Trainer Series
Electronic Trainers
PB-505
Advanced Analog & Digital Design
Workstation
Global Specialties Model PB-505 is an
Advanced Analog & Digital Design
Use the PB-505 to
construct a wide variety
of experiments, including
but not limited to:
Opto-Device Circuits
Clocks
Multivibrators
Oscillator Circuits
Timers
Function Generator Circuits
Logic Circuits
Gates
Counters
Flip-Flops
Analog-to-Digital
Converters
Digital-to-Analog
Converters
Medium Scale Integration
Circuits
Phase Lock Loops
Operational Amplifier
Features:
•
Ideal for analog, digital and microprocessor circuits
•
Includes built-in Function Generator with
continuously variable waveforms
•
Triple output power supply for a variety of DC
voltage levels
•
Two Digital Pulsers for logic test circuits
•
High & low buffered logic indicators
•
Logic Probe
•
AC Output
•
2 BCD to LED display circuits
•
8 channel logic monitor
•
Audio experimentation speaker
•
Removable breadboard plate allows the flexibility of
building circuits away from the lab
•
Analog & Digital optional courseware available
•
3-year warranty on all parts and workmanship.
Experienced designers will also find the
PB-505 an invaluable, capable and reliable
instrument, suitable for the most advanced
and demanding design applications.
Global Specialties trainers provide the most
complete platform required to enable
engineers and technicians to train for
careers in the rapidly growing field of
electronics technology.
The PB-505 can be used to construct basic
series and parallel circuits up to the most
complicated multi-stage microcomputer
circuits, incorporating the latest in industrial
technology.
The PB-505 allows students to learn
valuable hands-on lab experience by
employing necessary breadboarding
techniques, which provide a solid
foundation in circuit experimentation,
analyzing and troubleshooting.
The PB-505’s breadboarding area is
comprised of Global’s “Premium” solderless
breadboards and is backed by an industry
leading 3-year warranty.
Workstation. The PB-505’s robust design
makes it a trainer suitable for all levels of
electronics instruction and design.
Innovative Training Solutions
www.globalspecialties.com
Trainer Series
PB-505
Electronic Trainers
Specifications
Model
PB-505
Input power
Source
AC Line: 115VAC @ 60Hz (typical)
Fixed DC: +5VDC 1.0A max, current limited
Ripple, <5mV
Variable + DC: +1.3V @150mA to +15VDC @
500mA , Ripple < 5mV
Variable - DC: -1.3VDC @ 150mA to -15VDC @
500mA, Ripple < 5mV
(4) Ground, +5 VDC, Variable + DC & Variable -
DC Power Supply Outputs
(2) Pushbutton-operated, open-collector output
pulsers. Each with 1 normally-open, 1 normally-
closed output. Each output sinks up to 250 mA
Detects Logic High, Logic Low and Single Shot
events.
Logic High:
2.2V (nominal) in TTL mode, 70%
of Vcc in CMOS mode.
Logic Low:
0.8V in TTL mode, 30% of Vcc in
CMOS mode.
Memory Mode:
Detects single shot events and
holds indication until Pulse/Mem switch is
toggled
Frequency Range: 0.1Hz to 100KHz, six ranges
Output Voltage: 0 to + 10Vp-p into 50
Ω Load
(20Vp-p in open circuit), short circuit protected
Output Impedance: 600Ω
except TTL
Output waveforms: Sine, Square, Triangle & TTL
Sine Wave Distortion: <3% @ 1Khz Typical
TTL Pulse: Rise & fall time: <25ns, drive 100
TTL Loads
(TTL available when function
generator is set to Square Wave Mode)
Square Wave: Rise and fall times <0.5µs
(8) Logic Switches select Logic High and Logic
Low
Logic Low Level: Ground
Logic High Level: Switchable between +5V and
the variable positive power supplies.
(2) Single Pull Double Throw (SPDT) -
uncommitted
LEDs: 16 LEDs; (8) red to indicate logic high and
(8) green to indicate logic low
Logic High Threshold: 2.2V (nominal) in TTL/+5V
mode, 70% (nominal) of selected operating
voltage in CMOS mode
Logic Low Threshold: 0.8V (nominal) in TTL/+5V
mode, 30% (nominal) of selected operating
voltage in CMOS mode
2 ea BNC - uncommitted
2: 1 kΩ and 10 kΩ
- uncommitted
8 Ω, 0.25 W
- uncommitted
(2) BCD to 7 Segment Display Circuits include
(20 red LEDs and decoder/driver circuitry
Removable Plexiglas Socket Plate (PB-3) with
2520 Tie points with 200 additional buss strip tie
points internally connected to power supply
outputs and ground
10 lbs (4.6 kg)
6.5 x 19 x 11.5" (165 x 482 x 292 mm)
Optional Accessories
Courseware:
Available separately or as a
package (Model PB-505 Lab).
WK-1:
Jumper Wire Kit, 350 pieces
WK-2:
Jumper Wire Kit, 140 pieces
WK-3:
Jumper Wire Kit, 70 pieces
WK-4:
Wire Jumper Kit, 100 wires with
machined tips
GSPA Series:
Prototyping adapters
GSPA-K1:
Surface mount to DIP adapter
kit, 6 adapter boards
GSPA-K2:
Surface mount to DIP adapter
kit, 11 adapter boards
GSA-3185:
Minipro Test Clip Set
PRO-50A:
Digital Multimeter
The
PB-505 Lab
package offers
comprehensive course instruction
covering the following areas:
Advanced
Analog &
Digital
Design
Workstation
Power Supplies
Binding Posts
Pulsers
Logic Probe
Electronic Fundamentals
Fundamentals of Electricity
Ohm’s Law
Series Circuits, Parallel Circuits
Combinational Circuits
Current Control
Closed, open, shorts
Switches
Thevenin’s Theorem
Wheatstone Bridge
Capacitors, Inductors
Phase Shift Circuits
Impedance
Resonant Circuits
Transformers
Rectifiers & Filtering
Integrated Circuits
Transistor Amplifiers
Oscillators
Power Control Circuits
Function
Generator
Logic Switches
Switches
Logic
Indicators
Digital Electronics
Number Systems & Codes
Binary, Decimal, Hexadecimal, Octal &
ASCII
Logic Gates & Boolean Algebra
Combinational Logic Circuits
Flip-Flops
Digital Arithmetic
Counters & Registers
Integrated Circuit Logic Families
TTL Logic
MOSFETS
CMOS
Interfacing CMOS & TTL
Medium Scale Integration
Decoders
Encoders
Data Conversion & Acquisition
Microcomputer Concepts
Connectors
Potentiometers
Speaker
Displays
Breadboards
Weight
Dimensions
Technical data subject to change without notice.
Innovative Training Solutions
© 2011 Global Specialties V102109
22820 Savi Ranch Parkway
www.globalspecialties.com
Yorba Linda, CA 92887
1.800.572.1028
