PART NUMBER BREAKDOWN
UT
YO
ER
AT
IN
G
IX
IS
H
LO
R
MB
EF
LA
PR
IN
CO
NU
PL
2
0
C
o
m
A
S
o
H
ant
R
U
1
1
/
6
5
/
E
t
r
a
l
i
a
A
(72.0)
CT
ER
LF
ES
NT
A
VE
IN
ND
EL
EE
RI
MA
CO
IN
B
AX 3 F B 1 M 018 -AU
SERIES PREFIX
SERIES PREFIX
AX
3 = 3 CONTACTS
4 = 4 CONTACTS
5 = 5 CONTACTS
F = FEMALE SOCKET CONTACTS
M = MALE PIN CONTACTS
B
= BLACK COATING FINISH
BLANK = NICKEL PLATED FINISH
0
1
2
3
4
=
=
=
=
=
BLACK
BROWN
RED
ORANGE
YELLOW
5
6
7
8
9
=
=
=
=
=
GREEN
BLUE
VIOLET
GREY
WHITE
MALE CONNECTOR
1:1
CO
SH
GE
SL
PR
SE
NT
A
RK
T
CT
G
B
18.9
Ø 21.2
C
GENDER
SHELL FINISH
21.6
C
SLEEVE COLOR
(72)
D
MARKING
PRINT NUMBER
M
= MARKING
BLANK = NO MARKING
FROM 01 TO 99
AU
= GOLD PLATED
BLANK = STANDARD PLATING
(SILVER OR TIN- REFER TO
AX SERIES STANDARD DATA)
D
CONTACT PLATING
Ø 21.2
Ø 15.8
22.7
E
E
F
NOTE:
1. NUMBER "18" AS SHOWN ON THE CONNECTOR VIEWS
IS FOR AN EXAMPLE OF PRINT ONLY.
2. LEADING ZEROS ARE OMITTED IN PRINT NUMBERS.
3. NUMBER 6 AND 9 ARE UNDERLINED.
4. PRINT COLOR IS BLACK FOR WHITE SLEEVE AND WHITE FOR
ALL OF THE REST.
FEMALE CONNECTOR
1:1
UNLESS OTHERWISE SPECIFIED
TOLERANCE TO BE
ANGULAR
LINEAR
X
±
0.5
X
±
1
X.X ±
0.1
X.X' ±
30'
X.X ±
0.05
X.X'X " ± 15'
BREAK ALL SHARP EDGES
AND REMOVE ALL BURRS
THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD.
. NO PART THEREOF MAY BE REPRODUCED AND USED
WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER
.
Amphenol
TITLE:
Amphenol Australia Pty.Ltd,
22 Industry Blvd, Carrum Downs VIC 3201
PART No:
REV
MATERIAL:
F
DRN:
CKD:
T.N
P.M
P.M
DATE:
17/07/17
DATE:
17/07/17
DATE:
17/07/17
SIZE:
DO NOT SCALE
FINISH:
APP'D:
AX SERIES
CABLE CONNECTOR
MARKING SLEEVE
SEE P/No. BREAKDOWN
DRAWING No.
1
SHEET
DIMENSIONS IN MILIMETRES
1
2
3
4
5
THIRD ANGLE
PROJECTION
SCALE:
1:1
6
A3
7
55010255-000-1
1
/
1
CB4.17.F1
