AES/EBU ADAPTER MALE
CategoryThe connector
File Size173KB,1 Pages
ManufacturerSwitchcraft
Environmental Compliance
Download Datasheet Parametric Compare View All

367 Online Shopping

Suppliers Part Number Price MOQ In stock
367 - - View Buy Now

367 Overview

AES/EBU ADAPTER MALE

367 Parametric

Parameter NameAttribute value
Convert from (adapter side)XLR, male pin, 3 position
Convert to (adapter side)BNC plug, male pins
characteristic-
colorsilver
1
_
3
XLR
3.42
86.8
0.51
12.9
0.47
12.0
2
+
110
75 Ω
_
+
TRANSFORMER
BNC
SCHEMATIC
2.91
73.9
0.47
12.0
QG3F
0.74
18.9
QG3M
0.74
18.9
FEMALE XLR TO BNC
366
MALE XLR TO BNC
367
CUSTOMER DRAWING
NOTES:
1. MATERIALS:
ADAPTER HOUSING - ZINC, NICKEL PLATED
BNC HOUSING -COPPER ALLOY, NICKEL PLATED
BNC CONTACT - COPPER ALLOY, GOLD PLATED
QG3M OR QG3F XLR CONNECTOR
2. THESE PRODUCTS ARE RoHS COMPLIANT.
C
B
A
REV
26634
26594
26407
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
10-08-10
08-12-10
6-25-09
DATE
SIZE
FINISH
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
0.02
0.005
JEB
JEB
JEB
BY
TJK
TJK
TJK
APVD
- THREE PLACE DECIMALS
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
SCALE
1.5:1
1/2/08
BS
JEB
08-14-09
TJK
01-10-11
PART No.
APVD
SHEET
1
OF
1
REV
ECO NUMBER
REVISIONS
DO NOT SCALE DRAWING
NAME
XLR TO BNC IMPEDANCE
MATCHING ADAPTER, RoHS
366-367
C
SolidWorks CAD File
