Linear Position Sensors
LIN Sensors – Kit with magnet
Thin, programmable, non-contact magnetic position sensors
with dual outputs available
Description
The LIN Series sensors are non-contact linear position sensors with one or two independent outputs. The sensors operate through the
use of Hall Effect technology with magnetic fields generated by permanent magnets. They provide a linear change in voltage output
(ratiometric to the input voltage) corresponding to a linear displacement of the actuator magnet.
The included actuator magnet is specifically paired to the sensor and is required to assure proper operation. Other magnets may yield
less than optimal performance.
Features
Easy setup and robust monitoring with M4 screws
Dual independent (redundant) outputs assure high reliability
Custom programming available for: range, slope, PWM output
No mechanical interface means no parts to wear out or jam
Comes with 20 AWG 305 mm (12”) discrete wire leads or harness
with connector
RoHS Compliant
IP68*
Suitable for wide air gap applications
Compliant to industrial/automotive EMC/EMI/ESD directives
Typical Applications
Hydraulic valves
Hydraulic controls
Electric drives
Pneumatic controls
Zero-contact encoder alternative
Gear selection / shifting position
Environmental Specifications
Operating Temperature
Ingress Protection
*Contact ZF for details on testing conditions
-40
⁰
C to 140
⁰
C (-40
⁰
F to 284
⁰
F)
IP68*
Electrical Specifications
Input
Supply Voltage
5.0 VDC ± 10%
Output Signal
Input Current
Resolution
Accuracy, overall
Output Linearity
Maximum Overvoltage
16 VDC
0.5 – 4.5 VDC (with nominal input)
Single output
Dual output
12 bit
±2% Full scale
±1%Full scale
Reverse Battery Protection
12 VDC
8 mA typ., 10 mA max.
16 mA typ., 20 mA max.
Mechanical Specifications
Measuring Range
Air Gap**
Maximum Magnet Misalignment
Up to 45 mm
4.5 mm (0.18”)
2 mm (0.08”)
**Output is calibrated to meet spec within air gap shown; any variation will affect performance
www.cherryswitches.com
Page 1 of 2
Last update 2016-07-12; specifications subject to change without notice.
