INTERCONNECTS
SERIES 410, 411, 415 • .100” GRID SOLDER TAIL •
DOUBLE ROW STRIPS
•
Series 41X double row strip sockets are on
.100” grid
•
Various solder tails available: standard length,
.015-.025
.010 * .018
.146
.095
.110
long for multi-layer boards, very low and ultra
low profile. See Mill-Max #1001, #0134, #0501
or #1534 pins. See pages 161, 162 and 165
for details
.165
•
Hi-Rel, 4-finger BeCu #12 and #30 contact are
rated at 3 amps. See pages 252 and 253 for
details
.020 DIA.
.125
.100
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
FIG. 1
.015-.025
.010 * .018
ORDERING INFORMATION
Series 410...001
.165
Standard Solder Tail
410-XX-2_ _-41-001000
.150
.103
.110
FIG. 1
Series 411...001
.020 DIA.
Specify number of pins
.170
04-64
Long Solder Tail
411-XX-2_ _-41-001000
.100
FIG. 2
.015-.025
.010 * .018
FIG. 2
Series 415...001
.122
Specify number of pins
04-64
Very Low Profile
415-XX-2_ _-41-001000
.151
.096
.110
FIG. 3
Series 415...003
Specify number of pins
.030 DIA.
.108
04-64
Ultra Low Profile
415-XX-2_ _-41-003000
.100
FIG. 4
FIG. 3
PAGE 66 | INTERCONNECTS
.015-.022
.010 * .018
Specify number of pins
04-64
.071
.155
.071
.095
.095
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
11
10
μ”
Au
10
μ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.100
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
13
30
μ”
Au
91
10
μ”
Au
93
30
μ”
Au
41
10
μ”
Au
43
200
μ”
Sn
30
μ”
Au
47
200
μ”
Sn
Au Flash
FIG. 4
10
μ”
Au
200
μ”
Sn/Pb 200
μ”
Sn/Pb
200
μ”
Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
