Wet Tantalum Capacitors, Military Established Reliability,
MIL-PRF-39006/22/25 Qualified Styles CLR79, CLR81
FEATURES
• Hermetically sealed
• Metal cased
• Axial lead
• Tubular
STYLE, MILITARY SPECIFICATION
• CLR79, M39006/22 MIL-PRF-39006/22
• CLR81, M39006/25 MIL-PRF-39006/25
PERFORMANCE CHARACTERISTICS
www.vishay.com/doc?40188
Operating Temperature:
-55 °C to +125 °C
Capacitance Range:
M39006/22 - 1.7 μF to 1200 μF;
M39006/25 - 6.8 μF to 2200 μF
Capacitance Tolerance:
± 5 %, ± 10 %, ± 20 %
Voltage Rating:
6 V
DC
to 125 V
DC
Established Reliability Tantalum Capacitors to Military
Specification MIL-PRF-39006:
In accordance with the
military specification MIL-PRF-39006 all capacitors are
marked with the military part number (M39006/xx-xxxx)
rather than the older style designation (CLR79, CLR81) and
should be ordered as such.
For information on the performance characteristics of these
capacitors, please refer to the latest issue of the Military
Specification. MIL-PRF-39006 establishes 1000 h failure
rate levels of 1 %, 0.1 %, and 0.01 %. When ordering these
parts, care must be exercised that the correct part number
expressing the appropriate failure level be specified.
Each order for military style capacitors requiring
government inspection must state whether inspection is to
be at the destination or at the Vishay plant. Orders requiring
source inspection cannot be shipped until this has been
accomplished.
ORDERING INFORMATION
M39006
BASIC
DOCUMENT NUMBER
Indicates the basic
specification; in this case
MIL-PRF-39006
/22
SLASH SHEET
-0441
DASH NUMBER
H
DESIGNATION OF HIGH
VIBRATION (OPTIONAL)
H, optional, if specified
Indicates the specification
sheet of the basic
military specification
Taken from Standard /
Extended Ratings tables
Revison: 28-Aug-17
Document Number: 40022
1
