128-Channel Serial to Parallel Converter with Push-Pull Outputs
Features
• 128 High-Voltage Channels
- Up to 80V Operating Output Voltage
- 30 mA Peak Output Sink/Source Current
- Output Diodes to Ground for Efficient Power
Recovery
• Four Separate Shift Registers
- Clockwise and Counter-Clockwise Data
Shifting via DIR Pin
• 40 MHz Data Rate
Description
HV583 is a unipolar, 128-channel low-voltage serial to
high-voltage parallel converter with push-pull outputs.
This device has been designed for applications
requiring multiple high-voltage outputs with current
sinking and sourcing capabilities, such as plasma
displays and Inkjet printers.
The device consists of four parallel 32-bit shift
registers, a 128-bit latch and 128 high-voltage outputs.
Data can be input at 40 MHz or up to 25 MHz when
cascaded in a multiple device configuration.
HV583 is offered in a 169-ball 10 x 10 x 1.1 mm
TFBGA package.
Applications
• Inkjet Printer Driver
• Plasma Display Driver
• 3D Printer Driver
Package Type
HV583
10x10x1.1 mm TFBGA*
Bottom View
13
12
11
10
9
8
7
6
5
4
3
2
1
Related Devices
•
HV582:
96-Channel Serial to Parallel Converter
with Push-Pull Outputs
A
B
C
D
E
F
G
H
J
K
L
M
N
* See Section
Section 2.0 “Package Pin Configurations
and Function Description”.
2015 Microchip Technology Inc.
DS20005461A-page 1
HV583
Block Diagram
V
DD
V
PP
D1B
32-Bit
Shift
Register
D
0
D
1
D
2
D
3
D
4
D
5
D
6
D
7
D1A
D2B
32-Bit
Shift
Register
D2A
D3B
32-Bit
Shift
Register
D3A
D4B
32-Bit
Shift
Register
D4A
CLK
DIR
RST
LE
OH
OL
OE
D
GND
Q
0
Q
1
Q
2
Q
3
Q
4
Q
5
Q
6
Q
7
HV
OUT
0
128-Bit
Latch
D
124
D
125
D
126
D
127
Q
124
Q
125
Q
126
Q
127
HV
OUT
127
P
GND
DS20005461A-page 2
2015 Microchip Technology Inc.
HV583
1.0
ELECTRICAL
CHARACTERISTICS
Absolute Maximum Rating†
Supply Voltage V
DD
.................................................................................................................................... -0.5V to +6.5V
High-Voltage Supply V
PP
............................................................................................................................ -0.5V to +90V
Output Sink and Source Current I
OUT
.................................................................................................. -65 mA to +40 mA
Output Body Diode Current I
DIODE
....................................................................................................... -65 mA to +65 mA
Logic Input Voltage..............................................................................................................................-0.5V to V
DD
+0.5V
Operating Junction Temperature.............................................................................................................-25°C to +125°C
Storage Temperature ..............................................................................................................................-40°C to +150°C
†Notice:
Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the device.
This is a stress rating only and functional operation of the device at those or any other conditions above those indicated in
the operational listings of this specification is not implied. Exposure to maximum rating conditions for extended periods may
affect device reliability. Device is ESD sensitive. Use appropriate ESD precautions.
RECOMMENDED OPERATING CONDITIONS
Parameter
High-Voltage Supply
Low-Voltage Supply
HV
OUT
Peak Output Current
V
PP
Power Supply Slew Rate
Clock Frequency
Symbol
V
PP
V
DD
I
OUT
SR
f
CLK
Min.
15
4.5
-30
-
-
-
Typ.
-
5.0
-
-
-
-
Max.
80
5.5
30
8.0
40
25
Units
V
V
mA
V/μs
MHz
MHz
Data Read
Cascaded Devices
Conditions
TABLE 1-1:
POWER SEQUENCES
Steps
1.
2.
3.
4.
Connect Ground.
Apply V
DD.
Set All Inputs (Data, CLK, etc.) to a known state.
Apply V
PP
Sequence Type
Power- Up Sequence
Power- Down Sequence
Repeat the Power-Up sequence in reverse order.
DC ELECTRICAL CHARACTERISTICS
Electrical specifications:
Unless otherwise specified, T
A
= T
J
= +25°C, V
DD
= 5.0V and V
PP
= 80V.
Parameter
V
PP
Quiescent Supply Current
V
DD
Quiescent Supply Current
High-Level Output Voltage
Output P-Channel Body Diode
Low-Level Output Voltage
Output N-Channel Body Diode
Note 1:
Symbol
I
PPQ
I
DDQ
HV
OH
HV
OHD
HV
OL
HV
OLD
Min.
—
—
73
10
—
—
-1.5
Typ.
—
—
76
—
—
3.0
—
Max.
10
10
—
—
81.5
6.0
—
V
V
V
Units
μA
μA
V
I
OUT
= 15 mA, V
PP
= 80V
I
OUT
= 10 mA, V
PP
= 20V
I
OUT
= -30 mA, V
PP
= 80V
(Note
1)
I
OUT
= -15 mA
I
OUT
= 30 mA (Note
1)
Conditions
Specification is for design guidance only.
2015 Microchip Technology Inc.
DS20005461A-page 3
HV583
DC ELECTRICAL CHARACTERISTICS (CONTINUED)
Electrical specifications:
Unless otherwise specified, T
A
= T
J
= +25°C, V
DD
= 5.0V and V
PP
= 80V.
Parameter
Logic Input High Voltage
Logic Input Low Voltage
Logic Input High Current
Logic Input Low Current
Logic Output High
Logic Output Low
Note 1:
Symbol
V
IH
V
IL
I
IH
I
IL
V
OH
V
OL
Min.
2.3
0
—
10
-1.0
4.5
—
Typ.
—
—
—
30
—
—
—
Max.
V
DD
0.7
1.0
60
—
—
0.5
V
μA
Units
V
Conditions
V
DD
= 4.5V to 5.5V
V
DD
= 4.5V to 5.5V
V
IH
= 5.3V, V
DD
= 5.0V
V
IH
= 5.0V, for DIR only
V
IL
= -0.3V
I
OUT
= 1.0 mA
I
OUT
= -1.0 mA
Specification is for design guidance only.
AC ELECTRICAL CHARACTERISTICS
Electrical specifications:
Unless otherwise specified T
A
= T
J
= 25°C, V
DD
= 5.0V and V
PP
= 80V
Parameter
Clock Pulse Width, High and Low
(1)
LE Pulse Width, High and Low
(2)
Setup Time, DnA/B to CLK
(1)
Setup Time, CLK to LE
(1)
(1)
Symbol
t
wCLK
t
wLE
t
su1
t
su2
t
su3
t
h1
t
h2
t
pdHL
t
pdLH
t
pHL
t
pLH
t
pHZL
t
pLZH
t
pHZ
t
pLZ
t
r
t
f
Min.
10
10
5
10
25
5
10
—
—
—
Typ-40
—
Typ-40
—
—
—
—
Typ.
—
—
—
—
—
—
—
—
—
—
t
pHL
+ t
f
—
t
pHL
+ t
f
—
—
—
—
Max.
—
—
—
—
—
—
—
25
25
150
Typ+40
150
Typ+40
300
300
120
120
Units
ns
Conditions
V
DD
= 4.5V to 5.5V
T
J
= -25°C to 125°C
Setup Time, LE to OL,OH
Hold Time, CLK to DnA/B
Hold Time, LE to CLK
(1)
(1)
CLK to DnA/B (High-to-Low)
CLK to DnA/B (Low-to-High)
LE,OL,OH to HV
OUT
n (High-to-Low)
LE,OL,OH to HV
OUT
n (Low-to-High)
OE to HV
OUT
n (High-to-Low)
OE to HV
OUT
n (Low-to-High)
OE to HV
OUT
n (High-to-Low)
OE to HV
OUT
n (Low-to-High)
Rise Time HV
OUT
n
Fall Time HV
OUT
n
Note 1:
2:
C
L
= 15 pF
C
L
= 15 pF
C
L
= 50 pF
C
L
= 80 pF
C
L
= 50 pF
C
L
= 80 pF
R
L
= 10K, C
L
= 50 pF
R
L
= 10K, C
L
= 50 pF
C
L
= 50 pF
C
L
= 50 pF
Specification is obtained by characterization and is not 100% tested.
