulse Current
CLASSIFICATION OF h
FE
Rank
Range
Marking
Q
120-270
C4115
R
180-390
C4115
S
270-560
C4115
1
1
2
3
2
D
E
3
STRAIGHT LEAD BENT LEAD
BULK PACK
AMMO PACK
DIMENSIONS
DIM
A
B
C
INCHES
MIN
MAX
.056
.064
.154
.161
.120
.128
MM
MIN
1.42
3.90
3.05
MAX
1.62
4.10
3.25
NOTE
.050
1.27
Straight Lead
.086
.110
2.20
2.80
Bent Lead
.096
.104
2.44
2.64
Straight Lead
E
.173
.220
4.40
5.60
Bent Lead
L
.594
.610
15.10
15.50
* For ammo packing detailed specification, click here to visit our website
of product packaging for details.
D
www.mccsemi.com
Revision:
D
1 of 2
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-AP-HF
Packing
Ammo Packing:
30Kpcs/Carton
Bulk:
100Kpcs/Carton
