HDB-78PMMP-SL7001 datasheet, PDF

Datasheet> All Categories > The connector> HDB-78PMMP-SL7001

HDB-78PMMP-SL7001: DescriptionD-SUB CONN; CategoryThe connector; File Size83KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/; Environmental Compliance

Download Datasheet Parametric View All

HDB-78PMMP-SL7001 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HDB-78PMMP-SL7001	-	-	View	Buy Now

HDB-78PMMP-SL7001 Overview

D-SUB CONN

HDB-78PMMP-SL7001 Parametric

Parameter Name	Attribute value
Connector style	D-Sub, high density
Connector type	Plug, male pin
Number of pins	78
Number of rows	4
Housing size, connector layout	5 (DD, D) high density
Contact type	Signal
Installation type	Panel mount, through hole
Flange characteristics	Mating side, female anti-falling screw (4-40)
Termination	welding
characteristic	Ground notch, shielded
Housing material, plating	Steel, nickel plated
Contact plating	gold
Contact plating thickness	-
Intrusion protection	IP67 - dust and water resistant
Material flammability rating	-
Rated current	2A
Operating temperature	-40°C ~ 105°C
Rated voltage	-
color	black
Contact shape	-
Shell material	Polybutylene terephthalate (PBT)
Wire gauge	-
Contact material	copper alloy
Braking device interval	-

Preview

Download Datasheet

View All

Amphenol LTW Technology Co., Ltd.

D-USB Connectors

Specification

> Standard

(SDB)

D-SUB

Number of Contacts

09,15,,25,26...78 Contacts

Ex. 09 Pin =

(09)

Connector Body (Style)

> For Receptacle

(P)

Front Fastened

> For Overmolded with Cable

(A)

With Strain Relief

> For Field installable

(B)

Without Strain Relief

> High Density

(HDB)

High Density D-SUB

Connector (Housing) Gender

(M)

Male Connector

(F)

Female Connector

Contact Gender

(M)

Male (Plug)

Assemble Style

> For Receptacle

(S)

Solder Type

(P)

PCB Type (90° / 180°)

(F)

Female (Jack)

> For Overmolded with Cable

(M)

Overmolded with Cable

> For Field Installable

(A)

Field Installable (Solder)

(C)

Field Installable (Crimped)

(Q)

Automated Latch

> For Overmolded with Cable

(Without Board Lock)

(L)

Straight

> For Field Installable

(Without Board Lock)

(L)

Straight

Mating Style

(S)

Screw Thread

Backshell

> For Receptacle

(With Board Lock)

(A)

Straight

(B)

Right Angle

(Without Board Lock)

(L)

Straight

(R)

Right Angle

Waterproof Rating

(7)

IP 67

(8)

IP 68

More Information

> For Receptacle

(001), (002)……

Without Cable : Different

Versions

> For Overmolded with Cable

(□)+(■) : Cable Type + Cable Length

EX.

(A01)

= UL2464 Cable + 1M

(□) : Cable Type

(A)

UL2464 Cable

(■) : Cable Length

From 1M to 99M

EX.

(01)

= 1M

Innovation in Waterproof Solution
