5/8
M16*
3009/3029/3039
3044/3045/3046
HIGH
RESOLUTION
VRS
SENSORS
30X9 SERIES
Mates with 41010(VR) Connector or CA210 Cable Assembly
304X SERIES
FOR SPEED SENSING APPLICATIONS WHERE A PRECISE TIMING PULSE IS REQUIRED, AND/OR FINE PITCH GEARS
ARE USED. PROPER ALIGNMENT OF SENSOR IS REQUIRED.
OPER. TEMP. :
-67 to 250F (-55 to 120C)
THREAD*:
5/8 - 18 UNF-2A
VIBRATION:
Meets Mil-Std 202F Method 204D
SENSORS WITH .010" WIDE CHISEL POLE PIECE
MODEL
3009AN
3029AN
3039AN**
0
200
175
3029AN
150
125
2.5
5.1
7.6
GEAR PITCH RANGE: 36 DP (MODULE 0.7) OR COARSER
INDUCTANCE
25 mH max.
450 mH max.
85 mH max.
MIN.SURFACE
SPEED (Typ.)
20 IPS
10 IPS
15 IPS
MAX. OPER.
FREQ. (Typ.)
50 KHz
15 KHz
40 KHz
OUTPUT VOLTAGE
34V P-P min.
170V P-P min.
40V P-P min.
METERS / SECOND
10.1
12.7
15.2 17.8
20.3
22.9
25.4
COIL
RESISTANCE
45 to 85 OHMS
910 to 1200 OHMS
120 to 162 OHMS
** Test Condition B
VRS Tech Data
V P/P
100
75
50
3039AN
25
3009AN
0
100
200
300
400
500
600
700
800
900
1000
INCHES / SECOND
WEIGHT 2.5 oz. (70 gr.)
GEAR PITCH RANGE: 24 DP (MODULE 1.05) OR COARSER
INDUCTANCE
25 mH max.
450 mH max.
85 mH max.
MIN.SURFACE
SPEED (Typ.)
20 IPS
10 IPS
15 IPS
MAX. OPER.
FREQ. (Typ.)
50 KHz
15 KHz
40 KHz
SENSORS WITH .045" WIDE CHISEL POLE PIECE
MODEL
3044A
3045A
3046A**
0
400
350
300
250
3045A
2.5
5.1
OUTPUT VOLTAGE
80V P-P min.
300V P-P min.
65V P-P min.
METERS / SECOND
7.6
10.1
12.7
15.2 17.8
20.3
22.9
25.4
COIL
RESISTANCE
45 to 85 OHMS
910 to 1200 OHMS
120 to 162 OHMS
** Test Condition B
VRS Tech Data
V P/P
200
150
100
3044A
50
3046A
0
100
200
300
400
500
600
700
800
900
1000
INCHES / SECOND
WEIGHT 2.5 oz. (70 gr.)
*For M16 x 1.5 6g Mounting Thread Versions, add “M” as the first character of the model number.
Contact Invensys/Electro for availability and pricing.
Invensys Sensor Systems / Electro Corporation, U.S.A.
Tel. 941-355-8411
www.speed-position.invensys.com
Fax 941-355-3120
