Europe connectors - EC 10 TR - 3240178
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Polyamide Europe terminal strip, transparent, for connecting solid conductors and stranded conductors with
ferrules with a cross section of 1 to 10 mm²
Key commercial data
Packing unit
Minimum order quantity
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 pc
10 pc
44.48 GRM
85369010
Austria
Technical data
General
Number of levels
Number of connections
Color
Insulating material
Inflammability class according to UL 94
Maximum load current (lower level)
Nominal current I
N
(lower level)
Nominal voltage U
N
Maximum load current (upper level)
Number of positions
1
24
transparent
PA
V2
57 A (with 10 mm² conductor cross section)
57 A (with 10 mm² conductor cross section)
450 V
57 A (with 10 mm² conductor cross section)
12
Dimensions
Width
Length
Height
22.2 mm
132.7 mm
17.3 mm
Connection data
Connection method
Screw connection
11/04/2014 Page 1 / 4
https://www.phoenixcontact.com/us/products/3240178
Europe connectors - EC 10 TR - 3240178
Technical data
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded min.
Conductor cross section stranded max.
Min. AWG conductor cross section, stranded
Max. AWG conductor cross section, stranded
Conductor cross section stranded, with ferrule without plastic sleeve min.
Conductor cross section stranded, with ferrule without plastic sleeve max.
Conductor cross section stranded, with ferrule with plastic sleeve min.
Conductor cross section stranded, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
1 mm²
10 mm²
16
8
1 mm²
10 mm²
16
8
0.75 mm²
4 mm²
0.75 mm²
4 mm²
0.75 mm²
2.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1 mm²
sleeve, max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
Stripping length
Screw thread
Tightening torque, min
Tightening torque max
0.75 mm²
1.5 mm²
7 mm
M3,5
0.8 Nm
1 Nm
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
27141106
27141106
27141106
27141106
27141106
27141106
27141106
11/04/2014 Page 2 / 4
https://www.phoenixcontact.com/us/products/3240178
Europe connectors - EC 10 TR - 3240178
Approvals
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
14-8
50 A
300 V
C
14-8
50 A
300 V
D
14-8
50 A
300 V
cULus Recognized
Phoenix Contact 2014 © - all rights reserved
http://www.phoenixcontact.com
11/04/2014 Page 4 / 4
