NOT RECOMMENDED FOR NEW DESIGNS
MCC
TM
Micro Commercial Components
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
LLDB3
SILICON
BIDIRECTIONAL
DIAC
Features
Breakover Voltage: 32V
Breakover Voltage Range: 28V to
36V
Lead Free Finish/RoHS Compliant(Note 3) ("P" Suffix designates
RoHS Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Maximum Ratings
Operating JunctionTemperature: -40 C to +125 C
Storage Temperature: -40 C to +125 C
o
o
o
o
MiniMELF
Electrical Characteristics @ 25
o
C Unless Otherwise Specified
Power dissipation
on Printed
Circuit(l=10mm)
Repetitive Peak
on-state Current
P
C
150mW
T
A
=50
o
C
t
p
=20us,f=120Hz
A
B
C
I
TRM
2.0A
Breakover Voltage
V
BO
Min Typ Max
28 32 36V
C=22nF(Note 2)
DIM
A
B
C
INCHES
MIN
.130
.008
.055
DIMENSIONS
MM
MIN
3.30
.20
1.40
Breakover Voltage
|+V
BO
|
Symmetry
±3V
MAX
.146
.016
.059
MAX
3.70
.40
1.50
NOTE
∅
C=22nF(Note 2)
SUGGESTED SOLDER
PAD LAYOUT
Output
Voltage(Note 1)
Breakover
Current(Note 1)
Rise Time(Note 1)
V
o(min)
I
BO(max)
T
r
I
B(max)
5V
50uA
2.0us
10uA
V
B
=0.5V
BO(max)
C=22nF
0.075”
0.105
Leakage
Current(Note 1)
0.030”
NOTES:1.Electrical characteristics applicable in both forward and
reverse directions.
2.Connected in parallel with the devices.
3.Lead in Glass Exemption Applied,
see EU
Directive Annex 7(C)-I.
Revision:
B
www.mccsemi.com
1 of 3
2012/05/12
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Packing
Tape&Reel:
2.5Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
B
3 of 3
2012/05/12
