Current Foldback Protection (Disabled at Start-Up)
Parallel/Current Sharing
Ultrafast Transient Response
Current Mode Control
Programmable Soft-Start
Output Overvoltage Protection
–55°C to 125°C Operating Temperature Range
(LTM4612MPV)
Small Surface Mount Footprint, Low Profile
(15mm
×
15mm
×
2.8mm) LGA Package
LTM4612
EN55022B Compliant
36V
IN
, 15V
OUT
, 5A,
DC/DC µModule Regulator
DESCRIPTION
The
LTM
®
4612
is a EN55022 Class B certified high voltage
input and output, 5A switching mode DC/DC power supply.
Included in the package are the switching controller, power
FETs, inductor and all support components. Operating
over an input voltage range of 5V to 36V, the LTM4612
supports an output voltage range of 3.3V to 15V, set by a
single resistor. Only bulk input and output capacitors are
needed to finish the design.
High switching frequency and an adaptive on-time current
mode architecture enables a very fast transient response
to line and load changes without sacrificing stability.
The onboard input filter and noise cancellation circuits
achieve low noise coupling, thus effectively reducing the
electromagnetic interference (EMI)—see Figures 4 and 8.
Furthermore, the DC/DC µModule
®
regulator can be syn-
chronized with an external clock to reduce undesirable
frequency harmonics and allow PolyPhase
®
operation for
high load currents.
The LTM4612 is offered in a space saving and thermally
enhanced 15mm
×
15mm
×
2.8mm LGA package, which
enables utilization of unused space on the bottom of PC
boards for high density point-of-load regulation. The
LTM4612 is Pb-free and RoHS compliant.
L,
LT, LTC, LTM, Linear Technology, the Linear logo, PolyPhase and µModule are registered
trademarks and LTpowerCAD is a trademark of Linear Technology Corporation. All other
trademarks are the property of their respective owners.
APPLICATIONS
n
n
n
Telecom and Networking Equipment
Industrial and Avionic Equipment
RF Systems
TYPICAL APPLICATION
5V/5A Ultralow Noise µModule with 7V to 36V Input
V
IN
7V
TO 36V
CLOCK SYNC
2M
100k
V
IN
PLLIN
V
OUT
PGOOD
RUN LTM4612
COMP
INTV
CC
DRV
CC
f
SET
TRACK/SS
V
D
SGND
V
FB
FCB
MARG0
MARG1
MPGM
PGND
V
OUT
5V
5A
Radiated Emission Scan at 24V
IN
, 5V
OUT
/5A
70
60
50
40
dBµV/m
30
20
10
0
–10
30
226.2 422.4 618.6 814.8
1010
128.1 324.3 520.5 716.7 912.9
FREQUENCY (MHz)
4612 TA01b
4612fc
EN55022 CLASS B LIMIT
100pF
13.7k
MARGIN
CONTROL
392k
5% MARGIN
4612 TA01
C
OUT
C
IN
0.01µF
10µF
For more information
www.linear.com/LTM4612
1
LTM4612
ABSOLUTE MAXIMUM RATINGS
(Note 1)
PIN CONFIGURATION
INTV
CC
PLLIN
TRACK/SS
RUN
COMP
MPGM
V
D
SGND
f
SET
MARG0
MARG1
DRV
CC
V
FB
PGOOD
SGND
NC
NC
NC
FCB
TOP VIEW
INTV
CC,
DRV
CC
............................................. –0.3V to 6V
V
OUT
........................................................... –0.3V to 16V
PLLIN, FCB, TRACK/SS, MPGM, MARG0,
MARG1, PGOOD ....................–0.3V to INTV
CC
+ 0.3V
RUN ............................................................. –0.3V to 5V
V
FB
, COMP ................................................ –0.3V to 2.7V
V
IN
, V
D
....................................................... –0.3V to 36V
Internal Operating Temperature Range (Note 2)
E and I Grades ................................... –40°C to 125°C
MP Grade ........................................... –55°C to 125°C
Junction Temperature ........................................... 125°C
Storage Temperature Range .................. –55°C to 125°C
A
V
IN
B
BANK 1
C
D
E
PGND
BANK 2
F
G
H
J
V
OUT
K
BANK 3
L
M
1 2 3 4 5 6 7 8 9 10 11 12
LGA PACKAGE
133-LEAD (15mm × 15mm × 2.8mm)
T
JMAX
= 125°C,
θ
JA
= 15°C/W,
θ
JC
= 6°C/W
θ
JA
DERIVED FROM 95mm
×
76mm PCB WITH 4 LAYERS
WEIGHT = 1.7g
ORDER INFORMATION
LEAD FREE FINISH
LTM4612EV#PBF
LTM4612IV#PBF
LTM4612MPV#PBF
TRAY
LTM4612EV#PBF
LTM4612IV#PBF
LTM4612MPV#PBF
http://www.linear.com/product/LTM4612#orderinfo
PART MARKING*
LTM4612V
LTM4612V
LTM4612MPV
PACKAGE DESCRIPTION
133-Lead (15mm
×
15mm
×
2.8mm) LGA
133-Lead (15mm
×
15mm
×
2.8mm) LGA
133-Lead (15mm
×
15mm
×
2.8mm) LGA
TEMPERATURE RANGE
–40°C to 125°C
–40°C to 125°C
–55°C to 125°C
Consult LTC Marketing for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
This product is only offered in trays. For more information go to:
http://www.linear.com/packaging/
The
l
denotes the specifications which apply over the specified internal
operating temperature range, otherwise specifications are at T
A
= 25°C, V
IN
= 24V, unless otherwise noted (Note 2). Per Typical
Application (front page) configuration.
SYMBOL
V
IN(DC)
V
OUT(DC)
Input Specifications
V
IN(UVLO)
I
INRUSH(VIN)
Undervoltage Lockout Threshold
Input Inrush Current at Start-Up
I
OUT
= 0A
I
OUT
= 0A; C
IN
= 10µF
×
2, C
OUT
= 200µF;
V
OUT
= 12V
V
IN
= 24V
V
IN
= 36V
3.2
4.8
V
PARAMETER
Input DC Voltage
Output Voltage
C
IN
= 10µF
×
3, C
OUT
= 300µF; FCB = 0
V
IN
= 24V, V
OUT
= 12V, I
OUT
= 0A
V
IN
= 36V, V
OUT
=12V, I
OUT
= 0A
CONDITIONS
l
l
l
ELECTRICAL CHARACTERISTICS
MIN
5
11.83
11.83
TYP
MAX
36
UNITS
V
V
V
12.07
12.07
12.31
12.31
0.6
0.7
A
A
4612fc
2
For more information
www.linear.com/LTM4612
LTM4612
ELECTRICAL CHARACTERISTICS
SYMBOL
I
Q(VIN)
I
S(VIN)
V
INTVCC
I
OUT(DC)
DV
OUT(LINE)
V
OUT
DV
OUT(LOAD)
V
OUT
V
IN(AC)
PARAMETER
Input Supply Bias Current
The
l
denotes the specifications which apply over the specified internal
operating temperature range, otherwise specifications are at T
A
= 25°C, V
IN
= 24V, unless otherwise noted (Note 2). Per Typical
Application (front page) configuration.
CONDITIONS
V
IN
= 36V, V
OUT
= 12V, Switching Continuous
V
IN
= 24V, V
OUT
= 12V, Switching Continuous
Shutdown, RUN = 0, V
IN
= 36V
V
IN
= 36V, V
OUT
= 12V, I
OUT
= 5A
V
IN
= 24V, V
OUT
= 12V, I
OUT
= 5A
V
IN
= 36V, RUN > 2V, I
OUT
= 0A
V
IN
= 24V, V
OUT
= 12V (Note 4)
V
OUT
= 12V, FCB = 0V, V
IN
= 22V to 36V,
I
OUT
= 0A
V
OUT
= 12V, FCB = 0V, I
OUT
= 0A to 5A (Note 4)
V
IN
= 36V
V
IN
= 24V
I
OUT
= 0A,
C
IN
= 2
×
10µF X5R Ceramic and 1
×
100µF
Electrolytic, 1
×
10µF X5R Ceramic on V
D
Pins
V
IN
= 24V, V
OUT
= 5V
V
IN
= 24V, V
OUT
= 12V
I
OUT
= 0A,
C
OUT
= 2
×
22µF 2
×
47µF X5R Ceramic
,
V
IN
= 24V, V
OUT
= 5V
V
IN
= 24V, V
OUT
= 12V
I
OUT
= 1A, V
IN
= 24V, V
OUT
= 12V
C
OUT
= 200µF V
OUT
= 12V, I
OUT
= 0A
,
V
IN
= 36V
V
IN
= 24V
C
OUT
= 300µF V
OUT
= 12V, I
OUT
= 1A
,
Resistive Load
V
IN
= 36V
V
IN
= 24V
Load: 0% to 50% to 0% of Full Load
C
OUT
= 2
×
22µF Ceramic, 150µF Bulk
V
IN
= 24V, V
OUT
= 12V
C
OUT
= 200µF
V
IN
= 36V, V
OUT
= 12V
V
IN
= 24V, V
OUT
= 12V
I
OUT
= 0A, V
OUT
= 12V
V
SS/TRACK
= 0V
V
FCB
= 0V
(Note 3)
(Note 3)
l
l
MIN
TYP
57
48
50
1.85
2.72
MAX
UNITS
mA
mA
µA
A
A
Input Supply Current
Internal V
CC
Voltage
Output Continuous Current Range
Line Regulation Accuracy
Load Regulation Accuracy
4.7
0
5
5.5
5
V
A
%
%
%
Output Specifications
0.05
0.3
0.3
0.3
0.6
0.6
l
l
Input Ripple Voltage
7.2
3.4
mV
P-P
mV
P-P
mV
P-P
mV
P-P
kHz
mV
mV
V
OUT(AC)
Output Ripple Voltage
17.5
12.5
940
20
20
f
S
DV
OUT(START)
t
START
Output Ripple Voltage Frequency
Turn-On Overshoot,
TRACK/SS = 10nF
Turn-On Time, TRACK/SS = Open
0.5
0.5
153
37
9
9
0.591
1
–1
0.57
0.6
1.5
–1.5
0.6
–1
50
250
50
0.609
1.9
–2
0.63
–2
100
400
ms
ms
mV
µs
A
A
V
V
µA
V
µA
ns
ns
kW
4612fc
DV
OUT(LS)
t
SETTLE
I
OUT(PK)
Control Section
V
FB
V
RUN
I
SS / TRACK
V
FCB
I
FCB
t
ON(MIN)
t
OFF(MIN)
R
PLLIN
Peak Deviation for Dynamic Load
Settling Time for Dynamic Load Step Load: 0% to 50% to 0% of Full Load, V
IN
= 24V
Output Current Limit
Voltage at V
FB
Pin
RUN Pin On/Off Threshold
Soft-Start Charging Current
Forced Continuous Threshold
Forced Continuous Pin Current
Minimum On-Time
Minimum Off-Time
PLLIN Input Resistor
For more information
www.linear.com/LTM4612
3
LTM4612
ELECTRICAL CHARACTERISTICS
SYMBOL
I
DRVCC
R
FBHI
V
MPGM
V
MARG0
, V
MARG1
PGOOD
DV
FBH
DV
FBL
DV
FB(HYS)
V
PGL
PGOOD Upper Threshold
PGOOD Lower Threshold
PGOOD Hysteresis
PGOOD Low Voltage
V
FB
Rising
V
FB
Falling
V
FB
Returning
I
PGOOD
= 5mA
7
–7
10
–10
1.5
0.15
0.4
13
–13
%
%
%
V
PARAMETER
Current into DRV
CC
Pin
Resistor Between V
OUT
and V
FB
Pins
Margin Reference Voltage
MARG0, MARG1 Voltage Thresholds
The
l
denotes the specifications which apply over the specified internal
operating temperature range, otherwise specifications are at T
A
= 25°C, V
IN
= 24V, unless otherwise noted (Note 2). Per Typical
Application (front page) configuration.
CONDITIONS
V
OUT
= 12V, I
OUT
= 1A
99.5
MIN
TYP
22
100
1.18
1.4
MAX
30
100.5
UNITS
mA
kW
V
V
Note 1:
Stresses beyond those listed under Absolute Maximum Ratings
may cause permanent damage to the device. Exposure to any Absolute
Maximum Rating condition for extended periods may affect device
reliability and lifetime.
Note 2:
The LTM4612E is guaranteed to meet performance specifications
over the 0°C to 125°C internal operating temperature range. Specifications
over the –40°C to 125°C internal operating temperature range are assured
by design, characterization and correlation with statistical process
controls. The LTM4612I is guaranteed to meet specifications over the
–40°C to 125°C internal operating temperature range. The LTM4612MP
is guaranteed and tested over the full –55°C to 125°C internal operating
temperature range. Note that the maximum ambient temperature
consistent with these specifications is determined by specific operating
conditions in conjunction with board layout, the rated package thermal
resistance and other environmental factors.
Note 3:
100% tested at die level only.
Note 4:
See the Output Current Derating curves for different V
京公网安备 11010802033920号
EEWORLD
